Dell Latitude E7240/E7440
Setup and Features Information
About warnings
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
Latitude E7240 — Front and Back View
Figure 1. Front View
1.
microphone
3.
camera status light
5.
display
7.
battery status light
9.
power button
11.
mini Display Port connector
2.
camera
4.
microphone
6.
hard-drive status light
8.
wireless status light
10.
security lock slot
12.
USB 3.0 connector
Regulatory Model: : P22S, P40G
Regulatory Type: : P22S001, P40G001
2013- 04
Advertisement
Table of Contents
Related Manuals for Dell Latitude E7240
Summary of Contents for Dell Latitude E7240
- Page 1 Dell Latitude E7240/E7440 Setup and Features Information About warnings WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Latitude E7240 — Front and Back View Figure 1. Front View microphone camera camera status light microphone display...
- Page 2 audio and microphone connector SD card reader fingerprint reader contactless smart-card reader touchpad touchpad buttons (2) keyboard mute button volume down button volume up button Figure 2. Back View power status light hard-drive activity light battery status light network connector USB 3.0 connector HDMI connector USB 3.0 connector with PowerShare...
-
Page 3: Latitude E7240 - Base View
Latitude E7240 — Base View Figure 3. Base View (without battery) USIM slot speaker battery bay battery latch speaker docking connector... -
Page 4: Latitude E7440 - Front And Back View
Latitude E7440 — Front and Back View Figure 4. Front View microphone camera camera status light microphone display hard-drive status light battery status light wireless status light power button security lock slot USB 3.0 connector audio and microphone connector wireless switch fingerprint reader contactless smart-card reader touchpad... -
Page 5: Latitude E7440 - Base View
Figure 5. Back View power status light hard-drive activity light battery status light network connector USB 3.0 connector mini DisplayPort connector HDMI connector USB 3.0 connector with PowerShare power connector cooling vents smart card slot Latitude E7440 – Base View Figure 6. -
Page 6: Quick Setup
WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/regulatory_compliance WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. -
Page 7: Specifications
Figure 10. Power Button NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer. Specifications NOTE: Offerings may vary by region. -
Page 8: Finding More Information And Resources
Blu-ray Disc Association (BDA) and licensed for use on discs and players. The Bluetooth word mark is a registered ® trademark and owned by the Bluetooth SIG, Inc. and any use of such mark by Dell Inc. is under license. Wi-Fi is a registered ® ®...
