Summary of Contents for Mito 20-CS-110
- Page 1 20-CS-110 SIDE-VIEW FOR VEHICLE Thank you for purchasing this product. For proper usages and application, Please read this instruction manual thoroughly. INSTRUCTION MANUAL ver. 1.0 PRINTED IN KOREA ※ Design and specifi cations could be changed without notices.
- Page 2 CONTENTS Safety Rules ..................4 1. Features ..................5 2. Box Contents ................5 3. Installation .................. 6 4. Connection ................. 8 5. Cleaning & General maintenance ........9 6. Specifi cations ................9...
-
Page 3: Box Contents
SAFTY RULES FEATURES Please read the “Safety Rules” carefully before using this product. Following the (LENS) safety rules prevents users from damages related with the misuse of the product. ■ 1/4” IT COLOR CCD image sensor It is very important to follow these safety rules. We state “Caution” and “Warning” ■... - Page 4 INSTALLATION ※ Based on the condition and place, the installation procedures ⑥ could be varied. ⑤ (1) Verify the position of ‘TOP’ which should be upper side ⑦ and fi x it to the lens bracket with screws. MACHINE SCREW M3.0 X 4 (1ea) TAPPING SCREW T2 M3.0 X 6 (2ea) ⑧...
- Page 5 CONNECTION CLEANING & GENERAL MAINTENANCE ※ If your vehicle has been parked in direct sun light resulting in a considerable Side Camera rise in temperature inside the vehicle, allow the unit to cool off before operating. CLEANING Unplug or power off mode before cleaning. Do not use liquid cleaners or aerosol ceaners.
- Page 6 MEMO MEMO...
