Summary of Contents for EZ Heat Basic

  • Page 1 Basic Installation Manual READ THIS MANUAL BEFORE INSTALLATION...
  • Page 2 It should be as close to the pool as practical. There are three EZ Heat Basic solar system models. All are 4 feet wide. Basic 12 is twelve feet long, Basic 20 is twenty feet long and Basic 25 is twenty five feet long.
  • Page 3 Follow figure 2 or figure 3 in making the water connections to the pool, depending on whether or not using a control valve. Connections to the pool filter system may be made either with 1 ½ inch filter hoses or 1 ½ inch schedule 40 PVC pipe and fittings.
  • Page 4 (Or sufficient pipe and fittings.) b. An EZ Heat Hose Connection Kit or adapter fittings. Use part #1005 for connecting to 1-1/2” hoses. If you are using rigid pipe connections, connect to the piping with 1½...
  • Page 5 other hose from the other solar system fitting to the return fitting at the pool. Use the stainless steel hose clamps in the Hose Connection Kit and tighten them securely. If the solar system is mounted on a roof higher than the pool, a check valve part #3039 must be installed as shown in Figure 3 to prevent filter back-washing when the water in the system drains back to the pool.
