- Page 1 Windows Touch Pen User Manual...
- Page 2 Xcellon Windows Touch Pens WTP-10 WTP-20...
- Page 3 Designed for the Windows 8 Start screen, the pen is also compatible with the Windows desktop on Windows XP, 7, and 8 operating systems. The WTP-10 kit is designed for screen sizes 9ʺ to 17ʺ and the WPT-20 is designed for screen sizes 9ʺ...
- Page 4 Precautions Please read and follow these instructions and keep this manual in a safe place. ■ ■ Keep this product away from water and any flammable gases or liquids. ■ ■ Clean this product with only a soft, dry cloth. ■...
-
Page 5: Specifications
■ ■ System requirements: ■ ■ Windows XP/7/8 ■ ❏ One free USB port ■ ❏ 9" to 17" monitor (WTP-10) ■ ❏ 9" to 27" monitor (WTP-20) ■ ❏ Power Source: Two SR41 batteries ■ ■ Batterylife: 50 hr. - Page 6 Contents Include Windows Touch Pen ■ ■ IR receiver ■ ■ Metal strip (WPT-10) ■ ■ USB Standard-A male to Mini-B male cable (WTP-10) ■ ■ Metal bracket (WPT-20) ■ ■ Extra brush ■ ■ Two (2) SR41 batteries ■ ■...
-
Page 7: Before You Start
Before You Start Installing Batteries The Windows Touch Pen runs on two SR41 batteries. To install the batteries, follow these steps: Unscrew the rear cap. If necessary, remove the old batteries by holding the pen upside down and gently manipulating the metal tab. Insert fresh batteries with the positive terminal facing up. -
Page 8: Installing The Ir Receiver
If necessary, remove the pen cap. Remove the original brush by gently pulling on the metal ring connected to the bristles. Insert the replacement brush until it is fully installed. Be careful not to damage the bristles. Installing the IR Receiver The touch system works with an IR receiver and a metal bracket or strip that mount to your monitor’... - Page 9 Mount the IR receiver to the metal strip. The receded magnetic area of the WTP-10 receiver should fit perfectly over the strip and lock into place. Make sure the IR receiver is facing the proper direction. The USB cable should be pointing away from the screen, and the IR sensor should be facing the screen perpendicularly.
- Page 10 WTP-20 Remove the backing from the adhesive strip on the metal bracket. Mount the metal bracket halfway down the left side of your monitor’ s bezel. The bracket should be perpendicular to the monitor. Press firmly so the bracket stays in place. Mount the IR receiver to the metal bracket or strip.
-
Page 11: Calibrating The Screen
Calibrating the Screen Before you use the Windows Touch Pen, you will need to calibrate the screen in order to ensure the pen’ s accuracy. You can do this two ways—via the included software or via your computer’ s Control Panel. When calibrating, make sure to hold the pen as you would during normal use. - Page 12 Insert the included calibration software CD into your computer’ s media drive and install the software. Use your mouse to right-click on the software’ s icon in your taskbar and select “Calibrate. ” Use the Windows Touch Pen to touch and hold on the center of each of the four red circles as they appear consecutively in the corners of the screen.
- Page 13 Control Panel Calibration Use your mouse to go to Control Panel/Tablet PC Settings. Make sure the IR receiver is plugged into your computer’ s USB port, or Tablet PC settings will not appear in your computer’ s Control Panel. Click on the “Other” tab and select “Go to Pen and Touch. ” This will open the Pen and Touch window. In the Pen and Touch window, select the “Flicks”...
- Page 14 In the “Calibrate pen or touch input screens” window, select “Touch Input. ” If asked whether you want to allow the following program to make changes to this computer, select “Yes. ” Follow the onscreen instructions to calibrate your Windows Touch Pen. If you have calibrated the screen and the pen is not accurate, recalibrate the screen until you have achieved satisfactory results.
-
Page 15: Using The Pen
Using the Pen Start Screen Because the Windows Touch Pen turns your monitor into a virtual touch screen, it gives you access to the Windows 8 Start screen’ s integrated touch features. - Page 16 Feature Instructions Select a tile Tap a tile to select or open it. Move a tile Touch and hold a tile and then drag it across the screen to move it. Browse tiles Swipe the pen horizontally across the Start screen in the direction you want to browse. Charms bar To open the Charms bar, swipe the pen from the right edge of the screen to the left.
- Page 17 Desktop You can use the Windows Touch Pen like a conventional mouse on your Windows desktop. This is compatible with Windows XP, 7, and 8 operating systems. Feature Instructions Click/double click Tap once or twice on an object or icon by tapping the screen. This works just like left-clicking with a conventional computer-mouse.
-
Page 18: Troubleshooting
Troubleshooting Problem Solution The pen is not working. Make sure the IR receiver is plugged into your computer' s USB port. • Make sure there are fresh batteries installed in the pen. • Calibrate the screen. • Replace the brush tip in the pen. •... - Page 19 Problem Solution The pen is not working properly after • Replace the batteries in the pen. calibration. • Replace the brush tip in the pen. • Recalibrate the screen. If you used the included software to calibrate, try calibrating via the Control Panel or vice versa. The touch point is lagging behind Deselect the option "Use flicks to perform common actions quickly and easily"...
-
Page 20: One-Year Limited Warranty
To obtain warranty coverage, contact the Xcellon Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Xcellon along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
