1.3 Mega Pixel Digital Recording/ Video & Audio Transmission
User's Manual
ISSUE：0705, 2009
INDEX
1. Package Contents.................................................
2. Introduction..........................................................
3. System Requirements.............................................
4. Product Features...................................................
5. Hardware Overview................................................
6. Hardware & Software Installation..............................
6.1 Hardware Installation..........................................
6.2 Software Installation............................................
6.3 Internet Browser Settings....................................
7. Network Installation.................................................
7.1 Wired Network Installation...................................
7.2 Wireless Network Installation............................... 11
8. Using the Built-In Web for Configuration..................... 15
8.1 Language Select............................................... 15
8.2 Display............................................................ 16
8.3 Video Settings.................................................. 17
8.4 Audio Settings.................................................. 20
8.5 Network Settings............................................... 21
8.6 Wireless Network Settings.................................. 22
8.7 PPPoE Configuration......................................... 23
8.8 Dynamic DNS................................................... 24
8.9 SMTP Settings................................................. 25
8.10 FTP Settings.................................................. 26
8.11 Date and Time Settings.................................... 27
8.12 Motion Detection Settings................................. 28
8.13 Authentication Settings..................................... 29
8.14 Account Management...................................... 30
1
1
1
2
3
4
4
5
7
8
8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GrandTec Mega Pixel
Summary of Contents for GrandTec Mega Pixel
-
Page 1: Table Of Contents
INDEX 1. Package Contents……………………………..………….. GRAND MEGA PIXEL Wi-Fi CAMERA 2. Introduction………………………………….……………... 3. System Requirements...………..………….……………… 1.3 Mega Pixel Digital Recording/ Video & Audio Transmission 4. Product Features…….……….……………….…………... 5. Hardware Overview……………..…………….…………... 6. Hardware & Software Installation……..…..……..……… 6.1 Hardware Installation………..….………………..…. 6.2 Software Installation.....…….……………………... -
Page 2: Grand Mega Pixel Wi-Fi Camera
CD Driver with user manual/ software (IP Detect)/ Surveillance software 2. Introduction Grand Mega Pixel Wi-Fi Camera is a full featured network camera that enables you to remote view and listen with your web browser (supports iPhone WEB Browser). The Grand Mega Pixel Wi-Fi Camera uses the latest video compression technology that provides clearer and more fluent image transmission. -
Page 3: Product Features
4. Product Features 5. Hardware Overview 1/4” CMOS SXGA Sensor (1.3MegaPixel) Built-in High Sensitivity Microphone for remote listening. High Resolution Image Processor (160x120/ 320x240/ 640x480/ 1280x1024 ) High Performance Image Compression Supports TCP/IP / HTTP / FTP / SMTP / DHCP / PPPoE / DDNS / UPnP / NTP service Supports Motion detected Mail Function Remote view through the IE browser, simply type in the IP address Supports iPhone Web Browser (in MJPEG format). -
Page 4: Hardware & Software Installation
Step1: Press the Install Audio and Video Codec to install the audio and video codec. 6.1.2 Connecting to a Network Connect the Mega Pixel Wi-Fi Camera to an Ethernet hub or switch by using a standard cable. You can also connect directly to a computer by using the cross-over wire provided. -
Page 5: Internet Browser Settings
Step2: Press the Install Mega Pixel IP Camera Viewer to install the surveillance software. 6.3 Internet Browser Settings (IE 6.0) NOTE: Your browser must be enabled the ActiveX for connect to the Mega Pixel Wi-Fi Camera first time. Step 1: Start the internet browser. -
Page 6: Network Installation
Step 2: Click the “Auto Detect” button, and your camera’s MAC and default IP Address will be listed. Assign IP Address, Netmask (Subnet Mask) and Gateway (Default Gateway) for the Mega Pixel Wi-Fi Camera. (You must use the same Net Mask (ex. 255.255.255.0) and Gateway (192.168.2.254). -
Page 7: Wireless Network Installation
Step 6: Select the “MAC” and click the “Connect” button to connect the Mega Pixel Wi-Fi Camera. Step 2: Connect Mega Pixel Wi-Fi Camera to the PC with the crossover cable. Click the “Auto Detect” button specified as below, and your camera’s MAC and default IP Address will be listed. - Page 8 Step 4: Select “WLAN” in the “Mode” selection. Directly modify the “IP”, “Net Mask” and “Gateway”, and click “Setup” to save. Step 8: Turn off Mega Pixel Wi-Fi Camera, unplug the crossover cable, set the “WLAN/LAN” switch to “WLAN”, and then restart Mega Pixel Wi-Fi Camera.
-
Page 9: Using The Built-In Web For Configuration
In a normal situation, it might Mega Pixel Wi-Fi Camera provides a way for users to administrate the camera, a build-in web for take about 30~60 seconds for searching your Mega Pixel Wi-Fi Camera.) accessing the video, setting up the video parameter, configuring the network address etc. -
Page 10: Display
Resolution: Select the video resolution. Mega Pixel Wi-Fi Camera supports 4 kinds of resolution: 160 x 120, 320 x 240, 640 x 480 and 1280 x 1024. Framerate: Select the frame rate of the video. The range of frame rate supported by Mega Pixel Wi-Fi Camera is from 1 to 30 fps. - Page 11 8.3.2 iPhone User View the Camera from iPhone Mega Pixel Wi-Fi Camera supports iPhone’s browser, Safari. If user uses an iPhone to access to the Step 1: Assign your IP Camera an IP address and make your IP Camera accessible through the Mega Pixel Wi-Fi Camera, the Video Setting page should appear as below.
-
Page 12: Audio Settings
-IP Address, Subnet Mask and Gateway: If the user wants to use a static IP address for Mega Pixel Wi-Fi Camera, please enter the IP Address, Subnet Mask and Gateway - DNS Settings: Enter the DNS servers to Mega Pixel Wi-Fi Camera for name resolution. Save button: Save the configuration. All configurations should be available after the... -
Page 13: Wireless Network Settings
Mega Pixel Wi-Fi Camera supports 802.11b/g wireless network. User might configure the wireless setting Mega Pixel Wi-Fi Camera supports PPPoE dial-up function that let it directly connect to the Internet by clicking on “WLAN” in the Menu List. The details of network setting should appear in the Main Display through a DSL modem. -
Page 14: Dynamic Dns
Mega Pixel Wi-Fi Camera supports a build-in SMTP client for sending alarm e-mail. When the motion After creating an alias on the service provider’s web site, user might use this alias to access Mega Pixel detection function (see 8.12, Motion Detection Settings) is enabled, user might choose to receive alarm Wi-Fi Camera on the Internet. -
Page 15: Ftp Settings
Mega Pixel Wi-Fi Camera supports a build-in FTP client for uploading image or video. When the motion User could click on the “NTP” in the Menu List for configuring the time of Mega Pixel Wi-Fi Camera. detection function (see 8.12, Motion Detection Settings) is enabled, user might choose to upload video or image when motion is detected. -
Page 16: Motion Detection Settings
Mega Pixel Wi-Fi Camera supports the motion detection function. When this function is enabled, Mega -Alarm Mail: Enable/Disable the alarm e-mail function. Before enabling this function, please Pixel Wi-Fi Camera will monitor the video captured by it. And Mega Pixel Wi-Fi Camera will send alarm configure the SMTP configuration first. (refer to section 8.9) e-mail with image/video or upload the image/video to a FTP server when some object moves in the video. -
Page 17: Account Management
Control Port: Specify the control port the user wants to use for sending controlling message to Mega Pixel Wi-Fi Camera. The default port number is 21. Step 2: Enter the new password twice. And then press “SET PASSWORD” button for changing the RTP Range Low/High: User might specify the range of the random port that used by RTP protocol. - Page 18 Mega Pixel Wi-Fi Camera supports UPnP function. Using this function, user could find Mega Pixel Wi-Fi User could view the video connection status of Mega Pixel Wi-Fi Camera by clicking on the “Status” in the Camera by just one click on “My Network Place” (Windows XP and later version). For further setting the Menu List.
-
Page 19: Firmware Update
Step 1: Get the new firmware and save it in the hard disk. Step 1: Log in Mega Pixel Wi-Fi Camera and click on the “Reset” button in the Menu List. Step 2: Log in the Mega Pixel Wi-Fi Camera. Click on the “Upgrade” in the Menu List. -
Page 20: Reboot The Camera
9. Connecting Multiple Cameras to a Router 8.20 Reboot the Camera User could reboot Mega Pixel Wi-Fi Camera via the browser. Please follow the steps below for rebooting the camera. Step 1: Log in Mega Pixel Wi-Fi Camera and click on the “Reboot” in the Menu List. - Page 21 Step 1: Confirm the UPnP function of camera has been enabled (refer to section 8.16). Double click on ( ) Mega Pixel IP Camera Viewer’s execution file on Windows Desktop or in the Mega Step 2: Follow the steps below to enable UPnP for Windows ME/ XP.
- Page 22 11.1.3 System Setup 11.1.3.2 Record All Channels System Setup include: Global Parameters, Record All Channels, Account Manager, Login and Press the button to record all of the available channels according to the scheduler setting. Press Language. button again to stop recording. 11.1.3.3 Account Manager Press the button to open the Passwords Setting window.
- Page 23 11.1.4.3 Refresh: To refresh the videos, the recording process will be stopped and restart again. 11.1.4 Camera Setup If the video is unstable after some high CPU resource programs, CPU usage may come to 100% and all The buttons in the bottom of each channel are the functions for current channel only. the resources are taken.
- Page 24 11.1.5 Hard Disk Info. 12. Troubleshooting File package and disk free space amount. Situation Check Point Adjust the camera’s image quality through the configuration menu. The focus is bad Adjust by turning clockwise or counter-clockwise the 11.1.6 Channels focus manually. 16 channels indicators to control the function buttons.
