SPLIT TYPE ROOM AIR CONDITIONER

INSTALLATION MANUAL

(PART NO. 9312791019-01)
This air conditioner uses new refrigerant HFC (R410A).
The basic installation work procedures are the same as conventional refrigerant (R22) models.
However, pay careful attention to the following points:
(1) Since the working pressure is 1.6 times higher than that of conventional refrigerant(R22) models,
some of the piping and installation and service tools are special.(See the table below.)
Especially, when replacing a conventional refrigerant(R22) model with a new refrigerant R410A
model, always replace the conventional piping and flare nuts with the R410A piping and flare
nuts.
(2) Models that use refrigerant R410A have a different charging port thread diameter to prevent
erroneous charging with conventional refrigerant(R22) and for safety. Therefore, check
beforehand.[The charging port thread diameter for R410A is 1/2 threads per inch.]
(3) Be more careful that foreign matter (oil, water, etc.) does not enter the piping than with refrigerant
(R22) models. Also, when storing the piping ,securely seal the opening by pinching ,taping, etc.
(4) When charging the refrigerant, take into account the slight change in the composition of the
gas and liquid phases, and always charge from the liquid phase side whose composition is
stable.

Special tools for R410A

Tool name
Gauge manifold
Charge hose
Vacuum pump
Gas leakage detector
Copper pipes
It is necessary to use seamless copper pipes and it is desirable
that the amount of residual oil is less than 40 mg/10m. Do not
use copper pipes having a collapsed, deformed or discolored
portion (especially on the interior surface). Otherwise, the
expansion value or capillary tube may become blocked with
contaminants.
As an air conditioner using R410A incurs pressure higher than
when using R22, it is necessary to choose adequate materials.
Thicknesses of copper pipes used with R410A are as shown in Table1.Never us copper pipes thinner than 0.8mm even
when it is available on the market.
(1) Do not use the existing (for R22) piping and flare nuts.
• If the existing materials are used, the pressure inside the refrigerant cycle will rise and cause breakage, injury,
etc.(Use the special R410A materials.)
(2) When installing and relocating the air conditioner, do not mix gases other than the specified refrigerant(R410A)
to enter the refrigerant cycle.
• If air or other gas enters the refrigerant cycle, the pressure inside the cycle will rise to an abnormally high value
and cause breakage, injury, etc.
Pressure is high and cannot be measured with a conventional gauge. To prevent erroneous
mixing of other refrigerants, the diameter of each port has been changed.
It is recommended the gauge with seals-0.1 to 5.3 MPa (-1 to 53 bar) for high pressure.
-0.1 to 3.8 MPa (-1 to 38 bar) for low pressure.
To increase pressure resistance, the hose material and base size were changed.
A conventional vacuum pump can be used by installing a vacuum pump adapter.
Special gas leakage detector for HFC refrigerant R410A.
Contents of change
Table 1 Thicknesses of Annealed Copper Pipes
Nominal
diameter
1/4
3/8
WARNING
Thickness (mm)
Outer diameter
R410A
(mm)
6.35
0.80
9.52
0.80
[ref.] R22
0.80
0.80

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9312791019-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Orion Air 9312791019-01

  • Page 1: Installation Manual

    SPLIT TYPE ROOM AIR CONDITIONER INSTALLATION MANUAL (PART NO. 9312791019-01) This air conditioner uses new refrigerant HFC (R410A). The basic installation work procedures are the same as conventional refrigerant (R22) models. However, pay careful attention to the following points: (1) Since the working pressure is 1.6 times higher than that of conventional refrigerant(R22) models, some of the piping and installation and service tools are special.(See the table below.)
  • Page 2: Selecting The Mounting Position

    SELECTING THE MOUNTING INSTALLATION DIAGRAM OF POSITION INDOOR AND OUTDOOR UNITS Decide the mounting position with the customer as follows: 1. INDOOR UNIT Fig. 2 (1) Install the indoor unit level on a strong wall which is not subject to vibration.
  • Page 3: Indoor Unit

    INDOOR UNIT CUTTING THE HOLE IN THE WALL FOR THE CONNECTING PIPING (1) Cut a 65 mm diameter hole in the wall at the position shown in (Fig. Fig. 4 Centering marks Wall hook bracket (2) When cutting the wall hole at the inside of the installation frame, cut the hole within the range of the left and right center marks 40 mm below the installation frame.
  • Page 4: Connecting The Piping

    For left piping and left rear piping, align the marks on the wall hook Fig. 7 bracket and shape the connection pipe. Bend the connection piping at the bend radius of 70 mm or more and install no more than 35 mm from the wall. After passing the indoor piping and drain hose through the wall hole, Wall hook bracket hang the indoor unit on the hooks at the top and bottom of the wall...
  • Page 5: Standard Accessories

    For authorized service personnel only. WARNING (1) For the room air conditioner to operate satisfactory, install it as outlined in this installation manual. (2) Connect the indoor unit and outdoor unit with the air conditioner piping and cords available standards parts. This installation manual describes the correct connections using the standard accessories and the parts specified in this installation manual.
  • Page 6: Front Panel Removal And Installation

    FRONT PANEL REMOVAL AND INSTALLATION REMOVING THE INDOOR UNIT HOUSING Fig. 20 (1) Remove the two screw caps, and then remove the two lower tapping screws. (2) Open the front panel, and then remove the front cover. Indoor unit (3) Remove the four upper tapping screws. housing (Note: One tapping screw is located behind the front cover.) (4) Unhook the indoor unit housing from the center projection and remove.
  • Page 7: Outdoor Unit Installation

    OUTDOOR UNIT OUTDOOR UNIT INSTALLATION WARNING Set the unit on a strong stand, such as one made of concrete blocks to minimize shock and vibration. (1) Install the unit where it will not be tilted by mor Do not set the unit directly on the ground because it will cause trou- than 5°.
  • Page 8: Outdoor Unit Wiring

    OUTDOOR UNIT WIRING (1) Remove the outdoor unit connector cover. (5) Fasten the sheath with a cord clamp. (2) Remove the control box cover. (6) Install the control box cover. (3) Bend the end of the cord as shown in the figure. (7) Install the connector cover.
