WINDOW VACUUM CLEANER
3.6V
WVC10
Important
- Please read these instructions fully before operating or maintaining your window vac
These instructions contain important information that will help you get the best
from your window vacuum cleaner.
INSTRUCTION
MANUAL
AFTERSALES SERVICE
01904 727505
MON-FRI 9am-5pm SAT/SUN 11am-4pm
www.spearandjackson-power.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Spear & Jackson WVC10
- Page 1 01904 727505 3.6V MON-FRI 9am-5pm SAT/SUN 11am-4pm www.spearandjackson-power.com WVC10 Important - Please read these instructions fully before operating or maintaining your window vac These instructions contain important information that will help you get the best from your window vacuum cleaner.
- Page 2 THANK YOU! Dear Customer, Thank you for choosing a Spear and Jackson window vacuum cleaner. Spear and Jackson was founded in 1760 in the city of Sheffield, which is world famous for the production of steel, cutlery and garden and hand tools. Through continuous innovation and the use of new technologies and materials, Spear and Jackson has gained an enviable reputation as a supplier of reliable, high performance and high quality products designed to make your work in the...
-
Page 3: Table Of Contents
CONTENTS Safety Information Description of symbols General safety Personal safety Operating safety Maintenance and storage Intended use Box Content / Parts Assembly Assemble the appliance Fill the spray bottle Attach the wiping attachment Operation Charge the battery Start working Interrupting the work Emptying the reservoir during operation Maintenance Cleaning of window vacuum cleaner... -
Page 4: Safety Information
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine DESCRIPTION OF SYMBOLS The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the window cleaner. IMPORTANT! Symbol for battery separate collection. -
Page 5: General Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine GENERAL SAFETY PERSONAL SAFETY WARNING! IMPORTANT! Prior to using this appliance on sensitive ■ This appliance is not intended for use by ■ (high shine) surfaces, test the micro-fiber persons (Including children) with reduced wiping pad at an inconspicuous location. -
Page 6: Maintenance And Storage
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine MAINTENANCE AND STORAGE INTENDED USE This window vacuum is designed for domestic WARNING! use only: For cleaning wet, smooth surfaces such as To ensure the appliance safety, use only ■... -
Page 7: Box Content / Parts
BOX CONTENT PARTS Charger with charging cable Removable suction lip (suction bar) Charging cable plug Spray bottle Charging socket Fastening ring for the wiper attachment Charge/operation indication Spray lever ON/OFF switch Wiping attachment Handle Micro-fibre wiping pad Dirt water tank Spray head Dirt water tank plug Suction head (attachment) with... -
Page 8: Assembly
ASSEMBLY Assemble the appliance i. Line up the arrow on the suction head with the arrow on the top right hand side of the appliance. ii. Insert the suction head into the appliance and rotate 90° clockwise until it is secured. Fill the spray bottle i. -
Page 9: Operation
OPERATION Charge the battery WARNING - Use only with the original charger provided with this appliance. i. Ensure the appliance is switched off. ii. Plug the charger supplied with the appliance into the mains. iii. Insert the charging cable plug into the charging socket on the back of the appliance. -
Page 10: Start Working
OPERATION Start working i. Press the spray lever on the bottle to apply the detergent and spray the surface evenly; after that, loosen the dirt using the wiping pad. NOTE! Rinse pad under running water if needed! ii. Press the ON/OFF switch to switch the window vacuum cleaner on, the charge/operations indicator will illuminate. -
Page 11: Maintenance
MAINTENANCE WARNING! DANGER OF ELECTRIC SHOCK! Unplug the charger from the mains before carrying out any cleaning of the appliance. Cleaning of the window vacuum cleaner i. Always keep the device clean, dry and free of oil or grease. ii. Avoid getting the electrical part of the appliance wet or come in contact with any liquid. -
Page 12: Technical Data
TECHNICAL DATA WVC10 Model Rated voltage 3.6V Rated power Ingress protection rating IPX4 Volume of dirt water tank 80ml Charger Input voltage/power 230-240V ~ , 50-60Hz, 5.5W Output voltage/current 4.2V 500mA Charging time 3-5h Operation time with full charge Approx. 20min. -
Page 13: Troubleshooting
TROUBLESHOOTING Spray bottle does not spray Refill water and detergent. ■ Pump mechanism in the spray botte is defective, contact dealer. ■ Machine does not start Check the charge/operations indicator: No signal or slowly blinking signal: Charge the battery. ■ With a rapidly blinking signal: Inform your dealer. -
Page 14: Guarantee
GUARANTEE If your device develops a fault, please don’t hesitate to contact our customer service department on 01904 727505, we can solve 80% of problems via the phone. 1. These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights. -
Page 15: Ec Declaration Of Conformity
1XinghuoRD.,Nanjing,China And our branch office SUMEC UK Co.,Ltd. Unit A&B Escrick Business Park Escrick,York YO19 6FD Window vacuum cleaner Factory No. : PT1433501 Model No: WVC10 Function: Clean windows Serial number: WVC10-150001-151194 EMC Directive: 2004/108/EC RoHS Directive: 2011/65/EU WEEE Directive...
