Summary of Contents for Pyle PLCMDVR 42
- Page 2 Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. The installation instructions do not apply to all types of vehicles, and are written as guidelines to assist in installing the system. Please consult an experienced technician if you are not comfortable installing the product.
- Page 3 System Installation and Wiring Camera System installation on diesel vehicles may require a slightly different wiring install. These installation instructions do not apply to all types of vehicles. They are meant only as a general guide due to the large number of vehicle makes and models. Consult your local motor vehicle laws on the use of this product to be sure it is permitted.
- Page 4 - Mount your exterior camera in the desired location, then connect the included RCA video cable, from the camera, and run the cable through to your video display's RCA connection. Make sure to route all cables and wiring in the least obtrusive route possible as to avoid conflict with other vehicle circuitry and to ensure a safe and stable installation/connection.
- Page 5 User Control Interface The 'Main Screen' or user interface is where you can take control. User can distinguish whether he will record video (with the video film icon appearing), Control Mode capturing images (with the camera icon appearing) or playing back media files (with the play button appearing).
- Page 6 User Input Control Projects a strong front facing LED light, into the direction for the front facing camera, LED Light located on the mirror mount assembly Micro SD Card Slot Max compatibility 32GB Used for connecting the power and video wiring harness, which then connects to the AV Input exterior mount camera Used for connecting the cigarette lighter DC power cable, which then provides power to...
- Page 7 When in video recording mode, press 'Mode' to prevent that file from being overwritten by circular recording. Once you select a Playback Media While in the playback mode, press the up and down arrows to cycle through your captured media, then press OK to view your media. Model: PLCMDVR7 HD Rearview Mirror Monitor and Dual Camera System with Hi-Res Video Recording, Image Capture, Night Vision Illumination, Motion Impact Recording, (2) Cameras, Built-in 4.25'' Screen Display, Built-in Distance Scale Lines, Parking Assist...
