Installation instructions, accessories

Volvo Car Corporation Gothenburg, Sweden

Instruction No

Version

30756561

1.1

Part. No.

30756181, 30756569

TV receiver, digital

TV receiver, digital- 30756561 - V1.1

Page 1 / 29

Need help?

Do you have a question about the 30756181 and is the answer not in the manual?

Questions and answers

Summary of Contents for Volvo 30756181

Page 1 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Instruction No Instruction No Version Version Part. No. Part. No. 30756561 30756561 30756181, 30756569 30756181, 30756569 TV receiver, digital TV receiver, digital © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1...
Page 2 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Equipment A0000162 A0000165 IMG-239981 IMG-239664 IMG-317204 © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1 Page 2 / 29...
Page 3 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-213320 © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1 Page 3 / 29...
Page 4 Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. Note! When installing Digital TV-receiver on car with existing RSE- system, start by changing the cable harness for the tunnel console.
Page 5 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the panel for the front seat mountings of the second row's right seat/centre seat by pressing down the pawls (1) on top and pulling the panel forward. Remove the screw for the right seat.
Page 6 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Loosen the upper part of the sill moulding at the rear edge and loosen the seat belt from the end-fitting. The belt is loosened by carefully pressing with a weatherstrip tool on the lock lug so that it releases from the end-fitting.
Page 7 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the rear roof panel covers and the screws beneath them. Carefully pry away the panel at the rear edge with a plastic weatherstrip tool. Pull the rear edge of the panel downwards until the four clips on the top have released.
Page 8 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Carefully loosen the pillar panel. Start at the top and continue downwards until the three clips on the inside have released. Remove the connector on the D-pillar panel. Cars with D-pillar speakers have the connector located on the speaker.
Page 9 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the three screws on the battery holder and lift it out. Remove the battery cover. R3100130 Remove both covers on the floor. IMG-242241 Remove both panels. IMG-242242 © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1...
Page 10 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fold out the load lashing eye on the right side. Take a scriber or special tool part no.9995919 and insert the angled point in the hole in the top edge of the cover.
Page 11 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the two clips. IMG-317383 Install plastic nuts in the holes where the clips were located, as shown. Note! Turn the plastic nut so that it faces the right way. IMG-317384 © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1...
Page 12 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the cover panel under the tail lamps on the right and left sides by carefully prying them loose using a weatherstrip tool. R8600873 Loosen the rear fog light at the front with a weatherstrip tool.
Page 13 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take antenna and holder from the kit. Place the antenna in the casing and the cable in the slot. Snap together the casing's top and bottom parts. Done twice. IMG-317470 Install the holders on the casing.
Page 14 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Route the cable up through the bumper so that it comes out at the top of the plastic console. IMG-317474 Remove the top part of the foam tape that covers the hole.
Page 15 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Get the rubber bushing from the kit and open it up with expander pliers. Insert the antenna cable. Route the cable so that the length of the cable between the bushing and the top of the plastic console is 250 mm.
Page 16 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Install the strip clamp on the sheet metal flange. Clamp down the antenna cable in the clamp. Cut off any excess strip clamp. Carry out on both sides. IMG-317479 Connect the removed antenna cable.
Page 17 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Route the antenna cable along existing cable harness over to the right side through the hole in the polystyrene plastic under the right member. IMG-317551 Fasten the cable with strip clamps. IMG-317503 ©...
Page 18 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Get TV-tuner, console, as well as four screws from the kit. Tighten down the tuner on the console. IMG-317504 Take the cable harness from the kit. Plug in the connectors in the order as shown.
Page 19 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fasten the console with screws from the kit. Note! Cut away a piece of insulation for the lower attachment. IMG-317508 Install the strip clamp on the tuner's sheet metal flange. Clamp down the antenna cables.
Page 20 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fold aside the noise absorbent so that the sheet metal flange is visible. Install the strip clamp on the sheet metal flange. Clamp down both cables (1). Fold back the noise absorbent.
Page 21 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fasten the cable harness in the belt anchor with strip clamp. IMG-317512 Fold up the floor mat. IMG-317513 Place the cable harness between polystyrene plastic and body under the floor mat so that it runs along the floor sides on to the tunnel.
Page 22 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Install the strip clamp on the sheet metal flange. Fasten the cable harness. IMG-317523 Install the strip clamp around the cable harness by the yellow marking and press to fasten the clamp on the parking brake console's flange.
Page 23 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the belt holder and rough up the fabric where the holder has been installed. IMG-317526 Remove the rear cup holder. IMG-317528 © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1...
Page 24 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Illustrations A and B Measure and mark out on the inside of the side panel as shown. Saw according to markings. IMG-317530 IMG-317531 File down the edges. IMG-317532 © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1...
Page 25 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Saw by the side panel's rear cup holder as shown. IMG-317533 File down the edges. IMG-317534 Take the casing from the kit. Mark out the middle on the three flanges with a scribe.
Page 26 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fasten tape as shown. IMG-317543 Temporarily install the casing. IMG-317544 Mark the casing's three drilled holes on the tape. Remove the cover. IMG-317545 © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1...
Page 27 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Punch holes in the markings and through the panel with an awl or scribe. Remove the tape. Drill holes using a 7 mm bit. IMG-317546 Install the casing. Check from the rear that the four catches have engaged.
Page 28 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Loosen the insulation at the top and on the sides. Note! The insulation shall be left in place at the bottom. IMG-317548 Tighten down the casing with three screws PF5x14 and three washers.
Page 29 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden © Volvo Car Corporation TV receiver, digital- 30756561 - V1.1 Page 29 / 29...
