Summary of Contents for ELECTROCOMPANIET ECD 2
- Page 1 ECD 2 High Performance Balanced DAC 24 Bit /192kHz Owner's Manual...
- Page 2 Unpacking the ECD 2 Immediately upon receipt of the ECD 2, inspect the carton for possible dam- age during shipment. If the carton is visibly damaged, a claim must be filed with the carrier as soon as possible. Unpack the unit carefully, and please do remember to save all packaging materials for future shipment.
-
Page 3: Trigger Input/Output
The USB input accept sources up to 24bit/192kHz. Connect a PC/Mac/ Linux computer using a standard type A-B USB cable. ECD 2 will show up as a sound device on your computer. Please select ECD 2 as the active device to enable playback through ECD 2. On Windows drivers are needed. -
Page 4: Navigator Window
If the ECD 2 has been switched off, allow two hours of warm-up for optimal sonic performance. When the ECD 2 is not to be used for a long period of time, use the main switch to turn the unit off. Then discon- nect the AC main cord for maximum safety. -
Page 5: Remote Control Illustration
Remote control illustration 9 10 1. Vol. Down - Press to decrease the volume. 2. Arrow down – Press to decrease the volume. 3. Arrow left – Previous input. 4. Arrow up – Increase the volume level. 5. Double arrow left – no function. 6. - Page 6 Technical specifications ECD 2 The following technical data were measured on randomized test objects and are typical data. All measurements are made at 120V / 240V // 50Hz / 60Hz No. of channels................2 Output Impedance............300 Ohms Output level (Balanced)............4.6 Vrms Output level (Single-ended...........2.3 Vrms...
- Page 7 ECD 2 Front panel illustration...
- Page 8 ECD 2 back panel illustration...
- Page 9 How to connect your system...
-
Page 10: Important Notice
For optimal sonic performance, the ECD 2 should be burned in for a minimum time of 72 hours. If the ECD 2 has been switched off, allow two hours of warm-up for optimal sonic performance. It is normal for the ECD 2 to feel warm. - Page 12 Verify line voltage before use. Do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personal. The warranty is void if the product is tampered with by non-authorised personnel. Use only authorized Electrocompaniet service center. Made in Norway www.electrocompaniet.no...
