Before using your air conditioner, please read

this manual carefully and keep it for future reference.

INVERTER SPLIT-TYPE

ROOM AIR CONDITIONER

iQool9

iQool12

iQool18

iQool24

Read This Manual

Keep this manual where the operator can easily

find them.Inside you will find many helpful hints

on how to use and maintain your air conditioner

properly. Just a little preventative care on your

part can save you a great deal of time and money

over the life of your air conditioner. You'll find many

answers to common problems in the chart of

troubleshooting tips. If you review the chart of

Troubleshooting Tips first, you may not need

to call for service.

Table of Contents

Need help?

Do you have a question about the iQool9 and is the answer not in the manual?

Questions and answers

Summary of Contents for ElectiQ iQool9

Page 1 ROOM AIR CONDITIONER ROOM AIR CONDITIONER ROOM AIR CONDITIONER ROOM AIR CONDITIONER ROOM AIR CONDITIONER ROOM AIR CONDITIONER iQool9 iQool12 iQool18 iQool24 Read This Manual Keep this manual where the operator can easily find them.Inside you will find many helpful hints on how to use and maintain your air conditioner properly.
Page 2 READ BEFORE OPERATION When using this air conditioner in the European countries, the following informations must be followed: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 3: Table Of Contents
CONTENTS SAFETY PRECAUTIONS Warning .............................3 Caution ............................4 NAMES OF PARTS Indoor unit ..........................5 outdoor unit ..........................5 Display window ..........................5 OPERATING INSTRUCTIONS Operating temperature........................6 Manual operation ........................6 Airflow directional control ......................7 How the air conditioner works ....................8 Special functions ........................9 CARE AND MAINTENANCE Before maintenance..
Page 4: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury.
Page 5: Caution
SAFETY PRECAUTIONS CAUTION Never actuate any switches with a wet If the air conditioner is to be used in hand. It may cause an electric shock. conjunction with other heaters, the air Never use the device for any other should be refreshed periodically, otherwise purpose than the intended use.
Page 6: Names Of Parts Indoor Unit
NAMES OF PARTS Indoor unit Names of parts Air inlet Indoor unit 1. Front panel 2. Air inlet 3. Air filter 4. Air outlet Air outlet 5. Horizontal air flow grille 6. Vertical air flow louver(inside) 7. Display window Outdoor unit Outdoor unit 8.
Page 7: Operating Instructions
OPERATING INSTRUCTIONS NOTE: A guide on using the infrared remote is included in this literature package. Operating temperature Mode Cooling operation Heating operation Drying operation Temperature Room temperature 17 C~32 C 10 C~32 C 0 C~30 C (62 F~90 F) (50 F~90 F) (32 F~86 F) Outdoor temperature...
Page 8: Airflow Directional Control
OPERATING INSTRUCTIONS Airflow directional control Adjust the air flow direction properly, otherwise it might cause discomfort or cause uneven room temperatures. Adjust the horizontal louver using the remote controller. Adjust the vertical louver manually. Adjusting vertical air flow(Up--Down) Perform this function while the unit is in operation. Use the remote controller to adjust the vertical air flow Range direction.
Page 9: How The Air Conditioner Works
OPERATING INSTRUCTIONS How the air conditioner works Basic operation modes: AUTO/COOL/DRY/HEAT ) Model dependent SLEEP operation 7 hours timer off AUTO operation When you set the air conditioner in AUTO mode, it will automatically select cooling, heating(cooling/heating Temperature models only), or fan only operation depending on set temperature and the room temperature.
Page 10: Special Functions
OPERATING INSTRUCTIONS Special functions Refrigerant Leakage Detection Anto-restart function When refrigerant leakage is detected, In event of power interruption such as a the indoor unit will display EC code or blackout, the air conditioner stops once. flash LEDs(model dependent). But it restarts automatically and performs previous operation when the power supply Louver Angle Memory Function: is resumed.
Page 11 OPERATING INSTRUCTIONS Air Filter Reminding Function Cleaning filter reminding function: Mute operation After 240 hours of operation, the indoor Press the LED button on the remote display window will display and flash CL , controller can turn off the indoor screen this feature is a reminder to clean the Air display, and also turn off the Air Filter for more efficient operation.
Page 12: Care And Maintenance
CARE AND MAINTENANCE Care and Maintenance Before mainatenance Turn the system off before cleaning. To clean, wipe with a soft, dry cloth. Do not use bleach or abrasives. NOTE: Power supply must be disconnectd before attampting to clean or service! CAUTIONS Do not use a chemically treated cloth or duster to clean the unit.
Page 13: Preparation For Extended Non-Operation
CARE AND MAINTENANCE For the models adopts Plasma, do not touch the plasma within 10 minutes after you open the panel. Clean the Plasma according to the describtion in the figure left. 5. Refit the small air freshening filter onto the large Plasma air filter.
Page 14: Troubleshooting Tips
TROUBLESHOOTING TIPS Troubleshooting tips The following events may occur during normal operation, and may not indicate malfunction. Symptom Cause To prevent blowout of the fuse, the compressor will not operate while the Operation is delayed protection circuit is working for about 3 minutes after sudden OFF--ON after restart operation of the power supply.
Page 15: Troubleshooting Guide
TROUBLESHOOTING TIPS Troubleshooting guide Before you call for or request servicing, troubleshoot a problem by performing following checks: Symptom Diagnostic -- Is there a power failure? -- Has a switch been turned off, a circuit breaker tripped or a fuse blown? Unit will not operate -- Is the timer operating? -- Are the batteries used in the remote controller exhausted?
