Valco baby ZEPHYR Product Reference Manual page 3

Remove mattress
Turn over
Folded frame Mattress
FIGURE F
D
4. Unfold mattress and place inside Zephyr. Be sure
that the mattress if fully extned with and that
there are no gaps betweeen the mattress and the
Zephyr sides.
FIGURE G - FOLDING THE ZEPHYR
5. Remove the mattress.
6. Turn Zephyr over
7. Grasp each leg and lift it free from the housing
lock.
NOTE: YOU MAY FIND IT EASIER TO LIFT THE LEG IF YOU
HOLD THE ZEPHYR FRAME DOWN WITH YOUR FOOT.
8. Fold each leg down and across toward the centre
E
of the frame.
9. Repeat for all legs
FIGURE H
10. Fold the Zephyr frame in half.
11. Slide the Zephyr frame into the mattress
12. Place inside carry bag.
Lift &
fold
FIGURE I - CLEANING THE ZEPHYR
13. The fabric of the Zephyr is fully removable for
washing. Simply locate the zipper under the top
F padding on each side, unzip and remove the
fabric. See care instructions for washing detail.
Once cleaned, reverse the procedure to replace
the fabric.
14. The mattress cover is fully removable and
washable.
CARE INSTRUCTIONS:
30
Carry bag
G
Hand wash only. Close zippers befor
washing Warm rinse. Dry in shade. Wash
dark colours seperately.
Warm iron.
Do not bleach.
Do not dry clean.
Do not tumble dry.
