- Page 1 1CH Digital Video Recorder Thank you for purchasing our product. Please read this User＊s Manual before using the product. 1 Channel Digital Video Recorder V1.1 - 1 -...
- Page 2 SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This label may appear on the bottom of the unit due to space limitations. The lightning flash with an arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated ?dangerous voltage?within the ...
-
Page 3: Table Of Contents
BEFORE READING THIS DOCUMENT ...................5 UNIT DESCRIPTION ...........................6 ............................6 RONT ANEL ............................7 ANEL ............................8 ONTROLLER INSTALLATION ............................9 ........................9 AMERA CONNECTION ........................9 ONITOR CONNECTION ........................10 RIGGER CONNECTION ........................10 ETWORK CONNECTION 5.HDD ..........................10 CONNECTION ........................10 OWER CONNECTION OPERATION ............................11 1. L ............................ - Page 4 MANUAL FOR REMOTE VIEWER SOFTWARE .................37 ........................37 ENERAL DESCRIPTION 2.TCP/IP SETUP ......................37 UNIT IP ......................38 TATIC YNAMIC ......................41 IVE VIEW VIA NETWORK ................45 EARCH RECORDED PICTURES VIA NETWORK - 4 -...
-
Page 5: Before Reading This Document
Before reading this document (1) This document is intended for both the administrator and users of stand-alone DVMR unit (2) This manual contains information for configuring, managing and using stand alone DVMR unit. (3) To prevent fire or electrical shock, do not expose the product to heat or moisture. (4) Be sure to read this manual before using stand alone DVMR unit. -
Page 6: Unit Description
Unit Description 1 Front Panel LED: (over write/Rec/Play/Setup) P/T: Enter into or exit from PAN/TITL control mode. SPEED: In full screen, this button shows pictures in rotation. MARK: mark when it is in playback mode FRZ: On-off switch to freeze pictures in live mode PLAY: Play-Back MENU: used to change menu in system setup Enter: Used as selection key in system setup or changes contents displayed in live... -
Page 7: Rear Panel
2 Rear Panel HDD BOX TRIGGER RJ45 LOOP BACK RS232/RS485/IO ALARM Connection DC Power VIDEO OUT - 7 -... -
Page 8: Controller
3 Controller P/T: Enter into or exit from PAN/TITL control mode. SPEED: In full screen, this button shows pictures in rotation. MARK: mark when it is in playback mode FRZ: On-off switch to freeze pictures in live mode PLAY: Play-Back MENU: used to change menu in system setup ENTER: Used as selection key in system setup or changes contents displayed in live display. -
Page 9: Installation
INSTALLATION 1.Camera connection Connect camera the camera input on the rear panel of the system. 2.Monitor connection Connect the monitor to the monitor out on the rear panel of the system. - 9 -... -
Page 10: Trigger Connection
3.Trigger connection Connects to trigger port of multiplexer in case you replace time lapse VCR used in connection with multiplexer. TRIGGER TRIGIN/GND 4.Network connection Connects to HDD BOX, Multiplexer or network 5.HDD connection Be sure to set jumper setting for each HDD as per HDD manufacturer’s spjecification Main board (Default) -
Page 11: Operation
Operation 1. Log-in LOGIN DVR SYSTEM < > PASSWORD 1,2,3,4 : INPUT PASSWORD MENU : ERASE PASSWORD ENTER : ENTER OR EXIT (1) Press [MENU] button to enter the system menu after starting the system. (2) LOGIN DVR SYSTEM window appears as shown above. (3) Use button to enter password that has 1 to 8 digits with numbers from 1 to 4. -
Page 12: Recording
NOTICE : To protect hard drive from damaged, turn off the power switch of DVMR unit after you first press [MENU] button. If you press [MENU] button, DVMR unit stops recording, and HDDhead is not in the process of writing. NOTICE : When logged into USER MODE, only DISPLAY SETUP and TIME/DATE TYPE SETUP is possible. - Page 13 1. Indicate address of P/T 3. Set ON/OFF for selected camera : 001~255 command ON/OFF (ENTER button) 2. Command FOCUS FAR FOCUS NEAR 2002 / APR / 01 PM 01:00:00 FOCUS AUTO 60FPS REC PAN RIGHT PAN LEFT CAM : 001 FOCUS FAR TILT UP EXIT : PRESS [P/T]...
- Page 14 (4)Scheduled recording Records as scheduled, and setting can be done by date or by day of the week. For each day, 2 different time intervals can be set at ON or OFF in the unit of 30 minutes, and same for each day of the week. Therefore users can set 4 recording time intervals of recording or not recording for every day.
-
Page 15: Play
3. Play (1) How to replay Press [PLAY] button to begin playback. Screen on the right will appear. Press [PLAY] button to start playback from the first of recorded data. S (START) : Start of recording Indicates E (END) : End of recording recording is G (GOTO) : Set time from which stopped... - Page 16 (3)Pausing and advancing picture by picture During playback, press [PAUSE] button to pause. Press once more to play again. After [PAUSE] button, press button to advance picture by picture in both direction. It is useful to check one after the other carefully. (4)Playback speed setup During playback, press [speed] button.
-
Page 17: Setup
MARK IMAGE SETUP TOTAL FRAME START TIME EMD TIME Play just marked PLAY MARK IMAGE pictures or delete DELETE MARK IMAGE marked pictures SELECT , PRESS ENTER Display of MARK IMAGE SETUP 4. Setup (1)Start of SETUP Press [MENU] button. Log into the system by entering password. - Page 18 SYSTEM SETUP DISPLAY SETUP CAMERA SETUP TIME/DATE SETUP ALARM/MOTION SETUP RECORD SETUP TCP/IP SETUP MISCELLANEOUS FACTORY DEFAULT SELECT UP/DOWN , ENTER Display of SYSTEM SETUP SETUP items remain unchanged even though you choose FACTORY DEFAULT 1)Time and date of TIME/DATE SETUP 2)All recorded data on HDD 3)Marked data 4)ADMIN password...
-
Page 19: Display Setup
(2)DISPLAY SETUP This is about the contents displayed on the display screen. 2002/ARP12 AM 07:40:38 DISPLAY SETUP 60FPS REC TIME/DATE : ON CAMERA TITLE : ON PB TIME/DATE : ON : ON PB CAMERA TITLE : ON DVR STATUS SELECT , PRESS CAM1 Display of DISPLAY SETUP... - Page 20 CAMERA TITLE SETUP 0 1 2 3 4 5 6 7 8 9 . , < > ( ) A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d e f g h I j k l m n o p q r s t u v w x y z >...
-
Page 21: Time/Date Setup
(4) TIME/DATE SETUP SET TIME/DATE : Sets year/month/day/hour/minute/second SET TIME/DATE YEAR MONTH 2002/APR/15 HOUR PM 09:23:17 MINUTE SECOND SELECT , PRESS Display of SET TIME/DATE With button, move to year/month/day/hour/ minute /second, and change value using button. SET TIME/DATE TYPE : Sets notation of TIME/DATE TIME/DATE TYPE SETUP HOUR DISPLAY : AM/PM... -
Page 22: Alarm/Motion Setup
(5) ALARM/MOTION SETUP ALARM SETUP : Sets type of sensors connected to DVMR unit. ALARM SETUP > ALARM SIGNAL : N.C ALARM DURATION : 20 SEC ELECT LIST TYPE : ALM SELECT , PRESS Display of ALARM SETUP OFF : Not in use. NC : Normal closed. - Page 23 ALARM LIST SETUP A: ALARM L : LOSS DATE TIME M : MOTION > --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- --/--/-- Playback from GOTO SORT DELETE GOTO time SELECT , ENTER , MARK Display of ALARM LIST SETUP button, move to any of SORT/DELETE/GOTO 1.
- Page 24 MOTION SETUP MOTION SETUP > SENSITIVITY : NORMAL DETECT CELL : 001 RECORD TIME : 1 SEC SELECT , PRESS Display of MOTION SETUP SENSITIVITY : Adjust motion detection sensitivity in 5 steps. VERY LOW – LOW -- NORMAL -- HIGH — VERY HIGH DETECT CELL : Defines size of objects to be detected.
-
Page 25: Record Setup
1) Press [P/T] button to choose desired EDIT mode. 2) Use direct buttons to assign BLOCK and [ENTER] button to set. 3) MASK area in green color is detection area and the rest is no detection area. 4) Detection area is indicated in green and no detection area is in colorless. SELECT EACH CELL : Select cell by cell. - Page 26 HDD CLEAR : If YES is selected, it deletes contents of the HDD. Using button, set HDD CLEAR at YES and press [MENU] button. You will see messages on the right, and then press [ENTER] button to delete all <CAUTION> IF YOU WANT TO DELETE PRESS <ENTER>...
-
Page 27: Tcp/Ip Setup
MUX CH NUMS : When you use this DVMR unit in connection with multiplexer, replacing time lapse VCR,set numbers of camera connected to multiplexer. (7)TCP/IP SETUP TCP/IP option of stand-alone DVMR enables users to see live pictures and search recorded pictures via IP network, far apart from DVMR unit. It is also possible to control PTZ camera while you see live pictures. -
Page 28: Miscellaneous Setup
MAC ADDRESS : It is unique ID number provided by DVMR manufacturer, and the user must not change under any condition. When modified, it can cause collision with other systems in the Internet line and cause problem in operation. Make sure this number remains unchanged always. DHCP SETUP : If you press ENTER button, you can enter into sub-menu of DHCP SETUP. -
Page 29: Default Setting
ID/PW SETUP < USER > CURRENT < > < > CONFIRM < > 1,2,3,4 : INPUT PASSWORD MARK : ERASE PASSWORD SELECT , PRESS ENTER Display of ID/PW SETUP 1)Using button, select item to be changed and press [ENTER] button to be ready for changing 2) Using button, enter current number first and enter new number. - Page 30 Records according to schedule by day or day of the week. Two time spans can be set for a day and a day of the week respectively. In total, 4 spans of recording or not recording can be set in a day. 1) Recording schedule for a day : Record during set time in set day Select date : Select recording date using button.
-
Page 31: Hdd Information
4)Note for schedule recording : If you set scheduled recording, DVMR unit does not record before the set time. It only starts recording at START time and ends at END time. PANTILT CMD SETUP : If you want to connect PTZ camera which is not included in the list of PTZ camera, you have to input protocol of PTZ camera you are going to connect to DVMR unit. - Page 32 MARK IMAGE SETUP MARK IMAGE function is very useful, because it protects marked images from being overwritten. During playback, you can mark images to store them on HDD safely free from being overwritten after HDD starts to overwrite. Start and end of data recorded MARK IMAGE SETUP Numbers of images...
-
Page 33: Hdd Bay
HDD BAY 1.HDD EXTENSION Default HDD installed in DVMR unit (1)1~2 HDDs as per customer requirements (2)EIDE, 3.5 inch, 7200 rpm, LBA mode type (3)HDD capacity : Up tp 120GB/unit Compatibility with up to 120GB confirmed 2. HDD BAY In case up to 2 HDDs installed in a DVMR unit is not sufficient and needs to increase storage capacity, connect HDD Bay to DVMR unit. -
Page 34: Specifications
SPECIFICATIONS 1.Specification MODEL NO Single channel stand-alone DVMR INPUT 1 CH INPUT 1.0 VP-P, 75 OHM UNBALANCED (BNC TYPE) OUTPUT 2 OUTPUT VBS : 1.0VP~P.75 OHM UNBALANCED (BNC TYPE) VIDEO I/F HORIZONTAL RESOLUTION 500TV LINES S/N RATIO MORE THAN 4dB COLOR 16.7 MILLION ZOOM... -
Page 35: Configuration Of Single Channel Dvr
2.Configuration of single channel DVR 3.RS-232C Hex-Codes table Following ASCII code are for programmers who want to control the DVMR unit via RS-232C port. If you connect to RS-232C, you can operate DVMR unit using key board of PC, in addition to operation using operation buttons on the front of DVMR unit. - Page 36 Remote Viewer Software Thank you for purchasing our product. Please read this User＊s Manual before using the product 4 Channel Digital Video Recorder V1.1 - 36 -...
-
Page 37: Manual For Remote Viewer Software
Manual for Remote Viewer Software 1General description TCP/IP option of enables users to view live pictures, search recorded pictures, or control PTZ camera via Internet line, far apart from the DVR unit, and users can store selected recorded pictures on HDD of client PC. Arg stand-alone DVR does not include web server for access to DVR unit via Internet line, and you must install Remote Viewer software included in the package on client PC before you try to access to DVR unit over IP network... -
Page 38: Static Ip And Dynamic Ip
3.Static IP and Dynamic IP Practical guideline not to be confused in running Remote Viewer due to mistake in assigning right IP Address, Gateway and Subnet mask to DVR unit. (1) We recommend you to get static IP and input this static IP Address into DVR unit to which you want to access via IP network. - Page 39 (a)Window 2000 First you need to get to the command prompt using the command shell. The best way is from the run menu. Start--> Run --> and type in Command. Then either hit enter or click OK. At the command prompt, type in ipconfig. This will pull up the information that you need to find your IP Address for DVR unit.
- Page 40 When winipcfg launches, you'll get a window like this one: Now, hit the "Release" button and then hit "Renew". If all goes well, you'll get new information, and it is for your DVR unit. Write down this information on separate paper and input IP Address, Subnet Mask, and Default Gateway into your DVR to which you want to access via IP network.
-
Page 41: Live View Via Ip Network
4.Live view via IP network Click Remote Viewer icon to view live pictures via IP network. You will see then following window. Function of each button in live-view window : ① : Power switch. Press power switch to quit. Before press power switch button, press disconnect button first. - Page 42 ④ : Screen division button. You can select 1 or 4 to see live pictures of any single channel or 4 channels, in case of 4 channel DVR. If you select 1, you can further select channel number from 1 to 4 to see pictures of selected channel. If you selected 4, you swill see channel number from 1 to 4 are all activated.
- Page 43 LABEL : Assign a name to IP/PORT . IP load : Select a set of IP/Port from history table . Display Play Time On Image : Display time on image in playback(scan) mode . Set Path to Save Recorded Images : Set folder where you will save picture you selected during playback(scan) or series of pictures in AVI format .
- Page 44 - Scan. : Press scan button to enter into search window. Using various operation buttons, you can search recorded pictures, save s elected pictures on client PC, or print pictures. Refer to following paragraph “3. Search recorded pictures over IP network”...
-
Page 45: Search Recorded Pictures Via Ip Network
5.Search recorded pictures via IP network Function of each button in search window : ① : Power switch. Press power switch to quit. ② : Full screen button. Press full screen button to search recorded picture channel by channel in full screen. ③... - Page 46 ⑥ :Time selection button. You can set time to search pictures recorded at set time by dragging vertical line to the left or right. See time to be displayed on the left ( ) in green color and find an exact location for the time from which you want to search.
- Page 47 Speed of playback according to scan rate set . Scan rate set in 3-⑦-a) Maximum playback speed of YOKO DVR is 60x. : Command button. We have 3 different buttons that are, save, print, and event. Save During searching recorded pictures, you can save pictures one by one in the folder in client PC by pressing save button.
- Page 48 Notice : We recommend you to click operation buttons one after the other with enough time interval to give enough time for DVR unit to execute commands from client PC. Too fast clicking operation buttons one after the other with too short time interval may cause system hang-up in client PC.
