Roiscok iDo218 Manual

Wireless alarm system
Hide thumbs
Table of Contents

Advertisement

Quick Links

iDo218
Wireless Alarm System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iDo218 and is the answer not in the manual?

Questions and answers

Summary of Contents for Roiscok iDo218

  • Page 1 Wireless Alarm System...

  • Page 2: Table Of Contents

    ………… ……… ……… ……… ………… … Keys and LEDs … ……… ……… ……… ……… … Main Function of iDo218 ……… …… … Components and Technology Data of iDo218 ……… ……… ……… ……… ……… ……… Technical Data …………… ……… …… … … …… …… Professional Terms ……...
  • Page 3 …………………… iDo218UD and Remote PC Management …… …… ……… ……… ………… … … … … iDo218 Events …………… ……… …… … … … … … … Mounting Detectors …… ……… …… ………… … … … … … … … … ………...

  • Page 4: Packing List

    Do218 Wireless Alarm System...

  • Page 5: Chapter 1 Summary

    It can match with all kinds of wireless detectors of ROISCOK and iDo. It is easy and delightful to installers for its menu operation. The radio frequency is 433.92MHz.

  • Page 6: Main Function Of Ido218

    Alarm call has priority function. ● Build-in siren driver, can drive build-in siren and 15W outside siren. ● Matched for up to 10 remote controllers. Arm and Disarm iDo218 by remote controller; ● Arm and disarm iDo218 through line/mobile phone.

  • Page 7: Components And Technology Data Of Ido218

    ● About iDo218 The iDo218 is powered by an adapter of 12V/2A DC, with 16 keys, a large 4 lines LCD, 6 LED, a USB port, a phone port and a network port. On the main board, there are a build-in siren and MIC, a connector for outside siren and phone line and UO.
  • Page 8 Do218 Wireless Alarm System ● Zones Supervision The detector will send a report to the iDo218 to confirm itself every 2.5 hours. The iDo218 will alarm to the central monitor station if no report received in 16 hours. ● Code and Grading iDo218 can be set up 10 grading codes.

  • Page 9: Technical Data

    Arm/Disarm User can arm/disarm iDo218 by the following three ways: keys, remote controller, line phone or/and mobile phone. ● Events Log iDo218 can save up to 127 events, including arm, disarm, alarm, etc. Technical Data Input power DC12V 2A 9.6VDC1500mAH Standby battery Ni-MH rechargeable battery pack.
  • Page 10 ARM means start the warning status for part or all of the zones, DISARM means close the warning status for part or all the zones. During arming, iDo218 will alarm when any detector is triggered. During disarming, iDo218 will not alarm when any detector is triggered. ●...
  • Page 11 ● Partition All the zones of iDo218 could be divided into 5 groups at most, called partition. Each one can be operated separately, such arm, auto-arm, disarm and auto-disarm. ●...

  • Page 12: Chapter 2 Key Programming

    CHAPTER 2 KEY PROGRAMMING iDo218 can be programmed through keys and PC. To program iDo218 through keypads as following menu. The programming menu of iDo218 including 7 sub-menus: 0) Help 1) Probe/Transfer Detector/Repeater 2) Setting Code 3) Set Phone/Partition Number...
  • Page 13 Do218 Wireless Alarm System confirm disarm system; Use for confirm an operation, confirm data and save under the programming. ● */ Enter /return back key Use for enter into programming when system is disarming; Use for return back to last menu or exit the programming. ●...

  • Page 14: Programming Ido218

    Do218 Wireless Alarm System Programming iDo218 When power on, the LCD screen displays as following: ROISCOK iDo218Alarm System Under disarm status press [*] to enter programming menu. If do not press [ARM], [STAY] or [*] the screen will display Press [*] Enter Into Programming.

  • Page 15: Form 1.Summary Of Menu

    Do218 Wireless Alarm System...
  • Page 16 Do218 Wireless Alarm System...
  • Page 17 Do218 Wireless Alarm System...
  • Page 18 Do218 Wireless Alarm System...
  • Page 19 Do218 Wireless Alarm System...
  • Page 20 Do218 Wireless Alarm System...
  • Page 21 Do218 Wireless Alarm System...

  • Page 22: Chapter 3 System Operations And Usage

    Step 1. Cut off all the power, including AC power and standby battery; Step 2. Short on the DEFAULT jumper (Fig.9) , and then repower the iDo218, then off the DEFAULT jumper. The LCD will display as following: ROISCOK iDo218Alarm System Keypad Arm ●...

  • Page 23: Arm System

    ●If set Quick Arm Off, press [ARM] and code and press [#] to arm the whole system. If set Quick Arm On, then press [ARM] to arm the whole system. When arming, iDo218 will give “beebee--”, which means the exit delay time starts. Make sure the windows are closed and leave the protected areas during the delay time.

  • Page 24: Stay Arm

    Do218 Wireless Alarm System ●When set Quick Arm On, arm the system without code. Stay Arm ● If the system is set as Quick Stay Arm off, then press [STAY], and put in correct code and press [#] to stay arm the system. If the system is set as Quick Stay Arm on, then just press [STAY] to arm the whole system.

  • Page 25: Arm/Disarm By Remote Controller

    Do218 Wireless Alarm System ROISCOK iDo218Alarm System 2.Use [←] and [→] to choose which partitions would be disarmed. Arm/Disarm by Remote Controller Fig.3 Remote Controller - iDo104 b Emergency a.Arm c Disarm d Matching e Unlock Key Press arm key to arm the system, press disarm key to disarm the system.

  • Page 26: Arm/Disarm By Phone

    Unlock Key c Emergency Matching Arm/Disarm By Phone User can arm or disarm iDo218 by phone. Following the steps to arm/disarm: ● Dial the phone number which connected with iDo218. After One “beep-”, input user code and [#].When hear two confirm “beep”, to input an arm code or disarm code and press [#] to arm/disarm.

  • Page 27: Matching Remote Controller Ido104

    Do218 Wireless Alarm System 10 is used for disarm all; 11 is used for disarm partition 1; 12 is used for disarm partition 2; 13 is used for disarm partition 3; 14 is used for disarm partition 4; ● If user operated wrongly, the system will give three sounds (the first one and the third one are the same tone;...

  • Page 28: Matching Detector

    Do218 Wireless Alarm System Matching Detector 1.Press * key entering into the control panel to programming status, choose: 1 Probe/Transfer, 6) Matching to write code, (a) Prober matching, input code and press "#" to confirm. The screen displays as: 15 49 1 Probe/Transfer Matching start …...
  • Page 29 Battery clip Sensor Tamper switch Jumper S1S2S4S5 Fig.6 iDo304CMW iDo105 Battery clip Jumper Fig.7 iDo105 3.Depress the TAMPER switch to send a signal to the control panel iDo218,the LED of the detector and iDo218 would be blink. The screen will display:...

  • Page 30: Zone Types

    Do218 Wireless Alarm System 15 49 1 Probe/Transfer Matching Detector 01 ： Note 1. After matching, set detector and control panel to normal working status. 2. The “detector=01” means the first detector matched, max up to 62. Zone Types There 9 zone types as: alarm, transfer, close, Stay, 24hr, gas, medical, panic and fire.
  • Page 31 Do218 Wireless Alarm System Each system has only one Administrator Code; user cannot change Master Code with it, but owns the other same rights as Master Code. ●User Code System can set 1-6 six User Codes. User can arm/disarm the system with User Code, but cannot change system settings and check system status.

  • Page 32: Emergency Keys

    Door Chime Any zone has door chime function. If set the chime function On and under disarm status, the iDo218 will produce three short beep sound as soon as the zone is triggered. For home user, when door or window is opened, the sound can remind the mother to take care of the kids (this function needs to preset the Door Chime function as on);...

  • Page 33: Events Log

    2.Set wrong code locking time is 00-99 minutes, when system locks the keys, user needs to wait until the locking time is over. 3.When set Wrong Code Arm to On, the iDo218 will report to the CMS when wrong code times more than the limitation.
  • Page 34 (if the value more than 20, the user need to check whether there exists electromagnetic interference surrounding). When arming, if the interference is higher than the level and continuous or repeated within 30 seconds, the iDo218 would alarm it to the central monitor alarm(Alarm events is: communication failure) . b c d...

  • Page 35: Installation And Connection

    Do218 Wireless Alarm System Installation and Connection 1.Choose a dry place and convenient for power and phone line and good GND post for the iDo218. Power by external adapter, input 100- 240VAC,50-60Hz, output 12VDC 2.0A. RoHS OPEN OPEN Fig.8 Installation Bracket and Holes a Installation bracket.
  • Page 36 Do218 Wireless Alarm System 2. About the Mainboard and Connectors Fig9.motherboard and connectors diagram a. Power LED b.Signal LED...
  • Page 37 Wireless Alarm System c.Stay arm LED. d.LCD Screen connector e.Recorder molectron f.UO connector. iDo218 support one Utility Output. When connect the post, connect cathode to Uo and anode to AUX. When triggered, the UO will output 70mA at most. g.MIC.

  • Page 38: Chapter 4 Appendix

    Remote PC Management This Remote Management Module iDo218UD is designed for download and upload to/from iDo218. With this Module, the wireless panel iDo218 can be programmed and maintained by the computer. When user doesn't know how to program and maintain, the engineer can help the user by remote support.
  • Page 39 Wireless Alarm System 1.1Software Installation A.Put CD into computer running Setup.exe; b.Select Typical to start installation; c.You can see ROISCOK icon in the program listing of the start menu after installation. 1.2Running Running the Remote Management Program, the start interface will come out.
  • Page 40 Do218 Wireless Alarm System ig.12 Login window Confirm put in the correct user name and password to log in. Click “ ” to confirm user ID. The screen will show “Welcome to use the system” (as Fig. 13). Login Success Both of the default user name and password are “admin”.
  • Page 41 COM1, which is used for connecting iDo218UD COM: with RS232 on the local computer; the telephone number used for user s control Call Number panel iDo218 . " When finish setting it will display Communication Port " successful on the PC FIG 15...
  • Page 42 Do218 Wireless Alarm System 1.3.3Start the Communication Port First, must set the Remote Management Switch of iDo218 as ON (menu 5.8), otherwise the computer cannot program iDo218 through iDo218UD. Click "Configuration - Communication Port Settings - Start Communication Port", iDo218UD will dial the control panel. The windows will display successful dialing-up as shown in Figure 16.
  • Page 43 Do218 Wireless Alarm System Choose download column as required and click Download, iDo218UD immediately dial and download the information from the iDo218. As Figure 18. ig.18 Programmed Information After download the windows whether reset the iDo218CN. If need to continue, please click the "No"; Otherwise,If you click "Yes", iDo218UD will stop the dial and set Remote Management...
  • Page 44 1.3.6 Upload data to Control Panel Select the configuration column, as shown in Figure 16. After correct all of data in the iDo218, click the Send to finish upload and setting. Such as: Click "Configuration On/Off Settings", windows will show as Figure 21.
  • Page 45 Do218 Wireless Alarm System Correct the data as requirement including power trouble, switch On/Off. Click "OK" to save and exit. Select the configuration column again to correct other data, such as the detector setting, phone/partition setting, and switch On/Off setting, other setting, code setting, etc. After corrected all of the data, select the columns need to change, and then click Send to upload.

  • Page 46: Ido218 Events

    Do218 Wireless Alarm System 2. iDo218 Events Events Events Keys Fire Alarm Keys Arm Keys Medical Emergency Keys Disarm Keys Panic Auto-arm Burglar Alarm Auto-disarm Stay Zone Alarm Remote Arm 24hrs Zone Alarm Remote Disarm Telephone Arm Gas Leak Alarm...

  • Page 47: Mounting Detectors

    Do218 Wireless Alarm System 3. Mounting Detectors Wall Detector Wall mounting Coverage ⑤ Curtain Detector Corner Mounting Ceiling Mounting Wall Mounting Ceiling Detector Detection Range...
  • Page 48 Do218 Wireless Alarm System Ceiling Detector Ceiling Detector Detection Range...

  • Page 49: Faq

    Do218 Wireless Alarm System 4. FAQ Q: The iDo218 dialed my phone when there is an alarm, but why cannot I hear anything Alarming sound through it? A: iDo218 is not defaulted voice messages. So the user need to record voice before using.
  • Page 50 Q: What is the problem? When arming or any zone is triggered, the iDo218 cannot call through and send a message to the preset CMS, turn on the message displaying and the LCD screen shows: Contact ID Err.
  • Page 51 ROISCOK Electronics Ltd. Add:F/5,Building4,NO.3 Minzhi Industrial Park, Minzhi St.,Shenzhen,Guangdong China Tel:+86-755-81753600 Fax:+86-755-81753605 Http://www.roiscok.com...
