RESTORATION
HARDWARE
Installation Guide
For Model:
Bistro Ceiling Fan
WOD52AGV5RW
E192641
net weight of fan: 17.2 lb (7.8 kg)
READ THESE INSTRUCTIONS
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Warranty. pg. 10
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bistro WOD52AGV5RW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Restoration Hardware Bistro WOD52AGV5RW

  • Page 1: Table Of Contents

    RESTORATION READ THESE INSTRUCTIONS HARDWARE AND SAVE THEM FOR FUTURE USE Installation Guide For Model: Bistro Ceiling Fan Table of Contents: WOD52AGV5RW Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    blade edge 3. Installation Preparation. To prevent personal injury and damage, ensure inches 7 feet (76cm) that the hanging location allows the blades a (2.13m) clearance of 7ft. (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. 12ft.

  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. set screw hole If you wish to extend the hanging length of your set screw fan, you must remove the hanging ball from the stop pin 4in. downrod provided to use with the 12 in. downrod included with the fan (or an extended downrod, sold separately).

  • Page 6: Wiring. Pgs

    5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with hanging bracket tab two hands. Slide downrod through opening in hanging ball slot hanging bracket and let hanging ball rest on the hanging bracket.

  • Page 7: Canopy Assembly

    6. Wiring. (cont.) IN ORDER TO WIRE WALL CONTROL, remove existing wall switch. Wire the WALL CONTROL with wire connectors provided as shown in diagram at outlet box right. wall control plate * Wrap each wire connector separately with electrical tape as an extra safety measure. Gently push wires and taped wire connectors into outlet box.

  • Page 8: Blade Assembly

    8. Blade Assembly. Time Saver: Washers for blade screws can be set motor housing on each blade screw prior to installing blades. Locate 15 blade attachment screws and washers blade attachment in one of the hardware packs. Hold blade arm up screws and washers to blade and align holes.

  • Page 9: Automated Learning Process./Activating Code

    9. Automated Learning Process./Activating Code. CAUTION: The remote control transmitter can be TRANSMITTER code (back) programmed to multiple receivers or fans. If this is switches not desired, turn wall switch off to any other programmable receiver or fan. Remove battery cover on back side of remote control transmitter.

  • Page 10: Remote Control Operation

    11. Remote Control Operation. HI button - turns fan to HIGH speed MED button - turns fan to MEDIUM speed LOW button - turns fan to LOW speed OFF button - turns fan OFF REV button - used to REVERSE blade direction (fan must be turned low before reversing blade direction) button - (for use with optional light kit, sold separately) controls light function: turns light ON/OFF...

  • Page 11: Troubleshooting

    Troubleshooting. Warranty. LITEX LIFETIME LIMITED WARRANTY: WARNING: Failure to disconnect power LITEX INDUSTRIES, LTD. warrants this fan to the original supply prior to troubleshooting any wiring issues may household purchaser for indoor use under the following result in serious injury. provisions: 1-YEAR WARRANTY: LITEX INDUSTRIES, LTD.
