EI Ei100R3 Instruction Leaflet

12 volt relay smoke & heat alarms
Hide thumbs Also See for Ei100R3:

Advertisement

Table of Contents

13425-R1-12V COMMON-UC
SMOKE & HEAT ALARMS
IONISATION
MODEL Ei100R3
INSTRUCTION LEAFLET
Contains vital information on unit operation and installation.
Read and retain carefully. If you are just installing this unit this
leaflet MUST be given to the householder.
*
The Ei105R4 operating range 8 to 16V
Basic informat
© Ei Electronics 2009
READ THIS FIRST
IDEALLY INSTALL IN THE CENTRE OF CEILING AT
LEAST 300mm (12") FROM LIGHT FITTINGS. KEEP
ION-ISATION ALARMS AWAY FROM KITCHENS TO
PREVENT NUISANCE ALARMS. INTERCONNECT
ALL ALARMS.
ENSURE
THE
CONNECTED TO THE ALARMS.
DO NOT FIT ACTUAL ALARM UNTIL ALL BUILDING
WORK IS COMPLETED TO AVOID CONTAMINATION.
AFTER CHECKING OPERATION, COVER SMOKE
ALARM WITH DUST COVER UNTIL REQUIRED FOR
USE.
LOCATE IONISATION ALARMS (Ei100R3) AWAY
FROM
KITCHENS
ALARMS.
IF A NUISANCE ALARM OCCURS, FAN THE ALARM
VIGOROUSLY WITH A NEWSPAPER TO HELP
CLEAR THE SENSOR.
TEST WEEKLY - PRESS THE BUTTON FOR 10
SECONDS AND A RED LIGHT BEHIND THE BUTTON
OR
ON
THE
INTERCONNECTED ALARMS WILL ALSO SOUND.
29/9/09
7:56 AM
Page 1
12 VOLT RELAY
OPTICAL
MODELS Ei105R3
*
Ei105R4
P/N B13425 Rev 1
12V
PANEL
IS
TO
PREVENT
COVER
SHOULD
1
HEAT
MODEL Ei103R
CORRECTLY
NUISANCE
FLASH.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ei100R3 and is the answer not in the manual?

Questions and answers

Related Manuals for EI Ei100R3

Summary of Contents for EI Ei100R3

  • Page 1 CONNECTED TO THE ALARMS. DO NOT FIT ACTUAL ALARM UNTIL ALL BUILDING WORK IS COMPLETED TO AVOID CONTAMINATION. AFTER CHECKING OPERATION, COVER SMOKE ALARM WITH DUST COVER UNTIL REQUIRED FOR USE. LOCATE IONISATION ALARMS (Ei100R3) AWAY FROM KITCHENS PREVENT NUISANCE ALARMS.

  • Page 2: Read This First

    13425-R1-12V COMMON-UC 29/9/09 7:56 AM Page 2 READ THIS FIRST CONT. CLEAN YOUR SMOKE ALARM REGULARLY. THIS WILL REDUCE THE RISK OF FALSE ALARMS. REMOVE OR COMPLETELY COVER YOUR SMOKE ALARM WHEN REDECORATING TO PREVENT DUST OR OTHER CONTAMINATION DAMAGING THE UNIT.
  • Page 3 13425-R1-12V COMMON-UC 29/9/09 7:56 AM Page 3 Protection Levels Minimum Protection Recommended Protection All the Heat Alarms and Smoke Alarms should be interconnected to ensure the early warning will be heard, particularly by somebody sleeping. A properly designed early warning fire system ensures the alarm is given before the escape routes become blocked with smoke.
  • Page 4 13425-R1-12V COMMON-UC 29/9/09 7:56 AM Page 4 Single Storey Dwelling If the Home is on one level (a bungalow or mobile home for example) you should put the first Smoke Alarm in a corridor or hallway between the sleeping and living areas. Place it as near to the living area as possible, but make sure you can hear it loudly enough to wake a person in the bedrooms.
  • Page 5 If a Smoke Alarm is too far away for it to wake a person, it is best to interconnect it to another Smoke Alarm or Heat Alarm near the bedroom. The following alarms Ei100R3, 105R3, 105R4 & 103R can be interconnected - when one alarm senses smoke, all interconnected alarms respond (see below for further details).
  • Page 6 13425-R1-12V COMMON-UC 29/9/09 7:56 AM Page 6 walls etc). Temperature differences might stop smoke or heat from reaching the unit. • Next to or directly above heaters or air conditioning vents, windows, wall vents etc. that can change the direction of airflow.

  • Page 7: Installation Instructions

    13425-R1-12V COMMON-UC 29/9/09 7:56 AM Page 7 Wall Mounting (Smoke Alarm only) When a ceiling position is not practical (for example on a ceiling having exposed beams or joists, or built-in radiant heating) put the top edge of your Smoke Alarm between 150 and 300mm (6 and 12 inches) below the ceiling.
  • Page 8 Interconnecting Smoke Alarms and Heat Alarms When a fire is sensed the alarm must be given throughout the house. Up to twelve (12) Smoke Alarms (models Ei100R3, Ei105R3 & Ei105R4 only) and Heat Alarms (model Ei103R only) can be interconnected so that when one senses fire all alarm.
  • Page 9 13425-R1-12V COMMON-UC 29/9/09 7:56 AM Page 9 After Installation Test all units by pressing the test buttons in sequence. The Smoke/Heat Alarm horn should sound within 10 seconds and the relay contacts should change over about 4 seconds after the horn sounds. All interconnected alarms should sound within 10 seconds.

  • Page 10: Nuisance Alarms

    If you experience persistant nuisance alarms with the Ei100R3 Ionisation alarm due to cooking fumes you could consider replacing it with an Optical Alarm (Ei105R3 or Ei105R4) as they are significantly less susceptible to cooking fumes.

  • Page 11: Important Safeguards

    • Smoke / Heat Alarms are not a substitute for insurance. The supplier or manufacturer is not your insurer. • The chamber inside the Ionisation (Ei100R3) Smoke Alarm contains a small amount of radioactive material (33kBq of Americium 241). Do not tamper with the chamber. You may safely install and clean the Smoke Alarm following this leaflet’s instructions.
  • Page 12 13425-R1-12V COMMON-UC 29/9/09 7:56 AM Page 12 1. Check room doors for heat or smoke. Do not open a hot door. Use an alternate escape route. Close doors behind you as you leave. 2. If smoke is heavy, crawl out, staying close to floor.

  • Page 13: Getting Your Alarm Serviced

    What is the best Smoke Alarm - Optical or Ion ? Both types respond in all standard fires but each type may respond faster to particular fires as shown. The EI company manufactures complementary 12 Volt Smoke Alarms , Optical Smoke Alarm Ei105R3 &...

  • Page 14: Specifications

    7:56 AM Page 14 FIVE YEAR PRODUCT GUARANTEE Ei Electronics guarantees this product (excluding battery) against any defects that are due to faulty material or workmanship for a five year period after the original date of consumer purchase or receipt as a gift. This guarantee does not include damage to the product resulting from accident or misuse.

  • Page 15: Troubleshooting

    24 Volts/1 Amp (resistive), normally closed and normally open. Interconnect: Up to 12 Ei100R3 / 105R3 / 105R4 / 103R only can be interconnected. Max cable resistance 20 ohms. LED flashes every second to identify the unit sensing fire. (I/O line can supply 3.5 volts at 4 mA)
  • Page 16 Ionisation type alarm. Ei Electronics. Shannon, Co. Clare, Ireland. e-mail. eielectronics@eiltd.ie Ei Electronics. 9 Grundy St., Liverpool L5-9SG. Phone: +44 (0)151 2981588. Fax: +44 (0)151 2073312. e-mail: sales.uk@eiltd.ie The crossed out wheelie bin symbol that is on your product indicates that this product should not be disposed of via the normal household waste stream.
