Aetos 700w User Manual

1080p wi-fi camera
Hide thumbs

Advertisement

Quick Links

Download this manual
1080P Weather Station
Wi-Fi Camera
User Manual
Version:March,2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the 700w and is the answer not in the manual?

Questions and answers

Summary of Contents for Aetos 700w

  • Page 1 1080P Weather Station Wi-Fi Camera User Manual Version:March,2015...
  • Page 2 Quick Guide of Wi-Fi Camera Function: 1.Plug in power —> Turn on indoor unit’s switch, wait for 2 minutes; 2.Enter smartphone setting —> Search and connect device’s wi named: YM……,wait till phone status bar appear Wi-Fi symbol; 3.Enter APP ,press + and select Set up —> Scan device QR code and select / input your Wi-Fi name and password —>...
  • Page 3 Indoor unit Outdoor unit...
  • Page 4 Overview The 1080P weather station Wi-Fi camera is a multifunctional fashionable weather station with an integrated 1080P high –de nition hidden Wi-Fi camera. First, it can be used as a normal weather station to detect and show both outside and inside temperature and humidity, and display time/date/moon phase;...
  • Page 5 In the box a Indoor unit an Outdoor unit a Back cover an AC power adapter a USB cord a CD driver a User manual Three screws...
  • Page 11 Getting Started of Weather station part Remove the protective seal from the battery and connect power, LCD screen will be lighted on. Insert 2pcs*AAA batteries for outdoor unit, it will be powered on automatically and send out current actual weather info in 1 minute.
  • Page 12 TIME: Long press to set time/date ALM: Long press to set alarm UP : Up key(Press to change from 12 hour format time to 24 hour) DN : Down key(Press to change from Centigrade degree to Fahrenheit) MAX/MIN: Press to show the max or min temperature and humidity of the day ALERT: Long press to set outdoor max/min temperature...
  • Page 13 Getting Started of Wi-Fi camera part Step1: Download and install APP Scan below QR code or search and download free APP Pro iCam named “ ” in Apple APP store, Google play or Electronic market, and install it. [ Pro iCam ] APP QR code...
  • Page 14 Step2: Connect power and turn on device Remove the protective seal from the battery and plug it into AC power using the included adapter; Turn on right side switch, and wait for 2 minutes. (Blue light always on, red light blink slowly.) Step 3: Connect Wi-Fi 1.
  • Page 15 2. Open APP, press symbol + at the top right corner, select “Setup camera Wi-Fi connection”.
  • Page 16 3. Scan QR code(in the back of device) or input to add device UID , input your Wi-Fi name and password(Both are case – sensitive).Press Start con guring Wi-Fi. When it shows (The WIFI connection has been con gured), quit APP (and device restart automatically and ready again in 30 seconds).
  • Page 17 4.Enter APP and select “Add new online camera”. Then search for new camera and press ok . You can see the camera in the rst page now. When device connected Wi-Fi, red light will be always on.Then all is ok now!
  • Page 18 P2P(point to point) mode, and P2P mode to Wi-Fi setting. Plug in power —> Turn on indoor unit’s switch, wait for 2mins. P2P mode (when there is no Wi-Fi ) 1. Open smartphone setting, search and connect mobile Wi-Fi to the wireless signal named “YM……”, wait Wi-Fi connected, and phone status bar appear Wi-Fi...
  • Page 19 2. Open APP, press symbol + at the top right corner, select “Add new online camera”. Search for new camera and press ok. Then back to the rst page to see the live camera and do the following setting.
  • Page 20 P2P mode to Wi-Fi (The second way to connect Wi-Fi) 1.Press the after the camera or long press the camera and select Advance Cong ,select Wi-Fi Con g.
  • Page 21 2. Select your Wi-Fi and input passcode, camera will be connected to your Wi-Fi. Your smartphone will disconnect the signal from device and connected to your Wi-Fi. 3. Quit APP, and device restart automatically and ready again in 30 seconds. 4.
  • Page 22 Set camera name and private code Set name:Press the after the camera or long press the camera,select Modify camera, select Name and insert name like Of ce, Room…...
  • Page 23 Set code: Long press the camera and select Advance Con g ,select Change P2P password. Current one is 8888.

  • Page 24: App Introduction

    APP introduction: Camera name Camera setting key Camera UID Camera online user number Snapshot: Review snapshot pictures Record: Review recorded videos Alarm: Review alarmed pictures...
  • Page 25 Live video page - Click camera to check Resolution Brightness Contrast Zoom Up down Record Audio reversals Left right Snapshot reversals...
  • Page 26 Alarm Con g: Set motion detection sensitivity /Alarm interval Wi-Fi Con g: Set camera to other Wi-Fi SD Card Record Con g: Set SD card record mode / Resolution /File length … Change P2P password: Set camera new password Camera reboot: Restore to factory default setting...
  • Page 27 Set and watch by PC 1. Install software “IPCamera”from included CD and open software to nd the connected device’s IP address.
  • Page 28 2. Double click the IP address, insert name“admin” (no password) and press ok.
  • Page 29 3. After above steps, you can insert setting interface. For rst use, please choose langauge, then click to download and install plug-in.
  • Page 30 4. Click to go to the nal setting interface.
  • Page 31 5. Click left options to set other needed functions.

  • Page 32: Specification

    Specification: Pixel 5 Mega pixel CMOS Resolution 1080P Video format Frames 25fps View angle 90° Distance of motion detection shooting 6m straight-line distance Battery capacity 2400MA Continuous shooting time Above 24 hours Compressed format H.264 Power consumption 300MA/3.7V Type of memory card TF card>=Class 4/10 and HC marked Maximum capacity of memory card 32GB...
  • Page 33 1. Q: LCD Screen not stable, always shinning? A: It means low battery, please charge it. 2. Q: Can’t get device Wi-Fi signal? (Four solutions FYI.) A: 1) Take out battery, then plug in power and wait 2 mins. 2). Press reset key for 5 seconds and wait 2 mins 3).
  • Page 34 4. Q: Live video not smooth and clear? A: Select suitable resolution according to the real time network environment. 5. Q: How many cameras can be added to APP? A: No limit. 6. Q: How many visitors support to check live video? A: 1-2 7.
  • Page 35 8. Q: How is the micro SD card working? A: Every time you insert micro SD card, device will format the card and start to record automatically. (Please save the data before inserting micro SD card) 9. Q: Forget camera password, or item goes abnormal? A: When blue indicator light alway on, press reset key for 5 seconds to restore factory settings, device restarts and get ready again in 2 minutes.
