Summary of Contents for Smartview iSC-NVR2316-T
- Page 1 SmartVIEW NVRs Quick Installation Guide Version 1.5 iSC-NVR2316-T / iSC-NVR2532-T iSC-NVR2532-U /SC-NVR2532-R iSC-NVR2532-A / iSC-NVR2532-D Copyright © Ingrasys Technology Inc. All rights reserved.
-
Page 2: How To Start
1. How to Start? Thank you for using SmartVIEW NVR. Following steps are for bringing on this system from storage setting to starting recording and live viewing. Details will be described in following contents. Hardware preinstall & power on RAID setting... -
Page 3: Package Contents
2. Package Contents Following items should be included in your SmartVIEW NVR’s accessory content. If any component is missing in your SmartVIEW NVR package, please contact Ingrasys Technology Inc. Model No. iSC-NVR2316-T iSC-NVR2532-T iSC-NVR2532-U DVD-ROM Power Cord HDD Srews HDD tray keys... - Page 4 Model No. iSC-NVR2532-R iSC-NVR2532-A iSC-NVR2532-D DVD-ROM Power Code HDD Srews Slide Rail Slide Installation Guide Rackmount screw set RAID card driver RAID card Quick Intallation Guide...
-
Page 5: Pre-Install Notice
3. Pre-install Notice Before installing SmartVIEW NVR, please make sure the following items are ready. Network connection Well-configured IP camera(s) A computer monitor with VGA interface A USB mouse 1~24 3.5” hard disk(s) A screwdriver... -
Page 6: Hardware Interface
4. Hardware Interface 4.1 NVR2316-T Power switch Power LED Reset button System read/write LED Front cover for 4 x 3.5” lockable HDD trays 2 x USB 2.0 Power socket 4 x USB 2.0 E-SATA... - Page 7 4.2 NVR2532-T Power switch Power LED Reset button System read/write LED Front cover for 4 x 3.5” lockable HDD trays 2 x USB 2.0 Power socket COM1 Audio Jack COM2 DVI-D HDMI 4 x USB 2.0...
- Page 8 4.3 NVR2532-U Power switch Alarm mute button Fan failed LED Power LED 4 x 3.5” HDD tray Power socket Audio Jack COM1 COM2 DVI-D HDMI 4 x USB 2.0...
- Page 9 4.4 NVR2532-R / NVR2532-A (Redundant PSU) NVR2532-R NVR2532-A (Redundant PSU) Power switch System reset button Alarm mute button System read/write LED Power LED System alarm LED LAN1 LED LAN2 LED 2 x USB 2.0 16 x 3.5” HDD tray Power socket Audio Jack COM1 COM2...
- Page 10 4.5 NVR2532-D Power button System reset button Alarm mute button Power LED System alarm LED LAN1 LED LAN2 LED 2 x USB 2.0 Power socket 24 x 3.5” HDD tray COM1 Audio jack COM2 DVI-D HDMI 4 x USB 2.0...
- Page 11 … etc.), you MUST follow the steps to apply changes. Please do the 4 steps below before using SmartVIEW NVR. Notice : For the system safety, you have to enable the SysGuard for running SmartVIEW NVR after changing settings on Windows operation system.
- Page 12 SysGuard is enabled. ： Notice The most important setting is to create RAID and format disks, SmartVIEW Installation Wizard will apply 1st available drive letter (e:) automatically as default Recording Media.
- Page 13 Yes to enable the SysGuard. System will be restarted automatically. ※ If your SmartVIEW is already running and SysGuard is enabled, you may open the SysGuard program and select Disable the SysGuard function and click OK. Then, click Yes.
-
Page 14: Raid Settings
6. RAID Settings Notice : RAID settings only applied for NVR2532-R / NVR2532-A / NVR2532-D, if you are using NVR2316-T/K or NVR2532-T, please skip this chapter directly. 6.1 Log-in MegaRAID Storage Manager Insert all hard drives to the trays. Power on the system. Please disable the SysGuard (Refer to Chapter 4.) before changing the RAID settings. -
Page 15: Raid Configuration
6.2 RAID configuration MegaRAID Storage Manager You will enter the main console of Select to Physical tab and make sure every hard disks you installed in your SmartVIEW NVR’s front slots are all “Unconfigured Good” (like Right click on LSI MegaRAID SAS 9260-4i... - Page 16 Create Drive Group – Drive group and Virtual drive settings will pop up, please select RAID 5 ( ), then click Next ( ) button to create RAID. Create Virtual Drive - Summary window will pop up to confirm all settings are correct, and then click Finish and OK to complete settings.
- Page 17 Management. Please be aware of the recommended maximum volume size is less than for the best performance of database. 6.3 Enable SysGuard Please execute SmartVIEW and enable the SysGuard. The system will be under protection after system is restarted.
-
Page 18: Add Storage
7. Add Storage SmartVIEW NVR is capable to install up to 24 hard drives as recording storages. To keep the system working normally, you should operate steps as the following for adding recording storages: ： Notice If you are using NVR2532-R/A/D and your RAID setting has been just done, please jump to step (5) directly. -
Page 19: Installation Wizard
8. Installation Wizard After adding storages, once you are first using SmartVIEW, the Installation Wizard will pop up automatically to finish basic NVR setting and adding cameras. And then you will enter SmartVIEW main console to start your enjoyable surveillance experience! System setting Snapshot Folder：To assign a folder to store snapshot pictures. - Page 20 (Users are needed to prepare the storage of recording for each camera in the system configuration.) Add: To specify whether the camera to be managed or not. Click to finish adding cameras with basic settings and get into SmartVIEW Live view page.
