AXM-DC-HF
Universal hands-free/Bluetooth
FM modulator
• 4 FM frequencies to choose from
• Optional 3.5mm/RCA audio input
• 2.1-amp USB charging under-dash port
• RDS capable (must have AVRCP 3.1 or higher)
• Ability to answer or hang up a phone call
• Bluetooth range of approximately 30 meters
INTERFACE COMPONENTS
• AXM-DC-HF interface • AXM-DC-HF harness
• Circular on/off rocker switch • Hang-Up/Pick-Up switch
• Under-dash USB charging port
TOOLS REQUIRED
• Cutting tool • Crimping tool • Tape • Connectors
(example: butt-connectors, bell caps, etc.)
METRA. The World's best kits.™
Installation Instructions for AXM-DC-HF
FEATURES
1-800-221-0932
Caution: Metra recommends disconnecting the negative battery terminal before
beginning any installation. All accessories, switches, and especially air bag indicator
lights must be plugged in before reconnecting the battery or cycling the ignition.
*Note: Refer also to the instructions included with the aftermarket radio.
Connections to be made
From the 16-pin harness:
1. Connect the Red wire to 12-volt accessory power.
2. Connect the Black wire to chassis ground. Also ground the Black wire of the
Hang-Up/Pick-Up switch.
3. Connect the Green wire to the Pink wire of the Hang-Up/Pick-Up switch.
4. Connect the male antenna connector into the radio.
5. Connect the female antenna connector onto the antenna connector from the vehicle.
6. The Gray and White wires will be discussed later in the manual.
Note: Antenna adaptors may be required to connect the AXM-DC-HF
to the vehicle.
Rocker switch installation
1. Drill a 19/32 (15mm) hole in the desired location for the rocker switch.
2. Place the rocker switch into the drilled hole.
3. Connect the 2-pin plug from the rocker switch, to the 2-pin plug of the
AXM-DC-HF harness.
Pairing the AXM-DC-HF
1. Turn the vehicle on.
2. With your Bluetooth enabled cell phone, go into your Bluetooth settings and
search for a device.
3. After the search, "Axxess BT" will show up on your cell phone.
4. Select it and your phone will pair with the AXM-DC-HF.
5. Pairing is complete and you are now able to stream audio.
metraonline.com
(continued on next page)
