Summary of Contents for Valco baby Q SEAT
- Page 1 Q SEAT for Rebel Q Stroller PRODUCT REFERENCE GUIDE Important – Keep these instructions for future reference FURTHER INFORMATION: TESTED: Find us on: valcobaby.com.au AS/NZS 2088: 2013 EN:1888 © Copyright VE 2013 vs031013...
- Page 2 All pictures and diagrams herein are provided for illustration purposes only. Actual product, colour or fabric may vary. VALCO BABY reserves the right to modify or alter any specification or colour without notice or obligation to modify any product previously purchased...
- Page 3 OVERVIEW 20kg 44lb 300mm 11.8" 3.4kgs 600mm 7.7 lbs 23.6" PARTS HOOD HOOD LOCK BUMPER BAR SUPPORT HOOD CLIP SEAT LOCK BRACKET FOLD BUTTON SEAT BUMPER BAR HARNESS ANCHOR PIN HOUSING FASTENING ANCHOR POINT FOOT REST STRAP ANCHOR KNOB RELEASE BUTTON...
- Page 4 OPEN SEAT SEAT LOCK...
-
Page 5: Attach Seat
REmOVE STROLLER BUmPER BAR ATTACH SUPPORT BRACKET IMPORTANT: Secure, but do not tighten knob. Allow Support Bracket to slide on frame. ATTACH SEAT IMPORTANT: Rebel Q seat must face parent! CLICK... -
Page 6: Crotch Strap
SUPPORT BRACHET IMPORTANT: Slide Support Bracket to align seat Anchor Pin with Anchor Point on bracket, then tighten knob. CROTCH STRAP HOOD BUmPER BAR ‘CLICK’ ‘CLICK’... - Page 7 HARNESS ‘CLICK’...
-
Page 8: Care And Maintenance
WARNING: To AvoId INjuRy oR deATh ! WARNING: NeveR leAve youR chIld uNATTeNded. ! WARNING: ThIs ToddleR seAT uNIT Is NoT suITAble foR chIldReN uNdeR 6 moNThs. ! WARNING: AlWAys use The ResTRAINT sysTem. ! WARNING: ThIs pRoducT Is NoT suITAble foR RuNNING oR skATING ! WARNING: To AvoId INjuRy eNsuRe ThAT youR chIld Is kepT AWAy WheN uNfoldING ANd foldING ThIs pRoducT.
