Senal CSP-142 User Manual

Csp series
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
CSP-SERIES
Thank you for choosing Senal.
The. CSP-series. speakers. are. passive. coaxial. two-way. speakers. that. provide. premium. sound.
quality.for.use.with.70V.or.100V.systems.and.for.low-ohm.systems.
These.high.power.-.low.distortion.speakers.feature.wide.coverage.that.evenly.distributes.high.
fidelity.audio.to.fill.large.and.small.spaces..All.models.are.ideal.for.broadcasting.announcements.
and.music.reproduction.in.commercial.and.residential.applications..
The. CSP-series. ceiling. speakers. have. a. multi-tap. transformer,. which. allows. flexibility. in.
configuring.multiple.speakers.of.a.high-impedance.system..It.is.easily.accessed.with.the.multi-
tap. selector. on. the. front. baffle. of. the. speaker.. Low. frequencies. are. enhanced. with. a. vented.
port,. and. precise. and. smooth. high. frequencies. are. delivered. by. the. coaxially. mounted. 3/4".
titanium-coated.tweeter...The.sealed.backcan.enhances.overall.fidelity.by.focusing.the.sound.
and.preventing.the.distribution.of.sound.into.the.surrounding.ceiling.structure...
Removable.locking.connectors.simplify.the.process.of.wiring.the.speakers..Each.speaker.comes.
with. the. mounting. brackets. and. hardware. necessary. for. installation.. The. attachment. screw.
system.makes.installation.simple.while.providing.a.secure.mounting.connection.to.most.ceiling.
types.. Secondary. support. tabs. ensure. extra. security. for. compliance. with. building. codes.. The.
speakers.can.be.painted.to.match.ceiling.décor.
CSP-162
The. CSP-162. is. a. powerful. 150-watt,. low-distortion. ceiling. speaker. with. a. built-in. multi-tap.
transformer. with. maximum. power. of. 60W.. It. features. a. 6.5-inch. woofer. and. 3/4". titanium-
coated.tweeter..
CSP-142
The. CSP. 142. is. a. compact. 80-watt. ceiling. speaker. with. a. built-in. multi-tap. transformer. with.
a. maximum. power. of. 30W.. It. features. a. 4-inch. woofer. and. 3/4". titanium-coated. tweeter..
Low. clearance. of. 6.25". (15.9. cm). makes. it. possible. to. install. this. speaker. into. smaller. ceiling.
spaces.
USER'S GUIDE

Table of Contents:

Introduction.. . ............................................ 1
Overview....................................................2
Precautions. . ..............................................2
Setting.Up. . ............................................... 3
Preparing.the.ceiling. . ........................... 3
.....Drop.Ceilings..................................... 3
.....Fixed.Ceilings.................................... 3
Wiring.Schemes. . .................................... 4
wiring.to.the.speaker............................4
the.ceiling..................................................5
Attaching.the.Grille............................... 5
Painting. . .................................................... 5
.....Preparing.............................................5
.....Painting.the.rim................................5
.....Painting.the.grille.............................5
Specifications.......................................... 6
Frequency.Response............................ 6
Troubleshooting. . .....................................7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSP-142 and is the answer not in the manual?

Questions and answers

Related Manuals for Senal CSP-142

Summary of Contents for Senal CSP-142

  • Page 1 USER’S GUIDE CSP-SERIES Thank you for choosing Senal. Table of Contents: Introduction..........1 The. CSP-series. speakers. are. passive. coaxial. two-way. speakers. that. provide. premium. sound. quality.for.use.with.70V.or.100V.systems.and.for.low-ohm.systems. Overview............2 Precautions..........2 These.high.power.-.low.distortion.speakers.feature.wide.coverage.that.evenly.distributes.high. fidelity.audio.to.fill.large.and.small.spaces..All.models.are.ideal.for.broadcasting.announcements. Setting.Up..........3 and.music.reproduction.in.commercial.and.residential.applications.. Preparing.the.ceiling......3 The.

  • Page 2: Overview

    CSP-142 Woofer Tweeter Multi-tap.selector Attachment.screws Vented.port Removable.locking.connector Secondary.support.tab Mounting.tabs 10. Connecter.cover.plate.(CSP-162) Cover.plate.door.(CSP-162) 12. Adjustable.strain-relief.fitting.. (CSP-162) 13. Removable.cover.(CSP-142) 14. Knockout.(CSP-142) 15. (2).Screws.(CSP-142) 16. Perforated.grille 17. Rails 18. C-Ring 19. C-Ring.slots 20. C-Rings.adjuster.nuts.and.bolts. 21. Grille.removal.key 22. Cutout.template Precautions ▪ Please.read.and.follow.these. instructions,.and.keep.this. manual.in.a.safe.place.

  • Page 3: Setting.up

    6..Place.the.rails.on.either.side.of.the.hole.so.that.the.inverted.“V”. socket ends.of.the.rails.fit.over.the.ceiling.grid.rails..The.flat.side.of.the. rails.should.rest.on.the.tile,.and.the.side.with.the.pre-cut.holes. 3..Strip.approximately.1/4".(6.mm).off.the. should.stand.perpendicular.on.either.edge.of.the.hole. ends.of.the.insulation.on.the.speaker. wires. Note: The.rails.of.the.mounting.bracket.do.not.attach.to.the. ceiling.grid.rails,.but.suspend.over.them. 4..Insert.the.exposed.ends.of.the.wires. into.the.connector.and.tighten.the. 7..Insert.the.C-ring.by.angling. screw-down.terminals.using.a.small.flat.blade. it.through.the.hole.using. screwdriver. the.open.end.of.the.ring. CSP-142 1..Remove.the.cover.by.unscrewing.the.two. screws.attaching.it.to.the.backcan. 1.1..Determine.the.angle.your.speaker. wires.approach.the.speaker.and. remove.the.appropriate.knockout. 1.2. .Feed.the.wires.through.the. knockout. 2..Remove.the.locking.connector.from.the. socket 3..Strip.approximately.1/4".(6.mm).off.the. ends.of.the.insulation.on.the.speaker. wires. 4..Insert.the.exposed.ends.of.the.wires.into. Inside-ceiling view the.connector.and.tighten.the.screw- of assembled rails and C-ring.

  • Page 4: Wiring.schemes

    &.4.“-“..When.one.speaker.is.disconnected,.all.successive.speakers. and.are.securely.clamped,.close.the. are.disconnected.too..This.scheme.can.be.advantageous.when.using. cover.plate.door.and.secure.it.by. larger.gauge.wiring,.and.when.required.by.local.building.code..An. tightening.the.screw.with.a.Phillips. FROM AMPLIFIER OR TO NEXT entire.section.of.speakers.can.be.isolated.while.not.affecting.the. head.screwdriver. PREVIOUS SPEAKER – SPEAKER – wiring. CSP-142 1..Plug.the.removable.locking.connector.with.the.connected. speaker.wires.into.the.connector.socket.in.the.speaker.. Warning:.DO.NOT.FORCE.THE.CONNECTOR.INTO.THE.SOCKET. FROM AMPLIFIER OR TO NEXT PREVIOUS SPEAKER – SPEAKER – 2..Replace.the.cover.by.replacing.the.two.screws.attaching.it.to.the. backcan. Important:.Make.sure.all.wiring.conforms.to.local.building.codes. TO SUBSEQUENT SPEAKERS –...

  • Page 5: The.ceiling

    Installing the speaker into the ceiling Attaching the Grille Before.installing.the.speaker.into.the.ceiling,. 1..Place.the.grille.over.the.speaker.baffle. it.is.recommended.to.attach.a.safety.line. to.the.secondary.support.tab..Consult. 2..Press.the.edge.of.the.grille.into.place. local.codes.for.more.information. until.it.is.level.with.the.rim. about.secondary.support. requirements. Note:.Pressing.on.the.center.can.dent. 1..Remove.the.grille.by.inserting.the. the.grille. included.grille.removal.key.in.any. hole.at.the.edge.of.the.grille.and.pull. Caution:.Make.sure.the.grill.is.firmly.seated.into.the.speaker.to. out.to.lift.the.grille.. prevent.it.from.vibrating.or.falling. 2..Insert.the.speaker.into.the.ceiling.until. the.rim.is.flush.with.the.ceiling..Make.sure.to. Painting tuck.any.excess.wire.into.the.ceiling.behind.the. speaker. Preparing 3..While.supporting.the.speaker.from.below,. use.a.Phillips.head.screwdriver.to.tighten.the. Remove.the.grille.by.inserting.the.included.grille.removal.key.in. mounting.tabs.by.turning.the.attachment. any.hole.at.the.edge.of.the.grille.and.pull.out.to.lift.the.grille..Clean. screws.CLOCKWISE.. off.any.oily.residue.by.rubbing.the.surfaces.with.a.cloth.dampened. Note:.The.first.quarter.rotation.turns.the. with.a.mild.solvent.(like.mineral.spirits).and.wait.until.dry..Do.not.

  • Page 6: Specifications

    Specifications CSP-142 CSP-162 Height: 6.25".(15.9.cm) 7.5".(20.cm) Width: 7".(17.8.cm) 8.7".(22.cm) Width w/ rim: . 8.5".(21.6.cm) 9.7".(24.6.cm) Weight: 4.95.lb..(2.25.kg) 7.85.lb..(3.56.kg) Frequency Response: 80.Hz.to.20.kHz 75.Hz.to.20.kHz Power capacity: 80.Watts 150.Watts Max SPL: 85dB.SPL,.1W.@.1m 90dB.SPL,.1W.@.1m Transformer Tap: 70V:.30W,.15W,.7.5W,.3.7W 70V:.60W,.30W,.15W,.7.5W 100V:.30W,.15W,.7.5W 100V:.60W,.30W,.15W 16.Ohms.transformer.bypass 16.Ohms.transformer.bypass Low frequency driver: 4".(10.2.cm)

  • Page 7: Troubleshooting

    Make.sure.the.nuts.and.bolts.of.the.C-ring.slots.have.been.sufficiently.tightened. (refer.to.instructions.in.Installing the speaker into the ceiling.section.on.page.5). Ceiling.tile Place.dampening.material.under.the.ceiling.grid.rail.of.the.drop.ceiling.or.along.the. edge.of.the.ceiling.tile. Three-Year Limited Warranty This.SENAL.product.is.warranted.to.the.original.purchaser.to.be.free.from.defects.in.materials.and.workmanship.under.normal.consumer.use.for. a.period.of.three.(3).years.from.the.original.purchase.date.or.thirty.(30).days.after.replacement,.whichever.occurs.later..The.warranty.provider’s. responsibility. with. respect. to. this. limited. warranty. shall. be. limited. solely. to. repair. or. replacement,. at. the. provider’s. discretion,. of. any. product. that.fails.during.normal.use.of.this.product.in.its.intended.manner.and.in.its.intended.environment..Inoperability.of.the.product.or.part(s).shall.be. determined.by.the.warranty.provider..If.the.product.has.been.discontinued,.the.warranty.provider.reserves.the.right.to.replace.it.with.a.model.of. equivalent.quality.and.function.
  • Page 8 www.senalsound.com...

This manual is also suitable for:

Csp-162
