- Page 1 Digital Music Player For 2001-2010 Honda GL-1800 Part #JMDM-IPAX-GL18 Installation & Operating Instructions...
- Page 2 • SD card reader/writer • Velcro strips for mounting Note: The DIP switches on the JMDM-IPAX-GL18 are set at the factory to the ON position and all four switches must be left ON in order for the digital music player to function correctly.
- Page 3 4. Locate the white 14 pin plug located in the black rubber boot next to the cross-member and relay box under the seat. Diagram B 5. Plug the white 14 pin connector from the JMDM-IPAX-GL18 harness into the corresponding plug on the bike. NOTE: The cable must be routed under the cross member to prevent damage to the cable.
- Page 4 SD card will not be heard, until the aux cable is unplugged. 9. Test the JMDM-IPAX-GL18 by inserting the supplied SD card. Turn the ignition switch to either the on or ACC position and select CD on the stereo.
- Page 5 General Tips for Use with SD Card For the 2001-2005 GL-1800, it usually works best to limit the # of folders to 5, plus the root, with no more than 45 files/tracks per folder, using a 4Gb (max) SD card. 2006-2010 GL-1800s will support up to 8 folders, plus the root and up to 99 files/tracks per folder, using an SD card up to 8Gb in size.
- Page 6 3. Now find the SD card or USB thumb-drive (designated as Disk (I): in this example) 4. Click on the Removable Disk (I): and you should now have an open folder, this is also known as the Root Folder. 5. At this point Music can be added to the SD Card or USB Thumb-Drive. You will need to locate your MP3 or WMA files on your computer.
- Page 7 2006-2010 GL-1800s will support up to 8 folders, plus the root and up to 99 files/tracks per folder, using an SD card up to 8Gb in size. These folders can be named as you choose but these names will not display on the Honda Radio, only the CD Disk number will be displayed.
- Page 8 WARRANTY AND REPAIR INFORMATION TWO YEAR LIMITED WARRANTY In order to facilitate the servicing of this warranty, the Warranty Registration Form should be filled out and returned within 10 days of the date of purchase. However, return of the Warranty Registration Form is not a precondition of this warranty, and this Warranty will be observed by J&M CORPORATION whether or not the Warranty Registration Form is returned, on the condition that other satisfactory evidence of the date of the original purchase is provided to J&M CORPORATION.
