- Page 1 VLB7IR Waterproof Infrared Illumination Camera Instruction Manual VER.:1.0, NO.: R040557A/2-MN...
- Page 2 Thank you very much for purchasing our product. Before operating this product, please read this instruction manual carefully to ensure proper use. 1. Safety Precautious CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE.
- Page 3 3. Feature Built-in high quality CCD camera and high performance infrared illuminator module. Pixel number: NTSC=480K/ PAL=570K for ultra high resolution, NTSC=380K/ PAL=440K for high resolution, and NTSC=250K/ PAL=290K for normal resolution models. High sensitivity, low smear, excellent anti-blooming and high S/N ratio. ...
- Page 4 5. Installation & Operation 1. Install Preparation Drill holes on wall if wires need to go through the wall. 2. Install Camera Use the 3 screws provided to attach the camera and bracket to the ceiling, surface or wall.
- Page 5 3. Adjust 3-Axis Bracket Adjust the bracket while checking the view angle from the monitor. Loosen the bracket lock knob by turning counterclockwise, after adjusting the 3-Axis bracket (X-Y-Z Axis) to get the desired viewing angle, tighten the lock knob by turning it clockwise. 4.
-
Page 6: Specifications
6. SPECIFICATIONS According to the camera purchased, select and refer to the appropriate specification below: 1/3” SONY SUPER HAD II Image Device NTSC: 976x494 Pixel Elements PAL: 976x582 Resolution 700 TVL Min Illumination 0.01Lux/ F1.2 S/N Ratio More than 48dB NTSC: 1/60S~1/100,000S Electronic Shutter PAL: 1/50S~1/100,000S...
