215-1814 Rev. C; ECN 150010
© 2015 Keltech
Page 1 of 20
7/13/2015
Installation
CNA-Series
Tankless Heater Models
CNA-36
CNA-54
CNA-63
CNA-72
CNA-108
CNA-126
CNA-144
CNAR-108
CNAR-126
CNAR-144
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Storage Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mounting Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Plumbing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electric Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Start Up Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Digital Controller Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operational Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
Product Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
Special Installation & Operating Instructions . . . . . . . . . . 17-20
