Solstice SLS-ENVR4 Quick Setup Manual

SLS-ENVR4 Network Video Recorder V2.2.2 Quick Setup Guide
The SLS-ENVR4 series NVR is an intelligent and compact appliance that provides a network interface to
monitor, record and playback video from up to 4 IP cameras. It is very easy to install and use.
What's in the box
Your SLS-ENVR4 product includes components shown in the picture below.
SLS-ENVR4 NVR
Software CD
What you need
Your SLS-ENVR4 NVR hardware is preconfigured with an HDD. If you want to change the HDD or configure
it differently, refer to the document SLS-ENVR Series Network Video Recorder V2.2.2 User Manual
provided on the Software CD for specific instructions.
A PC is required to access and control your NVR. It must meet the following requirements:
Operating system: Microsoft® Windows® 2003, 2008, XP, Vista, 7 and 8 (32- and 64-bit versions);
•
Apple® OS X® 10.6, 10.7, 10.8; Linux with 2.6 kernel or newer (Oracle Java recommended)
Internet browser: Mozilla® Firefox® 17 ESR, 20 or newer; Internet Explorer® 8 (with performance
•
limitations, 32-bit version), 9, 10 (32-bit version); Google Chrome® 26 or newer; Apple Safari® 5.1 (on
Mac OS X only). JavaScript and cookies must be enabled.
Java™: Oracle® Java 6.0 or newer is required. The latest version of Oracle Java 7 is recommended.
•
MPEG4 and H.264 support for the viewer applet requires installation of native libraries to the client
•
computer. The libraries are automatically installed by the Java applet.
Client computer hardware configuration: Computer with 1GB RAM
•
Hardware configuration: Computer with 2GHz processor, 1GB RAM minimum (depends on number of
monitored devices). With the SLS-ENVR4 NVR you can download videos and pictures from videos saved on
a hard disk. The pictures are in standard JPEG format and can be displayed in every standard picture browser.
To play video, install an FFDShow CODEC (download from http://www.freecodecs.com/download/FFDshow.
htm) or similar filter. Also, VLC player contains the CODEC necessary to play SLS-ENVR4 videos (download at
http://www.videolan.org).
Storage
LED
Light strip
Power
LED
Network
LED
Info
LED
SLS-ENVR4 front panel
1
Power adapter
Quick Setup
Guide Ethernet
cable
Power
On/Off
button
The front panel of SLS-ENVR4 NVR includes four LED:
The Network LED indicates the activity of the network adapter.
•
The Storage LED blinks green if the hard disk is active, it lights red if the disk fails.
•
The blue Power LED and red Info LED function as follows:
•
Status
Service mode is active
Normal mode is active
Found by Discover
NVR is starting
NVR is switching off
Power ON / OFF button:
•
If pressed for less than 3 seconds, disables an audible alarm signal (see Acoustic Signals below).
—
If pressed for more than 5 seconds accompanied by a beep, will power off the device normally.
—
Acoustic signals
Acoustic signals indicate the following:
A brief sound: When the device is switched on or off by pressing the ON/OFF button.
•
A continuous sound for one of these reasons:
•
If there is a problem with the hard disk (can be switched off by briefly pressing the front ON/OFF
—
button).
If the temperature of the device exceeds 140 °F (60 °C). The acoustic signal is accompanied by the
—
blinking of a red light on the light strip. The sound can be switched off by briefly pressing the front
ON/OFF button. Solstice will make an entry in the log, and can e-mail information if the SMTP is
setup.
If the temperature of the device exceeds 158 °F (70 °C). The acoustic signal is accompanied by
—
the blinking of a red light on the light strip. The device will make an entry in the log, send an
information e-mail if the SMTP is set up and will be automatically switched off.
Retaining
screw
Power USB port
connector (not used)
The back panel buttons / indicators function as:
Reset button / Power LED (blue):
•
To use the Reset button:
Press for less than 3 seconds to restart the device from Normal mode to the Service mode. If in
—
Service mode, it will return to the Normal mode if Reset is pressed again.
Press and hold for 15 seconds to restart the device. NOTE: Recordings may become damaged.
—
Press and hold for 25 seconds while connecting the power cable to restore factory settings. All
—
settings and recordings will be lost.
Power LED: Indication is identical to the front panel Power LED.
•
Info / Reset LED (red-green): When red, it is identical to the Info LED on the front panel. It is lit green
•
when the Reset button was pressed for less than 5 seconds; blinks when the Reset button has been
pressed for a moderately long time; blinks fast when the reset button has been pressed for longer than
15 seconds.
Storage LED (red-green): combined red-green LED is identical to the Storage LED on the front
•
panel.
Power LED Info LED
– On
On –
On Blinking
Blinking –
Blinking –
Reset button / Power LED (blue)
Network Storage LED
connector (red-green)
Back panel
SLS-ENVR4-xT_2.2.2_RQ
Retaining
screw
Info / Reset
LED
(red-green)
9/26/13
