SERVICE MANUAL
LP-LED2
TYPE: YS1106
SMT Disclaimer
Due to the complex nature of the use of SMT installed components
in Yorkville equipment, we highly caution all service technicians in
attempting to repair or replace SMT factory installed components.
Many of these components may be glued prior to initial soldering.
Replacing SMT components requires expensive
specialized de-soldering equipment and training.
Yorkville Sound will repair and replace defective SMT components
to ensure proper quality assurance and installation is maintained.
®
C
US
Manual-Service-LP-LED2-00-1v2 • Feb. 24, 2016
Advertisement
Related Manuals for YORKVILLE LP-LED2
Summary of Contents for YORKVILLE LP-LED2
- Page 1 SMT Disclaimer Due to the complex nature of the use of SMT installed components in Yorkville equipment, we highly caution all service technicians in attempting to repair or replace SMT factory installed components. Many of these components may be glued prior to initial soldering.
-
Page 2: Power Cord
IM PORTA N T S A F E T Y IN ST RUC TI ON S This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is intended to alert the an equilateral triangle, is intended to alert the user to the presence of user to the presence of important operating and maintenance (servicing) uninsulated “dangerous voltage”... - Page 3 1, 2 S t a g e L i g h t i n g L i g h t b a r 3, 4 A-Z1467 / 1v3 DESIGNED & MANUFACTURED BY 15 s YORKVILLE SOUND • TORONTO, CANADA 90 s...
-
Page 4: Specifications
Specifications LP-LED4 Max AC Input Voltage 100-240VAC 50/60 Hz Power Consumption LEDs 16 Watts per LED, 4 LEDs per head, 64 Watts total Power Consumption 270 Watts Stand Mount Size 1 3/8 inch Round Controller Cable Standard Shielded 3-pin XLR Cable Other Optional DMX Module Dimensions (LWH) - Page 5 LP-LED2/4 Quick Guide Parts Yorkvi l l e PART# DESCRIPTION PART# DESCRIPTION 3425 DPDT PUSH SW PCMT BREAK B4 MAKE 4088 IEC POWER V-LOCK INLET CH Assign - LP-LED2 ONLY A.C. In 3922 XLR FEML PCB MT HORZ THIN SNAP-IN...
- Page 6 LED BIN CODE REF # LF: KL.LM.F.N_DW: R2.G3.B5- R3 LF: KL.LM.F.N_DW: R2.G3.B5- S3 LF: KL. L. F. N_DW: R2.G3.B5- S3 LF: R. G. B. N_DW: R1.G3.B5- R3 LF: R. G. B. N_DW: R1.G3.B4- R3 LF: R. G. B. N_DW: R1.G3.B5- R2 LF: KL.
- Page 7 LP-LED2 Parts List 2/23/2016 YS # Description Qty. YS # Description Qty. YS # Description Qty. 2357 4 CIR XH-HEADER RA 0.098IN 8003 3 PIN HEADER 1.5MM VER MINI SMT 2364 HEYCO LOCKIT STRAIN RELIEF 1852 8011 2W00 680R 2512 SMT RES 3073 PATCH 3 22AWG 29.0 4PIN CONNECTOR...
- Page 8 M1482 Parts Reference List 2/23/2016 YS # Description YS # Description YS # Description 7779 __2N2 50V 10%CAP 0603 SMT COG 7621 W100 1K0 1% 0805 SMT RES 7738 _10U0 16V 10%CAP 1206 SMT X7R 7676 W100 2K0 1% 0805 SMT RES 7767 100N 16V 10%CAP 0603 SMT X7R...
- Page 9 W125 W125 0R06 1% 1206 SMT RES 1206 W250 100R 1206 FDFS6N754 7743 7731 0.1W 10R0 0805 68UH CY8CLED04G01 7989 CSP0 PGND0 1/8W CSN0 0805 CSP1 PGND1 SMBJ26A 1/8W CSN1 0805 1206 CSP2 PGND2 1/8W CSN2 SMBJ26A 0805 W125 W125 0R06 1% 1206 SMT RES 1206 1206...
- Page 10 68UH HV GND 7743 470N 470N FDFS6N754 10R0 RGBW SMBJ26A SMBJ26A 68UH 7743 10R0 FDFS6N754 5 CIR C18 R14 7999 Yorkville Score C 2013 PROGRAM DRV=03 M1482 Top Assy M1482 2 OZ BlankSize - 6625 x 11120 SEE LAYOUT DOCUMENTATION...
- Page 11 - YS#8826 4-40 X 3/16 FLAT PHIL U/C TRILOB ZC. 2. MARK WITH INDELIBLE INK, THE YORKVILLE LED REEL NO. ON BOARD IN LOCATION INDICATED. THE YORKVILLE LED REEL NO. IS SHOWN ON THE PARTS REEL. IF THE NUMBER CANNOT BE IDENTIFIED ON THE REEL PLEASE CONTACT THE APPROPRIATE PERSON AT YORKVILLE SOUND LTD.
- Page 12 SEE LAYOUT DIAGRAM M1482 PCB HISTORY M1482 PENDING CHANGES LP-LED4 POD PCB M1482 MODEL(S):- MODEL(S):- LP-LED4 LP-LED4 PENDING CHANGE DATE VER# DESCRIPTION OF CHANGE APRIL 29 2011 V2.00 MAJOR REDESIGN MOVED U1 AND ADDED ESD CIRCUTRY, ADDED ANOTHER GROUNDING SCREW, REMOVE FAN2 CONN.
- Page 13 M1484 Parts Reference List 2/24/2016 YS # Description YS # Description YS # Description 7931 270P 50V 5%CAP 0805 SMT NPO 7860 W125 4K7 5% 0805 SMT RES 7931 270P 50V 5%CAP 0805 SMT NPO 7861 W125 10K 0805 SMT RES 7931 270P 50V 5%CAP 0805 SMT NPO...
- Page 14 MMBT3904 4 W8:C PTC3 FAN-SPD W1:B W125 7838 4 W8:D 0805 BAS21DW5T1 SOT-23 D11:C 7947 D11:B FAN CONNECTOR 100N 0805 0805 100N 0805 W1:A Product LP-LED2 0805 INPUT/OUTPUTS PCB# M1484 Sheet Date: Tue Jan 19, 2016 Rev: YsType:YsType Filename: M1484V03.sch2006...
- Page 15 100U MBRA340T3 {Watts} .2in .2in 100N 100N 100N 100N 100N 100N LOW VOLTAGE 0603 0603 0603 0603 0603 0805 0603 SUPPLY 0805 +3V3 0603 100N Product LP-LED2 MICROCONTROLER PCB# M1484 Sheet Date: Tue Jan 19, 2016 Rev: YsType:YsType Filename: M1484V03.sch2006...
- Page 16 LP-LED2 M1484 BlankSize - 10800x7900 6408 LINK CONTROLLER 3923 7839 3922 Ferrite 3425 MURA240T3 10V0 MMBT3904 4527 4527 4527 6481 ROT H ROT H ROT H SN74AHC138 1-2/3-4 POD#2 7948 Ch1 Color Ch2 Color Function 4 CIR LP-LED2 4161 M1484...
- Page 17 SEE LAYOUT DIAGRAM M1484 PRODUCTION NOTES M1484_PCB_DATABASE_HISTORY MODEL(S):- LP-LED2 DATE VER# DESCRIPTION OF CHANGE 20-AUG-2012 First release 31-OCT-2012 V02 PC8491: Moved Q5 away from J1. - ML 02-FEB-2016 V03 Implemented PC8856 and PC8857: Added fuses F1 and F2 (YS# 5062) to +24V net...
