Summary of Contents for iSolution IH9000-1
-
Page 1: User Guide
Technical Specifications Power AC 120V~60Hz or AC 230/240/250V 50/60Hz Fuse 20mm Glass T6.3A Fast Blow Lamp HTI 150W Dimension 373mm x 295mm x 451 mm Weight 13 kg IH9000-1 User Guide Professional Entertainment Technology Innovation , Quality , Performance... -
Page 2: Table Of Contents
5. How To Control The Unit & 5.1 Master/Slave Built-In Preprogrammed Function. Harmonized Standard 5.2 Easy Controller 5.3 iSolution Operation / Universal DMX Controller EN 60598-1: 2004 5.4 DMX512 Configuration IEC 60598-1:2003+ corrigendum 2004 5.5 DMX512 Connection Part 1:General requirements and test 6. -
Page 3: Safety Instruction
H. If The pan belt is broken 1. Safety Instruction 1. Turn off the main power. 2. Unscrew all the screws (A) and open the base-housing cover (B). Please read carefully the instruction, which includes important 3. Unplug all the connect wires (C) that from the arm to PC board and igniter. information about the installation, usage and maintenance. - Page 4 6. Troubleshooting Warning Following are a few common problems that may occur during operation. Here are ♦ To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or some suggestions for easy troubleshooting: moisture.
-
Page 5: Technical Specification
5.5 DMX512 Connection 2. Technical Specification The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. Power supply - AC 120V~60Hz Lamp - Discharge HTI 150W GY 9.5 Optical system - Standard 13° focused beam angle. Shutter/Dimmer - Blackout, 0~100 smooth dimming and strobe speed variable(1~10 flashes per second). -
Page 6: Inserting/Exchanging Rotating Gobos
2.1 Inserting/Exchanging rotating gobos 5.4 DMX512 Configuration DANGER! Install the gobos with the device switched off only. Unplug from mains before changing gobos! Open the cover by loosening the fastening screw at the sides of the cover. If you wish to use other forms and patterns as the standard-gobos, or if the gobos are to be exchanged, remove the fixation ring with an appropriate tool. -
Page 7: Lamp
(LED fast blinking) the eyes and skin. The high luminance of the arc can cause severe damage to the retina if looks directly at the lamp. 5.3.1 iSolution Operation Discharge lamp : HTI 150W ♦ Consistent DMX configuration enable iMove to be linked together with iRock and iShow 1. -
Page 8: How To Set The Unit
4. How To Set The Unit 5. How To Control The Unit You can operate the unit in three ways: 4.1 Control Panel 1. By master/slave built-in preprogram function 2. By easy controller 3. By iLead controller ( please refer to the user guide of iLead ) or by universal DMX controller No need to turn the unit off when you change the DMX address, as new DMX address setting will be effected at once. -
Page 9: Main Function 2
4.2 Main Function Display Inversion It is good for you to install the unit on the floor or under ceiling. Press the MENU button up to To select any of the pre-set functions, press the MENU button up to when the required one is shown on the display. - Page 10 Show Mode Color Mode Press the MENU button up to when the is showing on the display. Pressing ENTER Press the MENU button up to when the is showing on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to select the (show 1) or button and the display will blink.
