- Page 1 Lot:_____________ PO:_____________ Model # 2950 Sonoma Outdoor Fireplace Instruction Manual...
- Page 2 WARNINGS Read entire label and all instructions included with Ventless Fireplace Fuel and fireplace PROPERTY DAMAGE, SERIOUS INJURY OR DEATH result if these warnings are not followed HAZARDS Ventless Fireplace Fuel is flammable. Failure to follow warnings can result in property damage or serious burns. Do not attempt to refill a fire that is already burning.
- Page 3 Parts List Base 29500001 Door Glass 29500010 Foot 29500002 Hood 29500011 Trough 29500012 Drip Pan 29500003 Left Front Support 29500004 Log 1 29500013 Left Rear Support 29500005 Log 2 29500014 Right Rear Support 29500006 Log 3 29500015 Right Front Support 29500007 Cover 29500016...
- Page 4 Place the Base (1)upside down as shown. Attach a Foot (2) in each corner of the base using two screws (A). Attach the Drip Pan (3) to the base using four screws (A).
- Page 5 Place the Right Rear Support (6) over the left rear bracket on the base as shown so that the support leans in towards the center of the base. Locate the Rear Glass (8) and Right Front Support (7). With one hand insert the glass into the Right Rear Support (6) and with the other hand insert the Right Front Support (7) onto the right side of the glass.
-
Page 6: Hood
Locate the Left Front Support (4) and the Side Glass (9). With one hand place the Side Glass (9) into the slit in the Right Front Support (7) and with the other hand place the Left Front Support (4) onto the Side Glass (9). Set the Front Right Support down over the bracket on the base. -
Page 7: Door Glass
Attach the Door Glass (10) to the hinges on the Left Rear Support (5). Place a rubber washer on both sides of the holes in the Door Glass (10). Insert the cap into the hole in the glass and attach with a screw (B). Insert troughs (12) into the openings in the base. - Page 8 Place Logs (13,14 and 15) onto the base. Place logs in line with the openings in the base as shown. After placing the three logs spread out the Lava Rock (17) to cover the rest of the base. NOTE: Make sure you remove any lava rocks that fall into the troughs.
-
Page 9: Log
Using The Fuel With the troughs placed in the unit ll each trough to the top of the post in the trough or 3/4” from the lip of the trough. CLEAN UP ANY SPILLED FUEL PRIOR TO LIGHTING. Real Flame® Ventless Lighting Fireplace... - Page 10 Adjustment & Extinguishing Closed You may adjust the ames simply by pulling the damper out part way with tool until desired intensity is reached. Using with damper partially open will result in a longer burn time, while a fully open damper will provide a larger ame.
-
Page 11: Log.
Care and Cleaning - continued Burn troughs should be cleaned every two to three burns. This can be done with the included scraper tool. - ALLOW TROUGH TO COOL COMPLETELY (20 minutes) BEFORE ATTEMPTING TO CLEAN. - Using edge of tool, carefully scrape away any residue from sides and bottom of trough. - Page 12 Warranty & Return Policies Warranty Jensen Metal Products, Inc., doing business as Real Flame®, warrants Real Flame vent-less fireplaces and accessories to be free from defects in parts and workmanship under normal use and service for a period of 90 days from the date of purchase. In the event of such defects Real Flame will, at its option, replace the defective product or refund the purchase price.
