Wild Country
Renaissance Series
Barbecue
Four Seasons 5 Burner
Operating and Assembly Instructions
Read the following instructions carefully and be sure your barbecue is
properly installed, assembled and cared for.
Failure to follow these instructions may result in serious bodily injury and/or
property damage.
If you have questions concerning assembly or operation, consult your dealer,
gas appliance service person or your LP Gas supplier.
Note to Installer – Leave these instructions with the consumer after
installation.
Note to Consumer – Retain these instructions for future reference.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wild Country Renaissance Tuscany 4 and is the answer not in the manual?

Questions and answers

Related Manuals for Sure Heat Wild Country Renaissance Tuscany 4

Summary of Contents for Sure Heat Wild Country Renaissance Tuscany 4

  • Page 1 Wild Country Renaissance Series Barbecue Four Seasons 5 Burner Operating and Assembly Instructions Read the following instructions carefully and be sure your barbecue is properly installed, assembled and cared for. Failure to follow these instructions may result in serious bodily injury and/or property damage.

  • Page 2: General Information

    GENERAL INFORMATION GAS INSTALLATION CODES Barbecues must be used in accordance with the installation requirements of your gas supply authority, or the appropriate installation code issued by the Australian Gas Association or relevant authority. Barbecues for use with bottled (LPG) gas are labelled LPG or Propane Gas. Check the gas type sticker affixed to your barbecue.

  • Page 3: Specifications

    SPECIFICATIONS Barbecue specifications can be found on the data label attached to the barbecue. WARNING !I- YOU SMELL GAS 1. SHUT OFF THE GAS SUPPLY TO THE BARBECUE AT THE CYLINDER VALVE 2. EXTINGUISH ANY OPEN FLAME 3. REMOVE LID OR OPEN HOOD 4.
  • Page 4 Tools Required – 1 Phillips Screwdriver 2 x 10cm adjustable spanners REMOVE ALL TRANSIT PACKAGING PRIOR TO ASSEMBLY STEP 1 - Insert the Flavor Grids into the cut outs with triangle ridges facing up. Make sure the flavor grid with the long side is installed next to the bottom IR burner. STEP 2 - Install Main Cooking Grates on the ledges provided on the grill to create your cooking surface.
  • Page 5 STEP 3 - Rest bread warming grate on four (4) slots above cooking grid. STEP 4 - Pull out the drawer, you will find the igniter battery housing on the left side. Unscrew the black cap and feed the "AA" battery into the igniter with the Positive (+) end facing out. Screw the cap back into palce on the battery housing.
  • Page 6 STEP 5 - Remove any labels and additional packing material from the grill. Be sure to clean all foam packing material out of all areas. Congratulations! Your grill is now fully assembled. Please proceed and read the Gas Requirements and Operation portion of the Use and Care Manual before attempting to hook up the LP gas cylinder or operating your grill.

  • Page 7: General Assembly

    General Assembly Connecting and Disconnecting to Gas Cylinder WARNING ! - BEFORE CONNECTING AND DISCONNECTING BARBECUE TO GAS CYLINDER, ENSURE ALL CONTROLS ARE IN THE OFF POSITION. FOR STORAGE AND CYLINDER EXCHANGE, DISCONNECT HOSE AT THE CYLINDER ONLY, DO NOT DISCONNECT HOSE FROM APPLIANCE Check 1.

  • Page 8: Operating Procedure

    General Assembly WARNING! FAT CUP MUST BE EMPTIED PRIOR TO USE. Burner Operation and Ignition Check 1. Ensure roast hood is OPEN. 2. With burner controls in OFF position, turn on gas cylinder valve. 3. Upon first assembly, the gas lines and burners will be full of air. In order for the burners to operate properly, the lines must fill with gas.

  • Page 9: Care And Maintenance

    Operating Procedure Cooking with the Hood Down Cooking with the hood in the closed position helps to cook the food more quickly than conventional open barbecues. The hood (when closed) helps retain the heat more evenly and conserves energy. High direct heat on the cooking surface when the hood is down will result in burnt food.

  • Page 10: Specification

    Specification MODEL Wild Country Renaissance Tuscany 4 NOMINAL GAS CONSUMPTION 76 Megajoules per hour INLET PRESSURE 2.75 kPa GAS TYPE PROPANE AGA APPROVAL No. 7210 DATE OF MANUFACTURE mm/yy SIDE CLEARANCE 100cm BACK CLEARANCE 100cm...
  • Page 11 APPENDIX 1 Examples of an Outdoor Area.
  • Page 12 APPENDIX 1...
  • Page 13 APPENDIX 1 Examples of an Outdoor Area. THIS APPLIANCE SHALL ONLY BE USED IN AN ABOVE GROUND OPEN- AIR SITUATION WITH NATURAL VENTILATION, WITHOUT STAGNANT AREAS, WHERE GAS LEAKAGE AND PRODUCTS OF COMBUSTION ARE RAPIDLY DISPERSED BY WIND OR NATURAL CONVECTION. ANY ENCLOSURE IN WHICH THE APPLIANCE IS USED SHALL COMPLY WITH ONE OF THE FOLLOWING An enclosure with walls on all sides, but at least one permanent opening at...
