Campfire in a can Owner's Manual

Propane campfire

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Designed to Work

TESTED FOR UP TO 64,000 BTU:

CSA International Requirement

4.96 U.S. (3rd Ed.)

For Outdoor Gas Fireplaces

USA and Canada

THIS UNIT WAS TESTED AND LISTED TO ANSI Z21.97-2012 / CSA 2.41-2012

by OMNI-TEST LABORATORIES

DANGER

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame.

3. If odor continues, keep away from the appliance

and immediately call your gas supplier or fire

department

Owner's Manual

Built to Last

Report Number: 363-O-01-5

WARNING

Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any other

appliance.

An LP-cylinder not connected for use shall not be

stored in the vicinity of this or any other appliance.

Portland

Table of Contents

Need help?

Do you have a question about the Campfire In A Can and is the answer not in the manual?

Questions and answers

Summary of Contents for Campfire in a can Campfire In A Can

Page 1 Designed to Work Built to Last Owner’s Manual TESTED FOR UP TO 64,000 BTU: CSA International Requirement Portland 4.96 U.S. (3rd Ed.) For Outdoor Gas Fireplaces USA and Canada THIS UNIT WAS TESTED AND LISTED TO ANSI Z21.97-2012 / CSA 2.41-2012 Report Number: 363-O-01-5 by OMNI-TEST LABORATORIES DANGER...
Page 2: Warnings
Warnings WARNING: Use in a well-ventilated space. Not to be used inside a For Outdoor Use Only. building, tent, garage, or any other enclosed area. Do not use within 10 feet of open door(s) or window(s). Clearance to combustibles: 18” (45.7cm) on all sides and 78” (198 cm) above the unit. Always keep the area clear and free from combustible materials, gasoline, and other ammable vapors and liquids.
Page 3 Warnings WARNING If the information in this manual is not followed exactly, a re or explosion may result causing property damage, personal injury or loss of life. THIS UNIT IS WARNING NOT FOR USE WITH SOLID FUEL. WARNING Ensure all new cylinders are purged. Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or any other appliance.
Page 4 Warnings • e installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 • For use with liquid propane only. e maximum inlet gas supply pressure is 11” water column Input is 28.5MBH.
Page 5: Table Of Contents
Table of Contents Table of Contents Warnings 1 - 3 Table of Contents Happy Camper Guarantee Parts & Assembly Operating Instructions, Read Before Lighting Maintenance Attaching the Camp re to a Quick Disconnect 9-10 Converting to Natural Gas Troubleshooting 11-12 Accessories Warranty Backyard Ideas...
Page 6: Happy Camper Guarantee
Welcome to the Camp re In A Can family We are thrilled that you have made Camp re In A Can your propane camp re of choice. You have made a great investment in a camp re that will bring you many years of enjoyment. Happy Camper Guarantee Your Camp re In A Can is protected by our Happy Camper Guarantee and supported by our legendary...
Page 7: Parts & Assembly
Parts & Assembly PARTS PARTS 1. Burner Base / Hose & Regulator Assembly 2. Removable Cooking Grate 3. One-Piece Ceramic Log Set 4. Aluminum Canister Top Replacement parts are available by calling toll free 1.888.768.7737 CANISTER TOP COOKING GRATE e canister top is designed to be used as a stand. To use the cooking grate with the log set, place the Raising the camp re o the ground allows it to...
Page 8: Operating Instructions, Read Before Lighting
Operating Instructions LIGHTING THE CAMPFIRE 1. Attach POL/QCC (A) to tank valve. Make sure you have a good seal. 2. Close shut o valve (B) by turning clockwise. 3. Open tank valve (C); check for leaks. Before turning gas on, apply a solution of soapy water to all hose connections.
Page 9: Maintenance
Maintenance LOG SET CLEANING THE LOG SET Carbon (soot) should be cleaned o the surface of the logs periodically to prevent excessive build up. To clean the logs, be sure the re is out, the gas supply is turned o and the logs are cool to the touch.
Page 10: Attaching The Camp Re To A Quick Disconnect
Attaching the Camp re to a Quick Disconnect Determine if the quick disconnect you are hooking up to on your RV is high pressure or low pressure. If there are no propane lines before the propane regulator, then the quick disconnect on your RV is low pressure. If there are propane lines before the regulator, your quick disconnect could be high or low pressure.
Page 11: Converting To Natural Gas
Attaching the Camp re to a Quick Disconnect LOW PRESSURE QUICK DISCONNECT PROCEDURE Step 1. Remove the propane regulator assembly from the gas control ball valve. Step 2. Attach the male quick disconnect tting to the gas control ball valve. Step 3.
Page 12: Troubleshooting
Troubleshooting TROUBLESHOOTING LOW FLAME HEIGHT TROUBLESHOOTING LOW FLAME HEIGHT I lit my Camp re In A Can and the re does not seem to go high anymore. What could cause this to happen? SOLUTION 1. e camp re shut o valve (B) was Turn gas o at propane tank.
Page 13: Accessories
Troubleshooting Troubleshooting TROUBLESHOOTING LOW FLAME HEIGHT TROUBLESHOOTING LOW FLAME HEIGHT I have been running my camp re for a while, and all of a sudden I have a low ame, and I`m not out of propane. What could cause this? Your regulator may be freezing up! ere are 2 possible reasons that a propane regulator may freeze up.
Page 14: Warranty
Warranty EZ CAMPFIRE CORP., OUTDOOR PRODUCTS LIMITED ONE (1) YEAR WARRANTY EZ CAMPFIRE CORP., OUTDOOR PRODUCTS LIMITED ONE (1) YEAR WARRANTY EZ Camp re Corp. extends the following warranty for EZ Camp re Corp. outdoor products used in the United States of America or Canada. Dealers and employees of EZ Camp re Corp. have no authority to make any warranty or authorize any remedies in addition to or inconsistent with the terms of this warranty.
Page 15: Backyard Ideas
Backyard Ideas Visit camp reinacan.com for ideas and how to’s Toll Free 1.888.768.7737...
