TECHNICAL & SERVICE MANUAL
OUTDOOR UNIT : CU-3KS19NBU
DC INVERTER MULTI-SYSTEM AIR CONDITIONER
CU-3KS19NBU
CU-4KS24NBU
CU-4KS31NBU
CU-4KS24NBU
CU-4KS31NBU
Capacity at 230V
Outdoor Model No.
19,700 BTU/h
CU-3KS19NBU
CU-4KS24NBU
25,400 BTU/h
CU-4KS31NBU
30,600 BTU/h
Product Code No.
1 852 361 24
1 852 361 25
1 852 361 26
< Applicable Indoor Units >
Wall mounted type
CS-MKS7NKU
CS-MKS9NKU
CS-MKS12NKU
CS-MKS18NKU
CS-MKS24NKU
Semi-concealed type
CS-MKS9NB4U & CZ-18BT1U
CS-MKS12NB4U & CZ-18BT1U
CS-KS18NB4UW & CZ-18BT1U
IMPORTANT
These air conditioners employ new
refrigerant R410A.
Pay special attention when
servicing the unit.
REFERENCE NO.
SM
700877
