  • Page 2 Selftrack Nitro Vehicle Tracker User & Installation Manual GENERAL Terms of use of new materials – please read carefully From time to time, Enfora, in its sole discretion, may make available for download on its website (www.enfora.com), or may transmit via mail or email, updates or upgrades to, or new releases of, the firmware, software or documentation for its products (collectively, “new materials”).
  • Page 3 The modem was tested and certified to meet FCC Parts 15 in a stand-alone configuration, which demonstrated that the GSM2338 Nitro complies with Part 15 emission limits. FCC Part 22 & Part 24 is covered by the Enfora Enabler IIIG “modular approval”...
  • Page 4 Selftrack Nitro Vehicle Tracker User & Installation Manual the returned product, Enfora does not substantiate the defect claimed by purchaser, or determines that the defect is not covered under this limited warranty, Enfora will not be required to repair or replace the product, but may instead reship the product to the purchaser, in which case purchaser shall be responsible for paying Enfora’s usual charges for unpacking, testing and repacking...

  • Page 5: Table Of Contents

    Figure 7 - SIM Slot and SIM Lock ......................10 Figure 8 - Power Cable Installation ....................... 11 Figure 9 – LED Operation ........................12 Figure 10 – Standard Nitro wiring diagram.................... 14 List of Tables Table 1 – Battery Specifications………..…………………………...………………………………………...7 Table 2 –...

  • Page 6: Objective

    Installation voucher • Note: Your tracking device has been pre-setup, configured and provisioned on the Selftrack network and only requires the unique Device Code to complete registering it on your profile. Please keep this code secret and hide in a safe place in order to prevent any unauthorized monitoring of your device.

  • Page 7: Battery Specifications

    Align the Nitro in the drilled holes and secure it with mounting screws. Warning: The Nitro is NOT a waterproof or sealed device. Care must be taken to ensure the device is kept away from water or any other liquids.

  • Page 8: Mounting Dimensions

    Selftrack Nitro Vehicle Tracker User & Installation Manual Mounting Dimensions It is possible to mount the Nitro using either screws, or plastic mounting rails with tie- downs. Figure 3 - Mounting Dimensions Alternatively, the device may also be secured with the use of “sticky putty” or similar material, provided it is strong enough to be held in place without coming loose due to vibration (especially when used in heavy vehicles and off-road equipment).

  • Page 9: Connecting The Gps Antenna

    The Nitro has the capability of providing 3.3V to power an Active-Style GPS antenna. The GPS antenna connector on the Nitro model is a FAKRA Blue connector. The GPS antenna must be placed facing upwards in an area where it can have direct view of the sky.

  • Page 10: Inserting The Sim And Applying Power

    GPRS and/or voice, and the PIN is/must be disabled. Always take care to protect the SIM. Without the SIM installed, the Nitro modem is limited to emergency voice communication only. Please always ensure the SIM lock is ON in order to prevent accidental removal.

  • Page 11: Power Cable Installation

    Connecting the Power Source The GSM/GPRS Nitro has an input voltage range of 7 – 40 V DC. The power and ignition pins can support 7 -40 V DC input voltage. The user has an option to connect these wires depending on the desired functionality. Described below are the desired...

  • Page 12: Led Operation

    Selftrack Nitro Vehicle Tracker User & Installation Manual Warning: The Nitro is designed to operate from 7 to 40 VDC. The user is responsible for ensuring the voltage supplied to the Nitro remains in this voltage range to include transient voltage spikes and load dump voltages.

  • Page 13: General Notes On Installing Cables And Wiring

    ON event trigger could be missed on occasion. Standard Selftrack Nitro Installation configuration The eight (8) pin external I/0 and power harness connector for the Selftrack Nitro is included in the package. Table 1 below describes the pin functionality.

  • Page 14: Figure 10 - Standard Nitro Wiring Diagram

    Pin-7 User Controlled I/0 Pin-8 User Controlled Output Table 3 - 8 Pin I/0 Connector The Nitro allows the user the following functions: Battery Tamper Alert (built-in) • Ignition ON / OFF (PIN 5) • Panic Button (PIN 6, User I/O 1) •...
