Reely REX-X PROMO II Service Manual page 6

10
10B
10B
MV162
Step 1
10A -- TP F/H Screw 4 x 16 mm -- 2
Step 2
10B -- TP Screw 4 x 18 mm -- 2
11
MV162U2
10A
MV162
MV162D1
MV162U3
11A
MV110
12B
12D
11A -- TP Screw 3 x 18 mm -- 1
12A
MV110
MV142
12
12A
12A -- Cap Screw 3 x 25 mm -- 2
MV1331T
12B -- TP Screw 3 x 12 mm -- 2
MV142
12C -- Lock Nut 3 mm -- 1
12C
12D -- Screw 3 x 15 mm -- 1
Step 11
13
MV141
13A
MV141 / MV308
MV141
MV141
13A -- Screw 3 x 15 mm -- 4
MV308
MV141
MV308 -- 6 x 32 mm -- 2 MV141
1 3A
6
