- Page 1 HS-W8SPEN Ghost Writer User Manual April 2013...
- Page 2 Please read this user’s manual carefully before use. CONGRATULATIONS! Thank you for your purchase of this Hipstreet product and we hope you enjoy using it. Please visit website www.hipstreet.com. Please ensure that you fully read and understand the information within this user manual prior to using your product.
- Page 3 Important safety precautions • Always follow these basic safety precautions when using the unit. This will reduce the risk of product damage and personal injury. • Do not disassemble, repair or modify the unit by yourself. Refer servicing to qualified personnel. •...
- Page 4 • Clean only with a dry cloth. Make sure the unit is turned off before cleaning. Do not use liquid cleanser. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may...
- Page 5 and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is...
- Page 6 -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IC Warning This device complies with Industry Canada licence-exempt RSS standard(s).
- Page 7 gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
-
Page 8: Product Description
Product Description A. USB Port – connect to computer through the USB cable B. Pen Low battery indicator C. Power indicator for the base unit D. Magnet – attach the base unit onto the metal strip. E. Metal strip – Attached to the edge of Notebook display. -
Page 9: Package Contents
Package Contents Metal strip Base unit Pen batteries USB Cable Stylus Digital Pen... - Page 10 Setup Insert Pen Batteries a. Remove the battery compartment cover. b. Insert two SR41 batteries (Included), with the positive poles facing up as shown. c. Put back the battery compartment cover. WARNING: Do not attempt to open the pen. That may cause the pen to malfunction. Insert Stylus To insert the stylus, (1) Slide the stylus into...
- Page 12 Attach the Base Unit to Computer Display a. Connect the base unit to the computer through the USB cable. (Included)
- Page 13 b. Peel and stick the metal strip to the edge of the display. Center the magnet on the display. c. Attach the base unit onto the metal strip with magnet. Note: Some notebooks have a sensor at the edge of the display, and it may cause the notebook to sleep when the metal strip gets close to it.
- Page 14 onto the edge, please find an appropriate position to avoid interference with this sensor. Calibration In order to make the unit function properly, follow these steps to calibrate the screen with the pen. (1) Move mouse to the top right hand corner of your screen and click on Search when it appears.
- Page 15 (2) Search for “Control Panel” and select it. (3) Search for “tablet pc” in the top right hand corner of the window. (4) Select “Calibrate…”...
- Page 16 (5) Tap the centre of each cross-hair to complete the calibration process. (6) Once complete, you are ready to go!
- Page 17 Note: If you want to recalibrate the screen at a later time, click “Reset” in step 5 to clear the previous calibration data before you click “Calibrate”. Don’t move the Metal Strip’s position after calibration, otherwise you must recalibrate.
- Page 18 Drag: Tap and hold your pen on an item and then drag it. Sliding the pen to the left from the right edge of your display will bring up a menu:...
- Page 19 Zoom: a) Hold the Side Button on the pen. b) Touch and hold the point on the screen where you would like to zoom. Slide to another point, this will zoom in. To zoom out, slide back towards the first point.
- Page 20 Right click: Tap and hold your pen tip on an item for a few seconds and then release to show a pop-up menu.
- Page 21 Close a Window: Drag from the top to the bottom to close current window or application.
- Page 22 If you encounter any difficulties with this product, please visit website www.hipstreet.com and review our support section or call us. Our representatives are ready to help you with any questions about your product. We can guide you through connections, first-time use, or any of the features.
- Page 23 Product and Battery Disposal This product contains a built-in lithium battery and should not be disposed of in normal household waste. The battery in this device is not intended to be removed by the individual or end user. For disposal and recycling, please contact your local waste management authorities.
