Lithium Earthwise LPS40208 Operator's Manual

Cordless 20 volt pole saw lithium-ion battery pack
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL
CORDLESS 20 VOLT POLE SAW LITHIUM-ION BATTERY PACK
This product is covered by U.S. patents and other international patents
Copyright. All Rights Reserved.
LPS40208
Your pole saw has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual before
using this product.
Thank you for your purchase.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING, ASSEMBLY, PART, SERVICE QUESTIONS? Call 1-800-313-5111
BETWEEN 7:30AM-4:30PM EST FOR ASSISTANCE.
BATTERY MUST BE CHARGED BEFORE FIRST USE.
SAVE THIS MANUAL FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPS40208 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lithium Earthwise LPS40208

  • Page 1 This product is covered by U.S. patents and other international patents Copyright. All Rights Reserved. LPS40208 Your pole saw has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS TO REDUCE RISK OF INJURY: Save these instructions and review frequently prior to Before any use, be sure everyone using this tool use and in instructing others. reads and understands all safety instructions and WARNING: When using electric gardening appliances, other information contained in this manual.
  • Page 3 ASSEMBLY UNPACKING ADJUSTING LENGTH OF TELESCOPIC POLE This product requires assembly. Remove the battery pack from the pole saw. Carefully remove the product and any accessories from the Lift locking clamp and push poles towards each other to box. Make sure that all items listed in the packing list are shorten the pole or pull away from each other to lengthen included.
  • Page 4 INSTALLING/REPLACING THE GUIDE BAR AND CHAIN DANGER: Never start the motor before installing the guide  Remove the bar and chain from the mounting surface. bar, chain, chain cover and chain cover lock knob. Without all these parts in place, the clutch can fly off or explode, exposing the user to possible serious injury.
  • Page 5 INSTALLING/REPLACING THE GUIDE BAR AND CHAIN   Tighten the lock knob, but leave the bar free to move for Hold the chain in position on the bar and place the loop tension adjustment. around the sprocket.  Remove all slack from the chain by turning the chain tensioner clockwise until the chain seats snugly against ...
  • Page 6 CHAIN TENSION AND MAINTENANCE Lift file away from the steel on each return stroke. CHAIN TENSION Put a few firm strokes on every tooth. File all left hand cutters in one Stop the motor before setting the chain tension. Make sure the lock knob is loosened to finger tight, turn the chain tensioner direction.
  • Page 7 OPERATING Before you start the unit, make sure the pole saw is not ADJUSTING THE ANGLE OF THE POLE SAW HEAD: contacting any object. Push the head release button and adjust the rotating head to the angle TO TURN THE TOOL ON of 30°...
  • Page 8 OPERATING AND INSTRUCTIONS BASIC CUTTING PROCEDURE See figure 1-2 Keep the tree between you and the chain while limbing. Cut from side of tree opposite branch you are cutting. Do not cut from a ladder; this is extremely dangerous. Leave this operation for professionals.

  • Page 9: Charging The Battery Pack

    CHARGING THE BATTERY PACK When fully charged, the battery can be safety stored in temperatures The 20 volt battery supplied is sealed, maintenance free and spill free. down to –40° degrees F for a period of up to four weeks, before requiring charging.

  • Page 10: Maintenance

    MAINTENANCE LUBRICATION SYSTEM BEFORE USING: Fill oil well with new quality bar and chain oil. Unused SAE30 weight motor oil may be substituted. The chain is automatically lubricated. If you drop the pole saw, carefully inspect it for damage. If the Use only new bar and chain oil or unused SAE 30 weight motor oil may blade is bent, housing cracked, or handles broken or if you see be substituted.
  • Page 11 FEATURES PRODUCT SPECIFICATIONS LPS40208 Input ......20 V/1.5Ah, DC only Bar Length ....... .8” Oregon Bar Weight .

  • Page 12: Warranty

    WARRANTY LIMITED WARRANTY FOR CORDLESS ELECTRIC MODELS This product is manufactured for The Great States Corporation/American Lawn Mower Company. The Great States Corporation/American Lawn Mower Company, Shelbyville, Indiana, has been making lawn mowers for over 100 years and warrants to the original owner that each new product and service part is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective product or part from the original date of purchase for two (2) years except for the conditions and circumstances listed below.
