Summary of Contents for Innovative Technology ITKC-500

  • Page 2 FCC WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance will void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3 1.Product Introduction DPFMate is specifically designed PC software for small screened digital photo frames. Download pictures from your PC into a variety of digital photo frames. Features: Language (English) Picture preview Zoom In/Out, Crop, Rotate Single, Sequence, Delete Read and save pictures Function Keys/Buttons 1.
  • Page 4 5 OFF/ON: to turn off/on the device power. If OFF, to press MENU can not turn on the device. Functional Specification 1.5” CSTN Resolution 128x128 dots, 65K colors Internal Memory 8MB Flash Memory Capacity >50pcs photos Display Modes Single/Slide mode Operation Modes Calendar and Clock display File formats...
  • Page 5 3. Transfering pictures to the digital keychain photo frame. 3.1 Connecting Terminal Connect the keychain photo frame to the computer using the included USB cord. Once connected, the DPFMate will automatically start up. If connected correctly, the DPFMate will automatically load all the pictures that are saved in the keychain photo frame.
  • Page 6 Specific steps as shown in ‘Picture 3’: Picture 3 CAUTION: While donwloading pictures, if the USB cable is disconnected all pictures selected will be lost. Please be sure not to disconnect the keychain photo frame from the computer while downloading pictures. Other Functions 4.1 ZOOM Preview Image 1.
  • Page 7 4.3 Crop Preview Picture or Auto Resize Picture There are pictures that DPF Mate can be used with the “Crop Frame” to crop. The “Clear” button erases the selected rectangle on the displayed picture, as shown Picture 4 below. Picture 4 Click on “Clear”...
  • Page 8 picture (See Picture 4). Users can click on “Add” button so that the cropped or resized picture that is displayed will be added into “DPF Pictures Zone” on the right hand side of the screen can be saved in to the keychain digital photo frame. 4.4 Deleting Pictures from the DPF Picture Zone (edited or cropped pictures) Select one picture or several pictures then click on the “Delete”...
  • Page 9 4.5 Changing the Menu Color The DFFMate “Setting” dialog box let’s you set the DPF front color and background color, as shown in Picture 7. After changing the settings, you can see the results in the DPF menu interface. Picture 7 Keychain Digital Photo Frame Function Introduction There are three buttons on the side of the keychain digital photo frame.
  • Page 10 Main Menu USB Connect Slide Show AUTO Off LCD Contrast Backlight Display Clock Set Clock Delete One Delete All Exit The “USB Connect” function charges and downloads pictures from the PC. II. Setting the display time and selecting the “Slide Show” function. Main Menu USB Connect Slide Show...
  • Page 11 Slide Show Press the UP key or DOWN key to set the time. To finish this action, press the MENU key to confirm and exit. When the time value is zero minutes, the slide show function will be off. Pictures will have to be switched manually with the UP and Down buttons.
  • Page 12 press the MENU key to confirm and exit. When the time value is zero minutes, the unit must be turned off manually by keeping the MENU button down for a few seconds. IV. Setting the screen contrast, LCD Contrast”. ¡ Main Menu USB Connect Slide Show...
  • Page 13 Main Menu USB Connect Slide Show AUTO Off LCD Contrast Backlight Display Clock Set Clock Delete One Delete All Exit Press the MENU key to get into the submenu. Backlight Press the UP key or DOWN key to set the backlight value. To complete this action, press the MENU key to confirm and exit.
  • Page 14 VII. Set Clock Once the USB is connected, the keychain digital photo frame can update ¢ using the PC time when download pictures. Set Clock”. Set Clock, select £ £ £ £ Main Menu USB Connect Slide Show AUTO Off LCD Contrast Backlight Display Clock...
  • Page 15 One” function may delete the wrong picture. You may want to first disable the auto display mode and then choose the picture to be deleted. IX. Deleting ALL pictures. Select the seventh item “Delete All”, this will delete all the pictures in the keychain digital photo frame. If you are sure this is the action you would like to take, press the MENU.
  • Page 16 To select “Exit”, press the MENU key to exit the main menu and go back to displaying pictures. Press and hold the MENU key to turn on/off. Note: Connect the USB cable to the keychain digital photo frame to a PC to charge. Once finished charging, the battery gauge will show full.
  • Page 17 Important Safety Instructions CAUTION: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. WARNING: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure. 1.
  • Page 18 has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for the replacement of the obsolete outlet.
  • Page 19: Warranty

    Limited Warranty 90 Days Labor, One Year Parts Innovative Technology Electronics Corp. (IT) warrants the product to be free from “Defects” in materials under normal use for a period of “One Year” from the date of the original purchase. The Warranty is “Not” transferable IT agrees, within the initial “90 Day ”period, to repair the product if it is determined to be defective at “No Charge”.
  • Page 20 Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above exclusions or limitations may not apply to you. This warranty gives you specific legal rights and you may also have other rights, which vary from state to state.
