Summary of Contents for ArcVision ARC-12S49VF3
- Page 1 Vandal-Proof IR Dome Camera Instruction Manual VER.:1.0, NO.:040118...
- Page 2 Thank you very much for purchasing our product. Before operating this product, please read this instruction manual carefully to ensure proper use. 1. Safety Precautious CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE.
- Page 3 3. Feature u With built-in high quality CCD Camera and high performance Infrared Illuminator modules. u Infrared Illuminator has effective range up to 20 meters and wide angle at 60°, also assists cameras in providing a clear image when under completely dark area. u Infrared Illuminator has built-in 24 pieces 850nm wavelength infrared Light -Emitting Diode and provides over 6000 hours life.
- Page 4 5. Installation & Operation Using the provided L-Wrench, loosen the tamper-resistant housing cover screws (with screws still attached on the cover). The unit has a factory installed side conduit entry and one may adjust the cables to back conduit entry according to installation requirement (as shown on figure 1).
- Page 5 (4) Vari-Focal Dome CCD Camera Operate (4.1) Once the picture appears on the monitor, open the cover adjust the lens’ wrench of “NEAR←→FAR” to get the view zoom that you desire, then adjust the focus wrench of the Lens to obtain the b est picture. After adjustment, tighten this two wrench both.
- Page 6 (5) When the camera focus adjustments has been completed, using the provided L-Wrench to fasten the tamper-resistant housing to the main body (as shown on figure 4). Figure 4...
- Page 7 (6) Connect the Video Output to the monitor or other video device through a 75 Ohms type coaxial cable. Connect the AC/DC-Terminator with power source (as shown on figure 5). To Monitor To AC-24V/ DC-12V Power Source (AC/ DC Dual Model) Figure 5 (7) When using the side conduit cabling, it is suggested to use metal cover over the cables to prevent external damage and as to weatherproof prevention,...
-
Page 8: Specification
6. Specification According to the camera purchased, select and refer to the appropriate specification below: Image Device 1/3“ Color SONY Super HAD 1/3“ Color SONY Hi-Res. Super HAD NTSC: 510×492 NTSC: 768×494 Picture Elements PAL: 500×582 PAL: 752×582 Resolution 380 TVL Min.
