LED Flood Panel 150
LED floodlight
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LED Flood Panel 150 and is the answer not in the manual?

Questions and answers

Related Manuals for STARVILLE LED Flood Panel 150

Summary of Contents for STARVILLE LED Flood Panel 150

  • Page 1 LED Flood Panel 150 LED floodlight user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 17.08.2015, ID: 253358, 253359...

  • Page 3: Table Of Contents

    1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 7 Safety instructions..........................10 Features............................... 15 Installation..............................16 Starting up..............................19 Connections and operating elements................... 22 Operating..............................27 Technical specifications........................43 Plug and connection assignments....................44 Troubleshooting............................45 Cleaning............................... 48 LED Flood Panel 150...
  • Page 4 Table of contents Protecting the environment......................49 LED floodlight...

  • Page 5: General Information

    If you sell the unit please make sure that the buyer also receives this manual. Our products are subject to a process of continuous development. Thus, they are subject to change. LED Flood Panel 150...

  • Page 6: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’ , ‘OFF’ . 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. LED Flood Panel 150...
  • Page 8 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
  • Page 9 General information Warning signs Type of danger Warning – danger zone. LED Flood Panel 150...

  • Page 10: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used as an electronic illumination effect using LED technics. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage.
  • Page 11 Never let children unattended use electrical devices. DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. LED Flood Panel 150...
  • Page 12 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician.
  • Page 13 Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. LED Flood Panel 150...
  • Page 14 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.

  • Page 15: Features

    This LED floodlight is suitable for use in clubs, bars, theatres, exhibitions, etc. Special features of the device: 150 × 10 mm colour LEDs (RGB) Control via DMX and via buttons and display on the unit 10 preprogrammed automatic shows Sound control Master / Slave mode Compact design LED Flood Panel 150...

  • Page 16: Installation

    Installation Installation Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 17 When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand. LED Flood Panel 150...
  • Page 18 Installation NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. Please note that this device must not be connected to a dimmer. LED floodlight...

  • Page 19: Starting Up

    Starting up Starting up Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. LED Flood Panel 150...
  • Page 20 Starting up Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain.
  • Page 21 Connect the DMX output of the master device to the DMX input of the first slave device. Then connect the DMX output of the first slave device to the DMX input of the second slave device and so on. LED Flood Panel 150...

  • Page 22: Connections And Operating Elements

    Connections and operating elements Connections and operating elements Front and rear panel LED floodlight...
  • Page 23 Connections and operating elements 1 LEDs. 2 Locking screws for the bracket for hanging or placement. 3 Vents. 4 Control panel and connections. LED Flood Panel 150...
  • Page 24 Connections and operating elements Control panel and connections LED floodlight...
  • Page 25 8 [Setup] Selects an option of the respective operating mode. 9 [Up] Increases the displayed value by one. 10 [Down] Decreases the displayed value by one. 11 Microphone for sound control. 12 [DMX In] DMX input. LED Flood Panel 150...
  • Page 26 Connections and operating elements 13 [DMX Out] DMX output. 14 [Power Out] IEC chassis socket to feed another device with mains voltage. 15 [Power In] IEC chassis plug for the power cable. Below, the range of the allowable operating voltage is specified. LED floodlight...

  • Page 27: Operating

    Press any button to turn the display back on again. The previously called menu is displayed again. The set values are retained during a power supply interruption. LED Flood Panel 150...
  • Page 28 Operating Operating mode ‘Preprog‐ A preprogrammed automatic show can only be activated when the unit is operating in stand rammed automatic show’ alone mode or as master in a master / slave combination. This setting is only relevant if the device is not controlled via DMX.
  • Page 29 [Setup]. With [Up] and [Down] you can now select one of the colour settings ‘1.––r’ to ‘8.00F’ , see the following table. Value Colour setting ‘1.––r’ ‘2.–rg’ Red + green ‘3.––g’ Green ‘4.–gb’ Green + blue ‘5.––b’ Blue LED Flood Panel 150...
  • Page 30 Operating Value Colour setting ‘6.–rb’ Red + blue ‘7.rgb’ Red + green + blue ‘8.00F’ No function Press again [Setup ] to set the brightness of the colours and the flash frequency for the strobe effect. Depending on the mode, the display shows one of the following values: ‘rxxx’ , ‘gxxx’ , ‘bxxx’...
  • Page 31 Operating mode ‘Slave’ This setting is only relevant if the device is working as Slave in a Master / Slave configuration and is not controlled via DMX. Press [Mode] repeatedly until the display shows ‘SLAv’ . LED Flood Panel 150...
  • Page 32 Operating Sound control Sound control can only be activated when the unit is operating in stand alone mode or as master in a master / slave combination. This setting is only relevant if the device is not con‐ trolled via DMX. Press [Mode] repeatedly until the display shows ‘SU.xx’...
  • Page 33 DMX address for the various DMX modes Mode Highest possible DMX address 3-channel 4-channel 8-channel Press [Setup]. With [Up] and [Down] you can now select one of the following DMX operating modes: ‘3-ch’ (three channels) ‘4-ch’ (four channels) ‘8-ch’ (eight channels) LED Flood Panel 150...
  • Page 34 Operating Functions in 3-channel DMX mode Channel Value Function 0…255 Intensity Red (0 %…100 %) 0…255 Intensity Green (0 %…100 %) 0…255 Intensity Blue (0 %…100 %) Functions in 4-channel DMX mode Channel Value Function 0…255 Dimmer (0 %…100 %) 0…255 Intensity Red (0 %…100 %) 0…255...
  • Page 35 If channel 6 = 1…24: Constant colour, hue is defined via channel 2 0…8 Red: 255 9…17 Red: 255, Green: 50 18…26 Red: 255, Green: 150 27…35 Red: 255, Green: 255 36…44 Red: 200, Green 255 45…53 Red: 100, Green: 255 LED Flood Panel 150...
  • Page 36 Operating Channel Value Function 54…62 Red: 40, Green: 255 63…71 Green: 255 72…80 Green: 255, Blue: 50 81…89 Green: 255, Blue: 150 90…98 Green: 255, Blue: 255 99…107 Green: 150, Blue: 255 108…116 Green: 50, Blue: 255 117…125 Blue: 255 126…134 Red: 50, Blue: 255 135…143...
  • Page 37 Red: 220, Green: 200, Blue: 100 243…251 Red: 255, Green: 200, Blue: 150 252…255 Red: 255, Green: 255, Blue: 255 If channel 6 = 25…249: Programme progress speed 0…255 Slow…fast If channel 6 = 250…255: Sound control response characteristic LED Flood Panel 150...
  • Page 38 Operating Channel Value Function 0…255 Slow…fast 0…255 Intensity Green (0 %…100 %), if channel 6 = 0 0…255 Intensity Blue (0 %…100 %), if channel 6 = 0 0…9 No function 10…255 Strobe effect flash frequency, slow…fast RGB mix, constant, colour setting via channel 2…4 1…24 Constant colour, setting via channel 2 25…49...
  • Page 39 Programme Pr10, fading blue only 250…255 Sound control You can directly control single or multiple devices of a group via channel 7 by assigning the same ID. 0…9 ID1…ID66 10…19 20…29 30…39 40…49 50…59 60…69 70…79 LED Flood Panel 150...
  • Page 40 Operating Channel Value Function 80…89 90…99 100…109 ID10 110…119 ID11 120…129 ID12 130…139 ID13 140…149 ID14 150…159 ID15 160…169 ID16 170…179 ID17 180…189 ID18 190…199 ID19 200…209 ID20 LED floodlight...
  • Page 41 Operating Channel Value Function ID21 ID22 ID23 … … ID65 ID66 0…250 No function 251…255 Delayed LED power-up LED Flood Panel 150...
  • Page 42 Operating Menu overview LED floodlight...

  • Page 43: Technical Specifications

    48 × red, 10 mm 51 × green, 10 mm 51 × blue, 10 mm Dispersion angle LED Flood Panel 150 20°, item no. 235358: 20° LED Flood Panel 150 40°, item no. 235359: 40° Number of DMX channels 3, 4, 8 Operating supply voltage 100 ...

  • Page 44: Plug And Connection Assignments

    Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...

  • Page 45: Troubleshooting

    Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: LED Flood Panel 150...
  • Page 46 Troubleshooting Symptom Remedy The unit does not work, no light Check the mains connection and the main fuse. No response to the DMX con‐ 1. If the unit is in DMX mode and a DMX controller is troller connected and turned on, the LED (6) behind the first digit of the display will flash.
  • Page 47 2. Move the remote control closer to the unit. 3. Check the remote control battery. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. LED Flood Panel 150...

  • Page 48: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.
  • Page 49 Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. LED Flood Panel 150...
  • Page 50 Notes LED floodlight...
  • Page 52 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
