SERVICE MANUAL
STEREO CAR
CD CHANGER SYSTEM
• This Service Manual contains the additional information "NOTE ON BEFORE
SERVICING" and "TEST MODE" for the model ADC-M65 (YU).
If requiring the other information, see Service Manual of ADC-M65 (YU),
(S/M Code No. 09-001-404-5R4).
ADC-M65
BASIC CD MECHANISM : 8ZG-3 RNF
S/M Code No. 09-003-404-5S1
YU
ADC-M65

Advertisement

loading

Related Manuals for Aiwa ADC-M65

Summary of Contents for Aiwa ADC-M65

  • Page 1 CD CHANGER SYSTEM • This Service Manual contains the additional information “NOTE ON BEFORE SERVICING” and “TEST MODE” for the model ADC-M65 (YU). If requiring the other information, see Service Manual of ADC-M65 (YU), (S/M Code No. 09-001-404-5R4). S/M Code No. 09-003-404-5S1...
  • Page 2 NOTE ON BEFORE SERVICING How to Use the Repair Jig Use the following repair jig kit for servicing Part name Part code P.W.B. FLEX For 6 CD JIG-ADC-M60 SV-J00-089-010 P.W.B. JIG The kit contains the following parts (Refer to Fig-1): TRANSISTOR FFC (26P/25 cm) 1 pcs...
  • Page 3 Perform wirings to the C.Bs. Refer to Fig-5/-6. • Be sure to connect the wires coming from the P.W.B. JIG to the same connecting points on the MAIN C.B as follows. Connect the motor wires and sensor (PD201) wires that are removed in step (2) to the P.W.B. JIG.
  • Page 4 Fig-8 Fig-7 Fig-9 Connect wire for +12 V power to BACK UP of ICP601 by soldering. Connect ICP601 and ACC pattern land by soldering a wire. Connect GND by soldering a wire. Connect the +12 V power to the ACC/BACK UP wire and connect ground (-) to the GROUND wire of the connector. (Wires to be used for connection are not supplied.) 3) Perform the operation check.

  • Page 5: Test Mode

    TEST MODE There are two methods to perform operation check using test mode. One method uses the head unit. The other method uses the repair jig. Because different operation buttons must be used for entering the operation modes and there are cases that the set does not run at all in the method that uses the head unit, the method using the repair jig is described as follows.
  • Page 6 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9301978 Printed in Singapore...
