Summary of Contents for StarLogic 62903108
- Page 1 7” Digital Photo Frame Item Number: 62903108 User Manual * Important Notice: Please read this manual carefully All brand names and trademarks are the property of their respective owners...
- Page 2 FCC Norm This equipment has been tested and complies with limits for Class B digital devices pursuant to Part 15 of Federal Communications Commission (FCC) rules. FCC Compliance Statement These limits are designed to provide reasonable protection against frequency interference in residential installations.
-
Page 3: Table Of Contents
Contents Precautions............................4 Overview ............................5 Quick Start Guide ..........................5 Attaching the Easel Stand to the Digital Photo Frame ..............6 Package Contents ........................... 7 7” Digital Photo Frame........................7 Installation and Setup of Accessories ..................8-9 Menu Control Buttons........................9 Remote Control Layout......................... -
Page 4: Precautions
Precautions 1. Read all of these instructions and save this manual for later use. 2. Follow all warnings and instructions on the product. 3. Do not insert sharp objects or spill liquid into the digital photo frame through the cabinet slots; this may cause accidental fire, electric shock or failure. -
Page 5: Overview
Overview • The 7” Digital Photo Frame enables you to view digital photos from different types of memory cards simply and quickly. There’s no need to use a computer or a printer. You can enjoy your photos anytime and anywhere. It’s very convenient and quick. •... -
Page 6: Attaching The Easel Stand To The Digital Photo Frame
Attaching the Easel Stand to the Digital Photo Frame Clear a flat clean area to set your photo frame down upon in order to attach the easel stand to the back of the frame. Make sure there are no sharp objects in the area that can make contact with the LCD screen of the photo frame that may cause damage to the screen. -
Page 7: Package Contents
Package Contents 7” Digital Photo Frame 8 in 1 Card Reader Power Adapter User’s Manual Remote Control Earphone Cable USB Cable Easel Stand with Knob Audio Cable 7” Digital Photo Frame LCD Screen Remote Control Receiver Clear Acrylic Frame... -
Page 8: Installation And Setup Of Accessories
Installation and Setup of Accessories Carefully position your Digital Photo Frame so that you can see all of the connection ports on the side of the frame. Plug the DC power adapter cable into the DC + 12V input and plug the AC end of the adapter into a normal AC outlet. -
Page 9: Menu Control Buttons
7. In order to operate the photo frame viewer you may now slide the power on/off switch to the ON position. Menu Control Buttons Symbol Function Power Indicator Menu Press to access the main menu. Return Play/Pause Press to play or pause the media. Down/Next Press to navigate down or to view the next photo. -
Page 10: Remote Control Layout
Remote Control Layout 1. MUTE: Mutes the volume. 2. RETURN: Returns to the OSD main menu. 3. STOP: Stops the selected file or action. 4. POWER: Turns the unit on or off. 5. PHOTO: Goes to the Photo Setup and displays the photo files. 6. -
Page 11: On Screen Display (Osd) Setup Menu
On Screen Display (OSD) Setup Menu Setup Menu page Setup mode selected Current Setup mode 1. Turn on the Digital Photo Frame and press the “MENU” button on the remote or “ ” on the Digital Photo Frame to display the OSD menu. 2. - Page 12 MOVIE SETUP Repeat Mode: Movie Setup: Allows you to select Allows you to if the movie file(s) select how your selected will play movie files will repeatedly or one play. time only. Digest Style: Allows you to select how many movie thumbnails will appear on the screen.
- Page 13 PREFERENCES SETUP Preferences TV Type: Setup: When sending the Allows you to A/V signal to a TV select your you must select preferences on the matching TV the screen. tuner system. TV Display: Video Output: When sending When sending the the A/V signal to a A/V signal to a TV TV you must...
-
Page 14: Operating Your Digital Photo Frame With The Remote Control
Operating your Digital Photo Frame with the Remote Control Note: The following menu will only appear on the screen as long as the memory card contains MP3 and/or MPEG files. PHOTO PHOTO • Press the PHOTO button on the remote control to access the Thumbnail Preview of the pictures you have saved on the memory card. - Page 15 PREV / NEXT • When viewing the photo in full screen display, press the PREV button and it will display the last picture viewed. Press the NEXT button to display the next picture on the memory card. SLOW • Press the SLOW button on the remote and you can select the time duration that each picture will remain on the screen by choosing 1, 3, 5 or 10 seconds before the picture changes to the next image.
- Page 16 MOVIE/VIDEO MOVIE/VIDEO • Press the MOVIE button on the remote control and the Movie Thumbnails will appear on the screen allowing you to choose the video you would like to watch by pressing the ARROW keys to select the file and then pressing the ENTER key.
-
Page 17: Specifications
Specifications LCD Panel Type 7.0” TFT LCD Display Viewing Angle H: 80° , V: 70° Contrast Ratio 250 : 1 Brightness 300 cd/m2 Response Time 16 ms Max Resolution 1440X234 (Analog) Aspect Ratio 16: 9 Frame Acrylic Material Supported Formats Type JPEG, AVI (motion –... -
Page 18: Troubleshooting
Troubleshooting (FAQ) 1. Q: What type of file formats does the DPF support? A: It supports JPEG, AVI (motion – JPEG), MP3, MPEG1, MPEG2, MPEG4. 2. Q: Why are some of my photos not able to be displayed on the viewer? A: Most digital cameras take and save the photos in a JPEG format which allows the digital photo frame to display the photos. -
Page 19: Maintenance
Maintenance To clean your digital photo frame, please refer to the instructions below: NOTE: To prevent electrical shock, do not open the Digital Photo Frame casing. Leave repair of the frame to qualified personnel, please see the tech support information in the warranty. 1. -
Page 20: Service Procedure
Service Procedure For technical support after the first 14 days of purchase, please call the toll free number below to obtain service. A customer service representative will assist you and provide a return authorization number (RA number) if needed allowing you to ship your product to the service center. DO NOT RETURN THIS PRODUCT TO THE STORE. -
Page 21: Warranty
Warranty 90 Days Limited Warranty This product is warranted to be free from defects in material and workmanship for a period of 90 days. Warranty obligations are limited to replacement or repair of defective parts and components, at the option of the manufacturer.
