PACKING LIST
UC-1284 Printer Cable
User's Manual
CD-ROM Driver
• Please read this manual thoroughly and follow the installation procedures to prevent any
damage to the UC-1284 and/or the connecting devices.
All brand names and trademarks are the registered property of their respective owners
®
©Copyright 1998 ATEN
International Co., Ltd.
Manual Part No. PAPE-0108-100
Printed in Taiwan 06/1998
x 1
x 1
x 1
Advertisement
Table of Contents
Related Manuals for ATEN UC-1284
Summary of Contents for ATEN UC-1284
- Page 1 User's Manual CD-ROM Driver • Please read this manual thoroughly and follow the installation procedures to prevent any damage to the UC-1284 and/or the connecting devices. ©Copyright 1998 ATEN Manual Part No. PAPE-0108-100 All brand names and trademarks are the registered property of their respective owners ®...
- Page 2 TABLE OF CONTENTS INTRODUCTION PRODUCT FEATURES AND SPECIFICATIONS TROUBLE SHOOTING PREVENTING RADIO AND TV INTERFERENCE...
- Page 3 INTRODUCTION ATEN UC-1284 Printer Cable is a bridge that links the traditional IEEE 1284 parallel i n t e rface to the Universal Serial Bus(USB) interf a c e. It is easy to install and compatible with most printers from major manufacturers. The UC-1284 is Bus powered and does not need an external power.
-
Page 4: Product Features And Specifications
PRODUCT FEATURES AND SPECIFICATIONS FEATURES • Full compliance with the USB spec. 1.0. • Low power consumption and is powered from USB connection. • Full compatible USB host device drivers available. • Transparent fully automatic support for true bi-directional communication. •... -
Page 5: Specifications
SPECIFICATIONS... - Page 6 Hardware and OS Requirements Personal Computer with 486 (or higher) processor with : • 16 Mbytes of RAM • USB connector One of the two following operating systems: • Windows 98 • Windows 95 version 4.00.950b with the USB supplement (QFE 1214), also known as OSR2.1.
- Page 7 1. Connect the ATEN UC-1284 Printer Cable to a printer or other IEEE Standard 1284 peripheral that is turned on. 2. Plug the USB end of the ATEN UC-1284 Printer Cable into the USB HUB or PC’s USB port. A new Hardware Found box will appear stating that an Unknown Device has been found.
- Page 8 At this point, the files should automatically be copied from the diskette. The installation process is now complete. (Note: If a Plug & Play printer is being used, then a Plug & Play prompt may appear at this point to install the printer drivers.) 3.
- Page 9 ATEN UC-1284 Printer Cable: • Insert the diskette into the floppy disk drive. • Click on the Next button in the Update Device Driver Wizard box. Windows 95 OSR2.1 (or Windows 98) will find the driver for the ATEN UC-1284 Printer Cable.
- Page 10 5. To verify that the ATEN UC-1284 Printer Cable has been correctly installed, right click on My Computer, and then left click on Properties to access the System Properties box. 6. Choose the Device Manager tab in this box. The ATEN UC-1284 Printer Cable...
- Page 12 7. Now double click on ATEN UC-1284 Printer Cable (UC1284USBx). If the installation was successful, an ATEN UC-1284 Printer Cable Properties box will appear and the device status will state that the device is working properly.
- Page 13 1284 Printer Cable in step 1, a test page can now be printed: • Click on Start/Settings/Printers. • Right click on the icon for the printer connected to the ATEN UC-1284 Printer Cable, then left click on Properties. • Choose the Details tab. Select the correct UC1284USBx port “Print to the...
- Page 14 following port:”. Under “Print using the following driver” select the driver that corresponds to the correct printer. Click on the “A p p l y ” button and then select the “General” tab of the box. • To begin the printing process, click on the “Print Test Page” button.
-
Page 15: Troubleshooting
TROUBLE SHOOTING Please refer to Windows 95 or Windows 98’s Trouble-shooting guide for further assistance. PREVENTING RADIO & TV INTERFERENCE WARNING!! This equipment generates, Uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, may cause interference to radio communications. -
Page 16: Limited Warranty
LIMITED WARRANTY IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and specially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
