Installation & Operations Manual

Element-MF

Please read this entire manual before installation and use of this Multi-Fuel burning

room heater. Failure to follow these instructions could result in property damage,

bodily injury or even death."

Contact local building or fire officials about restrictions and installation inspection

requirements in your area.

Save these Instructions

615

Element-MF Installation and Operations Manual

Page 1

Table of Contents

Need help?

Do you have a question about the Element-MF and is the answer not in the manual?

Questions and answers

Summary of Contents for Even Temp Element-MF

Page 1 Failure to follow these instructions could result in property damage, bodily injury or even death." Contact local building or fire officials about restrictions and installation inspection requirements in your area. Save these Instructions Element-MF Installation and Operations Manual Page 1...
Page 2: Table Of Contents
TABLE OF CONTENTS General Information ........................4 Installation Check List ....................... 5, 6 Element-MF Layout Diagram ..................... 7, 8 Element-MF Dimension ......................... 9 Approved Installations ........................9 Venting - Approved Materials .......................10 Venting Size Guidelines ....................10 Venting-Typical PL Vent Components ................11 Venting - Determining Materials ...................
Page 3 Daily Maintenance (Multi-Fuel Pot) ................. 37-40 Periodic Maintenance....................41-43 Yearly Maintenance ....................43, 44 Safe Operation ..........................44 Wiring Schematic...........................45 Troubleshooting & Frequently Asked Questions ............... 46-49 Parts Breakdown ........................50-57 Warranty ............................58 Element-MF Info & Notes ......................59 Element-MF Installation and Operations Manual Page 3...
Page 4: General Information
DEFINITION OF “STOVE” The word “Stove” as used in this manual to describe the Element-MF is interpreted to mean a Multi-Fuel Stove approved for Corn, Wheat, Rye, Cherry Pits and Distiller’s Grain. This stove is not intended as the sole source of heat.
Page 5: Installation Check List
1. All joints of PL vent and single wall stainless steel pipe should be fastened by at least 3 screws and correctly installed. (Follow vent manufacturer’s instructions). Seal all joints with high temperature silicone to create an airtight seal. Element-MF Installation and Operations Manual Page 5...
Page 6 MANUAL MAY RESULT IN A HOUSE FIRE, PROPERTY DAMAGE, BODILY INJURY, EVEN DEATH. PLEASE FOLLOW INSTALLATION MAINTENANCE INSTRUCTIONS. CAUTION: NEVER ADD FIRE STARTER TO A HOT STOVE. CAUTION - Hot Surfaces - Keep Children away. - Do not touch during Operation. Element-MF Installation and Operations Manual Page 6...
Page 7: Element-Mf Layout Diagram
Figure 1 There are two burn systems used in Element Series of stoves. These systems are interchangeable in the stove body. This Manual covers the ELEMENT-MF, which uses the Multi-Fuel Burn System The Multi-Fuel Burn System is the St. Croix Patented “Clinker Removal System”. This burn pot allows the clinker to be removed without losing the fire in the pot.
Page 8 The Multi-Fuel Burn System is approved for Corn, Wheat, Rye, Cherry Pits and Distillers Grain. Wood pellets are no longer approved for use (except as starter pellets) in Element- MF’s built after the 2015 NSPS. Element-MF Installation and Operations Manual Page 8...
Page 9: Element-Mf Dimension
H – Front of Stove to end of Exhaust Pipe Approved Installations The Element-MF is approved for CONVENTIONAL and MOBILE HOME installations as a FREESTANDING stove. The stove may also be installed on the Hearth in front of a Fireplace and vented through the chimney of the fireplace.
Page 10: Venting: Approved Materials
VENTING: APPROVED MATERIALS The Element-MF requires a venting system approved for pellet or corn venting by a certified testing lab. Approved pellet or corn venting materials are: 1) PL vent, a double wall vent with a stainless steel liner; and 2) Single wall rigid or flexible stainless steel pipe. PL Vent and Single wall vent is available through manufacturers such as: ICC Pellet Vent, Energy Vent LTD, James A.
Page 11: Venting-Typical Pl Vent Components
TYPICAL PL VENT COMPONENTS RAIN CAP VERTICAL OR WALL THIMBLE CHIMNEY SUPPORT BRACKET HORIZONTAL ADAPTER ADJUSTABLE LENGTH SINGLE TEE SINGLE REDUCTION DOUBLE TEE PIPE w/TEE CAP TEE w/TEE CAP w/TEE CAP PIPE ADAPTER INCREASER ELBOW ELBOW Element-MF Installation and Operations Manual Page 11...
Page 12: Venting: Determining Materials
FUEL REMAINS IN THE BURN GRATE. (See “Battery Backup” on page 5) 2. It is not recommended to run vertical venting outside the heated environment where the Element-MF is installed. Running a venting system in a cold environment may cause the flue temperatures to cool down too much for adequate drafting.
Page 13: Venting: Termination Requirements
4’ (1.2 m) BELOW a door, window, cavity, or air vent 4’ (1.2 m) HORIZONTALLY FROM a door, window, cavity, or air vent 1’ (305 mm) ABOVE a door, window, cavity, or air vent Element-MF Installation and Operations Manual Page 13...
Page 14 50000 BTU/Hr shall be located not less than 12” from the opening. Figure 5 9” (229 mm) ABOVE, BELOW OR HORIZONTALLY FROM a door, window, cavity, or air vent. Element-MF Installation and Operations Manual Page 14...
Page 15: Venting: Termination Clearance Requirements
FROM The wall penetration point 3’ (915mm) FROM a gas meter/regulator assembly 2’ (610 mm) FROM any adjacent combustibles such as: Adjacent buildings, fences, protruding parts of the structure, roof eaves or overhangs, plants, shrubs, etc. Element-MF Installation and Operations Manual Page 15...
Page 16: Venting: Into An Existing Chimney
When wall penetration is necessary to access a masonry chimney, use a listed PL vent wall thimble. (Figure 7). 4. When venting into a Class A steel chimney, use an appropriate PL Vent adapter. (Figure 8) Element-MF Installation and Operations Stove Page 16...
Page 17: Venting - Hearth Mount
(C). An approved flex liner or PL vent must be used. A chimney system with known drafting problems may require a liner, which may also need to be insulated to keep vent system warm in a cold chimney environment. Element-MF Installation and Operations Stove Page 17...
Page 18: Floor Protection
The Hearth / Non-Combustible pad must extend a minimum of 6” (152 mm) in Front of Unit and beyond each side of the Fuel Loading and Ash Removal Opening(s). Figure 10 Floor protection (Top View) Element-MF Installation and Operations Stove Page 18...
Page 19: Minimum Clearances
Floor protection: Sides & back of stove 0” Alcove: Vertical to Combustibles 16” Alcove: Sides 4” Alcove: Back 4” Figure 11 (Top View) Figure 12 (Top View) Clearances: corners of stove Clearances Sides and Back Element-MF Installation and Operations Stove Page 19...
Page 20: Minimum Clearances
Operations Manual. Please read the section covering the Daily Maintenance, Periodic Maintenance and Yearly Maintenance in the Operations Manual. Figure 15 Alcove Installation (Top View) Element-MF Installation and Operations Stove Page 20...
Page 21: Outside Combustion Air
OUTSIDE COMBUSTION AIR 1. Under certain conditions it is recommended that the Element-MF be connected to an outside source of combustion air to improve performance. Flexible metal hose, or rigid metal pipe, (conduit), must be connected around (NOT INSIDE) the combustion air inlet tube. Be careful not to pinch or bend the outside air pipe with too small a radius which may be terminated flush with the outside wall but should be protected from wind and weather by a hood.
Page 22: Mobile Home Installation
9. Floor protection requirements must be followed precisely. 10. PL Vent must be used for exhaust venting. (Single wall vent is not allowed). Follow PL Vent manufacturer’s installation directions and observe all listed clearances to combustibles. Element-MF Installation and Operations Stove Page 22...
Page 23: Element-Mf Operation
PREVENTING CHIMNEY FIRES Chimney fires can be prevented by properly operating the Element-MF and by periodic inspection and cleaning of the chimney. When burning these fuels tar and other organic vapors are produced, which combine with expelled moisture to form creosote.
Page 24 If an excessive amount seems to be blowing out of the pot, adjust the damper by closing it a small amount at a time. (Read the section covering the Combustion Air Damper on page 30 - 32) Element-MF Installation and Operations Stove Page 24...
Page 25: Installation Check
- Be aware that the hotter the fire, the less creosote is deposited, and that weekly cleaning may be necessary in mild weather, even though monthly cleaning may be enough in the coldest Element-MF Installation and Operations Stove Page 25...
Page 26: Control Board Features
Stove. Control Board Features The Control Board controls all functions of the Element-MF by monitoring sensors that are in the system. These sensors serve 2 purposes. General Operation of the Stove. Safety Features, to shut the unit down in the event the sensors detect a problem in the unit.
Page 27: Pre-Lighting Instructions
T-Stat Mode. The Multi-Fuel Stove is hooked to a Thermostat and when calling for heat the Element-MF will advance to the Heat level set at the Control board. Once the Heat demand has been met the Stove will drop to the #1 Heat Level setting and pilot. The Stove never shuts off and provides constant heat.
Page 28: Changing The Program On The Control Board
OFF Time is increased or decreased, depending on the program chosen. Program 1. The Cycle Time is 11.5 seconds. This is the default program when the Element-MF is first plugged in. This program does not offer self-ignition. This program is for use with Corn, Wheat and Rye, Cherry Pits &...
Page 29: Lighting Instructions
If the Stove went into “Shutdown” and the #3 LED is flashing (See section on Diagnostic Features on page 34 and 35.) repeat the Start-Up process. CAUTION: NEVER ADD FIRE STARTER TO A HOT STOVE. Element-MF Installation and Operations Stove Page 29...
Page 30: Shutting Off The Insert
The board essentially goes into “Safety shutdown”. 2. As long as the temperature within the Element-MF remains above 110°F the both Fans will continue to run. When the P.O.F. switch drops out, the room fan shuts of and the Combustion fan will run for another 10 minutes and finally shut down completely.
Page 31: Adjusting The Damper
If the grain has formed a clump in the pot, use a screwdriver to break up the clump of fuel to allow for proper airflow). Wait 15 minutes to see if the burn pot becomes balanced. Repeat this step as many times as needed until the burn pot becomes balanced. Element-MF Installation and Operations Stove Page 31...
Page 32: Flame Pattern Characteristics
USE OF A THERMOSTAT The Element-MF offers the optional feature of thermostatically controlling your new stove. By using a thermostat to control the operation of your Stove you can benefit two ways. First of all, after setting the thermostat to your desired heating needs, the stove will operate accordingly to uniformly maintain your desired temperature setting.
Page 33 Read Frequently Asked Questions section in the Operations Manual to Troubleshoot the Thermostat. Figure 22 NOTE: Installers must determine a neutral location of where to mount the thermostat for accurate room temperature measurements. Element-MF Installation and Operations Stove Page 33...
Page 34: Diagnostic Features & Safety Sensors
110 degrees F, the Stove will go into “Internal Alarm” and the Auger will quit feeding fuel. Once the Stove completes the safety shutdown the #3 LED will start blinking. (Read Frequently Asked Questions for more information)) Element-MF Installation and Operations Stove Page 34...
Page 35 Occasional cleaning of the lens will be needed. The lens easily slides out of the bracket for cleaning. The Reflector may also be cleaned, by gently wiping the reflector with a soft cloth. Element-MF Installation and Operations Stove Page 35...
Page 36 WARNING: The Stove has been Safety Tested by an accredited, independent laboratory. These safety features are designed to protect life and property. Bypassing these features voids all warranties and the safety listing of the Furnace. Element-MF Installation and Operations Stove Page 36...
Page 37: Element-Mf Maintenance
ELEMENT-MF MAINTENANCE NOTE: WHEN YOU FIRST OPERATE YOUR ELEMENT-MF, CHECK TO DETERMINE THE NEEDED CLEANING FREQUENCY. THE ELEMENT-MF REQUIRES A MINIMUM AMOUNT OF DAILY MAINTENANCE. REQUIRED MAINTENANCE DEPENDS LARGELY UPON THE QUALITY OF FUEL BURNED AND THE RATE OF BURN. THE AMOUNT OF DAILY MAINTENANCE WILL INCREASE IF FUEL QUALITY DECREASES AND/OR THE BURNING RATE OF THE FUEL INCREASES.
Page 38 Figure 24 The Daily Maintenance will mainly focus on 4 areas in the Element-MF; removing the clinkers from the ash pan (if needed), dropping the clinker from the burnpot, cleaning the heat exchange tubes and cleaning the glass. A breakdown of this process consists of the following steps: Figure 25 The Coal Rake &...
Page 39 Pull the bottom out in one quick motion and let the clinker drop into the ash pan. Quickly push the bottom in again. To pull out the slide bottom use the Rod Handle tool that came with the unit. Figure 27 Element-MF Installation and Operations Stove Page 39...
Page 40 2. If the Element-MF has been running for an extended period of time on the #5 setting, the clinker will sometimes stick to the burn pot. If that happens, pull the coal rake back out.
Page 41: Periodic Maintenance
Stove. To access the Slide-out Bottom, remove the lower panel and slide the bottom out of the Stove. 3. Clean-Out Ports. The Element-MF has 2 Exhaust Cleanout Ports located in the LEFT AND RIGHT lower corners of the firebox. Remove covers and clean regularly.
Page 42 Periodic cleaning of the exhaust system is required. Under certain conditions chimneys may plug up rapidly. Dirty/High Moisture content Fuel and poor installations require more frequent chimney cleanings. The products of combustion will also contain small Element-MF Installation and Operations Stove Page 42...
Page 43: Yearly Maintenance
Many dealers offer a Service Contract that will cover Yearly Maintenance. Contact your St. Croix Dealer for assistance in maintaining your Element-MF in top condition. Yearly Maintenance is designed to assure Safe Operation, prolong the life of the Element-MF and help preserve its aesthetic appeal.
Page 44: Safe Operation
4. Do not Overfire this unit by tampering with the controls on the unit. Follow all instructions regarding the proper use of this heater. Element-MF Installation and Operations Stove Page 44...
Page 45: Wiring Schematic
2 Amp without the igniter running. The minimum recommended circuit is 15 Amp. A dedicated circuit for the Stove is recommended. CAUTION: The electrical components of the Element-MF are not owner serviceable. Call your dealer for proper diagnosis of electrical problems and service to those components.
Page 46: Troubleshooting & Frequently Asked Questions
TROUBLESHOOTING & FRQUENTLY ASKED QUESTIONS The Element-MF is equipped with the Multi-Fuel Burn System. The Stove is very trouble free in operation when properly maintained and quality fuel is used. When the Stove fails to operate properly, troubleshooting by the operator of the Stove is limited.
Page 47 Stove. It also could be an indication that the Stove is getting plugged and needs a good cleaning. Refer to the section in the manual that covers the Daily, Periodic and Yearly Maintenance of the Stove. Element-MF Installation and Operations Stove Page 47...
Page 48 This gives 2 adjustments increasing the voltage (LED’s 4 & 5) and 2 adjustments decreasing the voltage. (LED’s 1 & 2) The voltage is increased or decreased 2.5 volts with each adjustment. Figure 33 Element-MF Installation and Operations Stove Page 48...
Page 49 Program 2 – 13.0 second cycle time. The LED’s flash twice. This program is for use with Corn, Wheat, Rye, Cherry Pits or Distiller Grain. This program is for use with the Element-MF Program 3 - 11.5 second cycle time. The LED’s flash three times.
Page 50: Parts Breakdown
Element-MF Parts Figure 36 Element-MF Installation and Operations Stove Page 50...
Page 51 Element-MF Parts Figure 37 Element-MF Installation and Operations Stove Page 51...
Page 52 Element-MF Parts Figure 38 Element-MF Installation and Operations Stove Page 52...
Page 53 Element-MF Parts Figure 39 Figure 40 Element-MF Installation and Operations Stove Page 53...
Page 54 Element-MF Parts Sensor System Figure 41 Figure 42 Figure 43 Element-MF Installation and Operations Stove Page 54...
Page 55 CONTROL BOARD HARNESS RESTRAINT NOT USED NOT USED 80P53681-R SLIDE-TOP STANDOFF PLATE ASSEMBLY 80P30045-R SPEAKER TERMINAL 80P52630-R TERMINAL BLOCK 80P30809-R GLASS RETAINER 80P30807-R RIGHT ANGLE SENSOR BRACKET 80P54205-R ADJUSTABLE SENSOR BRACKET ASSEMBLY 80P30948-R PHOTOELECTRIC SENSOR Element-MF Installation and Operations Stove Page 55...
Page 56 NOT USED NOT USED 80P52437-R CONVECTION FAN MOUNT BRACKET 1/4" x 1" FOAM TAPE – 19.5” 8709K46 80P20003-R CONVECTION FAN 80P20132-R DOOR GASKET – 48” 80P20131-R SMALL BRASS COIL 80P53773-R DOOR HANDLE - PAINTED Element-MF Installation and Operations Stove Page 56...
Page 57 10 - 24 X 3/8" BUTTON SOCKET CAP SCREW 80P53677-R MOUNT PLATE ASSEMBLY 8X1/2HWHTEK-B #8 X 1/2" HWH TEK SCREW - BLACK 80P52947-R DOOR WELDMENT 80P52375-R DOOR GLASS 80P20022-R GLASS GASKET – 44” 80P52357-R GLASS RETAINER Element-MF Installation and Operations Stove Page 57...
Page 58: Warranty
ELEMENT-MF WARRANTY The Stove manufactured by Even Temp, Inc. is warranted for five (5) years, to the original owner, against defects and workmanship on all steel parts (excluding the burn grate, Baffle and Brick Panels) and two (2) year on electrical components from the date of sale to the original owner. There specifically is no warranty on the paint, glass and all gaskets.
Page 59: Element-Mf Info & Notes
LED #5 APPROVED FUEL: Circle One CORN WHEAT RYE CHERRY PITS DISTILLERS GRAIN PROGRAM: Circle one (see Figure 19 on page 28) Serial Number: Date of Purchase: Dealer Information: EMAIL: support@stcroixstoves.com WEB ADDRESS: www.stcroixstoves.com Element-MF Installation and Operations Stove Page 59...
