Summary of Contents for SOUNDMASTER highline BT3000

  • Page 1 DEUTSCH NEDERLANDS ENGLISH ESPAÑOL FRANÇAIS PORTUGUÊS BT3000...
  • Page 2: Table Of Contents

                          BT3000 / English instruction manual    Table of contents    PACKAGE CONTENTS…………………………………………………………..2  FEATURES……………………………………………………………………………2  SAFETY PRECAUTION…………………………………………………………..3  CONTROLS…………………………………………………………………………..4  REMOTE CONTROL BATTERY………………………………………………..5  GENERAL OPERATION………………………………………………………….6  TROUBLESHOOTING……………………………………………………….……8  SPECIFICATION…………………………………………………………………….8  TRADEMARK………………………………………………………………………..8  RECYCLING…………………………………………………………………………..8        Congratulation      Congratulation on your purchase. For a better use of your  new  device,  we  recommend  you  to  read  carefully  this  user manual and keep it for record. ...
  • Page 3: Package Contents

                          BT3000 / English instruction manual    Package contents  - Main Unit  - Remote  control  function  with  battery  type  CR2025  (included)  - Detachable power cord  - 3.5mm AUX IN cable x 1  Instruction Manual x 1 Quick Start Guide x 1  Features  - 3.5mm aux in jack to connect your MP3 player  - Bluetooth enabled to wirelessly play your music  - Full function remote control  EN- 2...
  • Page 4: Safety Precaution

                          BT3000 / English instruction manual  Safety precaution    Water and Moisture – The unit should not be used near water. For  example: near a bathtub, washbowl, kitchen sink, laundry tub,  swimming pool or in a wet basement.      Ventilation – The unit should be situated so that its location or  position does not interfere with its proper ventilation. For example, it  should not be situated on a bed, sofa, rug or similar surface that may  block ventilation openings. Also, it should not be placed in a built‐in  installation, such as a bookcase or cabinet, which may impede the flow  of air through the ventilation openings.  Heat – The unit should be situated away from heat sources such as  radiators, heat registers, stoves or other appliances (including  amplifiers) that produce heat.  Power Sources – The unit should be connected to a power supply only  of the type described in the operating instructions or as marked on the  appliance.  Power Cable Protection – Power supply cables should be routed so  that they are not likely to be walked on or pinched by items placed  upon or against them. It is always best to have a clear area from where  the cable exits the unit to where it is plugged into an AC socket.  Cleaning – The unit should be cleaned only as recommended. See the  Maintenance section of this manual for cleaning instructions.  Objects and Liquid Entry – Care should be taken so that objects do not  fall and liquids are not spilled into any openings or vents located on  the product.  Attachments – Do not use attachments not recommended by the ...
  • Page 5                       BT3000 / English instruction manual  time. This will prevent damage to the product due to lightning and  power‐line surges.      Overloading – Do not overload wall sockets, extension cords, or  integral convenience receptacles as this can result in a risk of fire or  electric shock.  Damage Requiring Service – The unit should be serviced by qualified  service personnel when  A. the power supply cable or plug has been damaged.  B. objects have fallen into or liquid has been spilled into the enclosure.  C. the unit has been exposed to rain.  D. the unit has been dropped or the enclosure damaged.  E.  the unit exhibits a marked change in performance  or does not operate  normally.  Periods of None Use – If the unit is to be left unused for an extended  period of time, such as a month or longer, the power cable should be  unplugged from the unit to prevent damage or corrosion.      Servicing – The user should not attempt to service the unit beyond  those methods described in the user’s operating instructions. Service  methods not covered in the operating instructions should be referred  to qualified service personnel.  WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
  • Page 6: Controls

                          BT3000 / English instruction manual  from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
  • Page 7                       BT3000 / English instruction manual        Technical Specification              Power supply              : AC 100‐240V, 50/ 60Hz  Battery for remote control    : 3V   (CR2025)  Power consumption              : 140W  Output power ...
  • Page 8                       BT3000 / English instruction manual  FRONT PANEL    REAR PANEL  EN- 7...
  • Page 9                       BT3000 / English instruction manual  REMOTE CONTROL  1. Power / Pairing / Function  10. Mute  2. Volume –  11. Previous    3. Volume +  12. Bass up  4. AUX(Green) / Bluetooth(Blue)    13. Bass down  / Standby(Red) indicator  14. Pairing  5. Remote sensor  15. AUX switch  6. AUX jack  16. Play / Pause    7. AC socket  17. Next    8.
  • Page 10: Remote Control Battery

                          BT3000 / English instruction manual  Remote control battery  1. Slide and hold the battery release tab in the direction  of the arrow.  2. Pull  out  the  battery  holder  and  remove  the  old  battery.  3. Replace with a new battery (CR2025).  4. Insert the battery holder back into the remote control.  Powering up your unit      To power the player ON:  1. Plug AC cord into AC jack, and plug into a live AC wall  outlet.  2. Press  the  Power/Pairing/Function  button  on  the  top  panel or the ...
  • Page 11                       BT3000 / English instruction manual  Note:  To  save  power,  the  player  will  switch  to  economic  standby mode when the speaker is idle for 15 minutes.    Using Bluetooth Function: Paring Your Device  Before your start  Your Bluetooth device (cellphone, MP3 player, computer,  etc.) must support the A2DP Bluetooth profile (Commonly  known as stereo audio profile) to work with the player.  Many of the latest mobile phones and PCs with built‐in  Bluetooth functionality will support this profile. For  accurate information about your product, please refer to  your Bluetooth device’s user manual for details on the  Bluetooth profiles it supports and on how to set the  device’s Bluetooth pairing/searching/setup mode.    Pairing your Bluetooth device with the player  1. Press and hold the Power/Pairing/Function button on  the  top  panel  for  5  seconds  or  the  Pairing  button  on  the ...
  • Page 12                       BT3000 / English instruction manual  4. Once  paired  with  a  device,  the  Blue  light  will  stop  flashing  and  glow  steadily.  A  beep  sound  will  also  indicate that the connection is established.  5. Pairing  remains  intact  even  when  the  player  or  the  Bluetooth device is powered off or is taken out of link ...
  • Page 13                       BT3000 / English instruction manual    2. Turn on the player and press the  Power/Pairing/Function button on the top panel or  the Bluetooth button on the remote control to select  the Bluetooth mode, Blue light indicates for Bluetooth  mode.  3. Press  the    button  on  the  remote  control  to  play  your Bluetooth‐enable device.    (Depending  on  the  Bluetooth  device  you  are  using,  you may need to manually go into media player mode ...
  • Page 14                       BT3000 / English instruction manual    2. Press  the  Power/Pairing/Function  button  on  the  top  panel or press the AUX button on the remote control  to  select  the  AUX  mode.  Green  light  indicates  Aux  Mode also.  3. Set your personal audio player/computer to PLAY.  Headphone socket            3.5mm jack cable (included)   ...
  • Page 15: Troubleshooting

                          BT3000 / English instruction manual    Troubleshooting    There is no power to the player  Ensure  that  the  Power  Switch  of  wall  socket  is  physically set to the ON position.  Ensure that the AC plug is securely connected to the  player and proper wall outlet.    Trouble pairing device/computer with the player  Make  sure  you  have  the  latest  firmware  for  your  iPhone /iPad/iPod.  Make ...
  • Page 16: Recycling

                          BT3000 / English instruction manual    This product bears the selective sorting symbol for Waste  electrical and electronic equipment (WEEE). This means that  this product must be handled pursuant to European directive  2002/96/EC in order to be recycled or dismantled to minimize  its impact on the environment.  User has the choice to give his product to a competent  recycling organization or to the retailer when he buys a new  electrical or electronic equipment.  For further information, please contact your local or regional  authorities.    Net weight: 6300g      Hereby, Wörlein GmbH declares that this Bluetooth device is in  compliance with the essential requirements and other relevant  provisions of Directive 1999/5/EC.    A copy of the Declaration of Conformity may be obtained  at the following location: Wörlein GmbH, Gewerbestrasse  12, D 90556 Cadolzburg, Germany  EN- 15...
