GrandTec POE-5000 Quick Installation Manual

Introduction ...........................................................
Power Over Ethernet (PoE) & Features ......................
Unpacking and Installation ......... ..............................
System Requirement....... .......................................
Front Panel /LED.....................................................
Hardware Installation... ............. ...............................
Technical Speci cation..............................................
Troubleshooting .......................................................
FCC Warning:
This device has been tested and found to comply with the regulations for Class B digital equipment.
Pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with users guide, may cause harmful interference to radio communications. Operation of this device in
a residential area is likely to cause harmful interference, in which case the user will be required to
correct the interference at his/her own expense.
CE Mark Warning:
This is a Class B product. In a domestic environment, this product may cause radio interference, in which
case the user may be required to take adequate measures.
UL Warning:
1> Elevated Operating Ambient Temperature- If installed in a closed or multi-unit rack assembly, the
operating ambient temperature of the rack environment may be greater then room ambient. Therefore,
Consideration should be given to installing the equipment in an environment compatible with
manufacturer's maximum rated ambient temperature
2> Reduced Air ow-installation of equipment in a rack should be such that the amount of air ow required
for safe operation of the equipment is not compromised.
3> Mechanical Loading- mounting of the equipment in the rack should be such that a hazardous
condition is not achieved due to uneven mechanical loading.
Important
This user guide contains information on the limitations regarding product use and function and
information on the limitations as to liability of the manufacturer. Read the entire guide carefully
5-Port Ethernet Gigabit PoE Switch
Quick Installation Guide
5-Port Gigabit PoE+ Switch (30W)

Table of Contents

Rev 1.0 01/03/2013 Page 1 OF 7
