INSTALLATION AND OPERATING INSTRUCTIONS
TUFF CHARBROILER
INTENDED FOR OTHER THAN HOUSEHOLD USE
RETAIN THIS MANUAL FOR FUTURE REFERENCE BROILER
MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES

IMPORTANT INSTRUCTIONS

After the gas supply has been connected to your unit, it is extremely important to check piping for possible leaks.
To do this, use soap and water solution or solutions which are expressly made for this purpose. DO NOT USE
matches, candles, flames, or other sources of ignition since these methods are extremely dangerous. Post in a
prominent location instructions to be followed in the event you smell gas. Obtain these instructions from your
local gas supplier.
This equipment has been engineered to provide you with year round dependable service when used according
to the instructions in this manual and standard commercial kitchen practices.
