Page 1 IB2S-A User Guide Series Advanced Transmission Line...
Page 3 IMPORTANT Warranty Certificate Please take a few moments to complete the warranty card at the back of this booklet (or register at www.pmc-speakers.com) as this not only records the purchase of your loudspeakers, but also provides you with an opportunity to make suggestions and provide feedback directly to PMC.
Page 4 A message from Peter Thomas – arguably the world’s smartest loudspeaker designer and a truly obsessive audiophile. “ Peter Thomas Owner & Chief Designer Our sole aim while designing loudspeakers is to recreate the true essence of an artist’s intention, combining the ultimate level of sonic resolution with solid engineering principles. We believe that the same loudspeaker can be used throughout the entire audio chain, from composer to studio or film stage, post-production or mastering and then, finally, the consumer.
Page 5 Congratulations - You have joined the elite. PMC: the authority for quality sound. Prince Over two decades PMC has earned an UNIVERSAL MUSIC GROUP unrivalled reputation for creating the world’s finest professional loudspeakers. Robbie Williams Stevie Wonder Simply put, our loudspeakers provide a reference for the world’s highest profile Royal College of Music Francis Rossi (Status Quo)
Page 6: Table Of Contents
IB2S-A User Guide Series Contents General Usage Guidelines Introduction Unpacking and Care PMC’s – How the Advanced Transmission Line Works Advanced Transmission Line System Description User EQ Options Connections Running In Applications and Accessories Positioning Surround System Set-up Operational Controls...
Page 7: General Usage Guidelines
General Usage Guidelines Read these instructions and keep them in a safe place for future reference. Heed all electrical safety warnings, including any on the loudspeakers themselves. Do not use the loudspeakers near water. Do not install the loudspeakers near heat sources such as radiators, ovens or other very hot equipment, or in unventilated soffits or enclosures.
Page 8: Introduction
Introduction The IB2S-Active Series builds on PMC’s world-class monitor design pedigree, combining the finest drivers available with the unique (Advanced Transmission Line) bass loading principle, Advanced Transmission Line sophisticated Class-D amplification, and ultra-precise DSP control. The bass is loaded by PMC’s unique (Advanced Transmission Line) technology.
Page 9: Unpacking And Care
Unpacking and Care IB2S-Active Series monitors are packed in heavy-duty protective cartons. Please retain these to ensure that they can be transported safely if the need arises in the future. If you dispose of the packaging please do so in an environmentally responsible and safe way. Inside the packaging you will find: IB2S-ACTIVE IB2 XBDS-ACTIVE XBDS-ACTIVE...
Page 10: Advanced Transmission Line
An important benefit of the ATL approach ™ is that the air pressure inside the cabinet, loading the bass driver, is maintained.
Page 11: System Description
System Description The electronic heart of the IB2S-Active Series roll-off rates, optimising the contribution of is a powerful DSP stage which operates at a each driver, minimising distortion, and providing fixed sample rate of 192kHz. The balanced a flatter and more natural balance over the analogue line input level is conditioned by a widest possible listening area.
Page 12: User Eq Options
User EQ Options The IB2S-Active Series master cabinet remote control unit has facilities for five user-configurable equalisation presets, each of which can be named for easy recognition (eg. Frank, Geoff etc). These DSP-based user-equalisation options include LF and HF shelf responses, as shown in the graph above, each adjustable over a range of ±8dB in increments of less than 1dB, with fixed knee frequencies of 200Hz and 5kHz, respectively.
Page 13: Connections
Connections Caution To avoid potential damage, please ensure that the signal source is turned off before connecting or disconnecting your active loudspeakers. Connections The rear panel of the IB2S-Active Series carries various connectors for audio, control and mains power. Audio The electronically-balanced analogue audio input and the AES3 digital input accept 3-pin male XLR connectors, wired with Pin-1 screen (ground), Pin-2 signal positive (hot), and Pin-3 signal negative (cold).
Page 14: Running In
Running-In When brand new, PMC loudspeakers will take a short period of use before they reach their full potential. This is because the mechanical and acoustical characteristics of the bass, midrange and treble drive units alter slightly after manufacture as the flexible elements in their construction relax and reach their optimum compliancy.
Page 15: Applications And Accessories
Applications and Accessories Applications The large-scale performance of IB2S-Active Series monitors makes it appropriate wherever a clean, neutral and powerful presentation is required. Typically, IB2S-Active Series monitor loudspeakers are used for high-power midfield monitoring for music and speech recording and mixing, outside broadcast vehicles, radio on-air studios and television sound control galleries, home theatre and high-end domestic hi-fi, project music studios, post-production and editing suites, quality monitoring, music mastering, and A&R evaluations.
Page 16: Positioning
Positioning With their unique cabinet design, wide dispersion, ultra-low distortion, and smooth bass Advanced Transmission Line roll-off, PMC loudspeakers are more forgiving of difficult room conditions and placement constraints than conventional designs – you will be able to achieve a superb sound throughout the room with little effort.
Page 17 When initially positioning the loudspeakers, ideally they should be located at two of the three points of an equilateral triangle, with the listener at the third. If the monitors are spaced too far apart the stereo image will be wide but central definition will be impaired. Use a well recorded vocal track to judge the ideal placement.
Page 18 Positioning (Cont.) Speaker Orientation The IB2S-Active Series is designed to be used upright to ensure optimum stereo imaging, tonality and amplifier cooling. Around the crossover frequencies each adjacent pair of drive units are inherently reproducing the same audio signal (although PMC designs employ steep crossover filters which minimises this), and so there are inevitably two sources of sound.
Page 19 Bass Response IB2S-Active Series monitor loudspeakers can produce significant bass energy below the frequencies at which they become omnidirectional. As a consequence, it is important to consider the effect of the boundaries of the listening room when placing the monitors. The use of plinth modules can assist in fine tuning the in-room bass response.
Page 20 Fine tuning for perfect sound Surround Sound Systems 5.1 Systems The IB2S-Active Series monitor has been designed for perfect multi-channel music or movie playback. The following diagrams indicate the ideal speaker layouts. The constraints of room size and shape will often force some loudspeakers to be placed closer or further from the listening position than is ideal.
Page 21: Operational Controls
Operational Controls The IB2S-A Active Series monitor is configured and controlled via the supplied remote control panel which has an LCD display with two rows of up to 16 characters each, plus four push buttons and a rotary control. The top push button accesses the configuration menu, with a back button to exit.
Page 22 1.2 Trigger-ON When the 12V trigger mode is set to ON in the main menu (see 3.1.3) the default standby mode display will look like this (Note: Backlight will be off, and there is no sub-menu): Actions: Buttons: MENU: If held for more than two seconds the 12V Trigger Mode is set to OFF.
Page 23 Trigger: ON mode: shut down, and show trigger on standby mode (see 1.2). OFF mode: nothing. 3 Main Menu The main menu is shown when the MENU button is pressed in the default display, or when BACK is pressed in the setup menus. The sub-menu options which appear depend on the last shown main sub-menu (in this example power off): Sub-menus: Power off, Setup...
Page 24 12V Trigger Mode: enter 12V Trigger Mode menu (see 3.1.3). 1: Left Master: enter Channel Settings menu (see 3.1.4). 2: Left XBD: enter Channel Settings menu (see 3.1.4). 3: Right Master: enter Channel Settings menu (see 3.1.4). 4: Right XBD: enter Channel Settings menu (see 3.1.4). 5: Centre Master: enter Channel Settings menu (see 3.1.4).
Page 25 MUTE: a mute/un-mute command will be sent to all channels. The display backlight will flash once per second when muted. Clip: Nothing. Trigger: ON mode: system shuts down and display shows standby mode (see 1.2) Off mode: nothing. 3.1.2 Analogue Input Sensitivity Menu The analogue input sensitivity menu is shown when the SELECT button is pressed in the setup menu with analogue input sensitivity menu as active sub-menu.
Page 26 Sub-menus: Main Source Main Trim LFE Source LFE Trim Actions: Rotary: UP/DOWN: scrolls up/down through the sub-menu list. Buttons: MENU: nothing. BACK: the setup menu appears (see 3.1). PRESET: If pressed briefly the display shows the current preset for two seconds.
Page 27 menu appears (see 3.1.4). MUTE: a mute/un-mute command is sent to all channels. The display backlight flashes once per second when muted. Clip: Nothing. Trigger: ON mode: system shuts down and standby mode is displayed (see 1.2). OFF mode: nothing. 3.1.4.3 LFE Source Menu The LFE Source menu is shown when the SELECT button is pressed in the Channel Setting menu with LFE Source as active sub-menu.
Page 28 Sub-menus: Preset Setup, No Preset, Preset A* to Preset E*. Actions: Rotary: UP/DOWN: scrolls up/down through the sub-menu list. Buttons: MENU: nothing. BACK: the default display appears (see 2). PRESET: If pressed briefly the current preset is displayed for two seconds. If held for more than two seconds: nothing.
Page 29 If held for more than two seconds the preset menu appears (see 4). SELECT: depends on sub-menu. MUTE: a mute/un-mute command is sent to all channels. The display backlight flashed once per second when muted. Clip: Nothing. Trigger: ON mode: system shuts down and standby mode displayed (see 1.2). OFF mode: nothing.
Page 30 4.1.2.1 Front LF Shelf Menu The Front LF Shelf menu is shown when the SELECT button is pressed in the preset settings menu with Front LF Shelf as active sub-menu (in this example 1), along with the current value (in this example +1.00dB). There are no sub-menus.
Page 31 SELECT: saves value and sends to all channels. The preset settings menu appears (see 4.1.2). MUTE: a mute/un-mute command is sent to all channels. The display backlight flashes once per second when muted. Clip: Nothing. Trigger: ON mode: system shuts down and the standby mode is displayed (see 1.2). OFF mode: nothing.
Page 34: The Pmc Range
The PMC Range The PMC range of professional monitors currently spans 22 different models, from the enormous BB5 XBD-A flagship system down to the diminutive DB1 passive speaker. However, every monitor is designed with the same care and attention, using shared families of drive units, crossover designs and amplifiers.
Page 35: Service
Service We are confident that your IB2S-Active Series loudspeakers will afford many years of trouble-free listening of the highest order. However, in the unlikely event of requiring repair all replacement parts will exactly match the performance of those originally installed because we record the precise value of each component along with the system response as a whole for every loudspeaker we produce.
Page 36: Specifications
Specifications Usable Frequency Response 20Hz – 25kHz Maximum SPL 120dBA @1metre Effective 2.4m (8.0 feet) Advanced Transmission Line (Advanced Transmission Line length) Crossover 380Hz and 3.8kHz with 24dB per octave slopes Drive Unit Complement LF 254mm (10 inch) PMC-designed Carbon Fibre and Nomex Flat Piston MF 75mm (3 inch) Soft-dome PMC-designed midrange HF 34mm (1.25 inch) FerroFluid-cooled Soft...
Page 37 Main Source Selection Main analogue, Main AES3 (left), Main AES3 (right) All with ±8dB level trims. LFE Source Selection LFE analogue, LFE AES3 (left), LFE AES3 (right), All with ±8dB level trims Amplifier Section LF 800Wrms, MF 200Wrms, HF 200Wrms User Equalisation LF Shelf ±8dB, HF Shelf ±8dB Remote Control...
Page 38: Our Meticulous Care And Attention
Our Meticulous Care and Attention All PMC loudspeakers are hand-built in the U.K. using components that are individually matched to our reference model. This includes the structural integrity of every cabinet, and the testing and recording of each individual component to guarantee adherence to our strict tolerances. In this way we can ensure your purchase sounds identical to the original design.
Page 39: Warranty On-Line
Warranty On-Line SIMPLY ACTIVATE YOUR 5-YEAR WARRANTY ON-LINE GO TO WWW.PMC-SPEAKERS.COM AND CLICK ON REGISTER PRODUCT WARRANTY ON-LINE If you do not have access to the internet fill in the warranty form on pages 40 and 41, and post page 41 to us.
Page 40 WARRANTy CERTIFICATE - PART 1 your copy Please complete and retain this page for your own records Product Serial No’s Date of purchase Dealer’s name Dealer’s address Town County Postcode Dealer’s Telephone No. Servicing and warranty issues – Please read the following carefully. Non-UK clients Contact your local dealer/distributor for the details of warranty repairs –...
Page 41 WARRANTy CERTIFICATE - PART 2 PMC’s copy Please complete and return this section – or simply complete the on-line registration at www.pmc-speakers.com and click on ‘register product.’ Product Serial No’s Date of purchase Purchased from Your name Your email address Your address Town County...
Page 42: Help Us Improve: Your Comments
Help us Improve: Your Comments We value all of our clients’ comments. Please take a moment to help us improve: If there is one thing we should change, what would it be? Please tell us how your new PMC loudspeakers perform. Your comments may appear on the customer quotes section for this product on our website –...
Page 43: Inspection Certificate
Inspection Certificate Every component employed within a PMC product is measured, tested, matched and recorded by hand. This analysis also applies to the final product to ensure you receive an identical replica of the original reference model. Enclosure finish Assembly & Wiring Driver installation Enclosure seal Level –...
Page 44 The Professional Monitor Company Limited will not assume responsibility for errors that may appear in this document. Information may be subject to change. Document edited by Apple & Pear Productions Ltd. Job No. 206 IB2S-A manual.V2 - May 2012 Copyright ® 2012. All rights reserved.
