Quick Installation Guide
IEEE 802.11b+ Wireless LAN
22 Mbps Wireless Access Point
Model: WL22-AP
Installing and Connecting the Access Point
1.
Power everything down, including your PC, your Cable or DSL modem, and your
Hub/Switch/Router.
2.
Connect the Ethernet or Network Cable from Access Point to the HUB or Switch.
3.
Power on the Hub/Switch/Router.
4.
Connect the power supply cable to the power port at the back of the Access Point and then
insert the AC plug into a power outlet.
• The power LED will illuminate RED
• The LINK and TX/RX will illuminate GREEN for 2 second and then will blink for a
few seconds.
5. Power on the Cable or DSL modem. Verify that the power is on by checking the LINK LED
in the WAN connection.
6. Power on your desktop PC or Laptop and activate your wireless LAN adapter (PC/PCI, USB
Adapter, etc.).
The default IP address is 192.168.1.1 with a subnet mask of 255.255.255.0. You will need to
assign your computer a Static IP within the same ranges as the Wireless Access Point's IP
address for the purpose of configuration. The Link LED will light on to indicate a proper
Ethernet connection.
NOTE: When connecting the Access Point to an Ethernet adapter in a computer, please use a
crossover Ethernet cable.
Installing the Configuration Utility
1. Insert the AmbiCom Installation CD into an available CD-ROM drive. Unless you have
deactivated the auto-run feature in Windows, an interactive installation screen should appear
automatically. If an installation screen does not appear automatically, you can access the
installation program by clicking the Start button and selecting Run. In the drop down box
provided, type "D:\setup.exe" and click OK ("D" represents the CD-ROM drive).
2. Click Install WL22 Products
3. Click Install WL22-AP Utility
WL22-AP Quick Installation Guide v.1.1
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AmbiCom WL22-AP
Summary of Contents for AmbiCom WL22-AP
-
Page 1: Quick Installation Guide
Ethernet cable. Installing the Configuration Utility 1. Insert the AmbiCom Installation CD into an available CD-ROM drive. Unless you have deactivated the auto-run feature in Windows, an interactive installation screen should appear automatically. If an installation screen does not appear automatically, you can access the installation program by clicking the Start button and selecting Run. - Page 2 AP(s) on the network. Select one AP and click Apply. 3. The following Login Management window will appear for you to log in. The default for both the username and password is “admin”. WL22-AP Quick Installation Guide v.1.1 Page 2...
- Page 3 The default setting is Fixed IP Address with the IP address of 192.168.1.1 and subnet mask of 255.255.255.0. Please select the DHCP Client Option if your AP is connected to DHCP Server. Click Apply to change the settings. WL22-AP Quick Installation Guide v.1.1 Page 3...
- Page 4 After that, select the Key Length of 64 bits, 128 bits or 256 bits. Click Apply to complete the changes. For Web Management Utility configuration instructions please refer to the user manual located in the Software CD. WL22-AP Quick Installation Guide v.1.1 Page 4...
- Page 5 This warranty gives you specific legal rights. You may also have other rights that vary from state to state. 1 Year Limited Warranty: AmbiCom, Inc. warrants its Wireless LAN products to be free from defects in materials and workmanship, under normal use and service, for 1 year from the date of purchase from its Authorized Reseller.
- Page 6 IMPLIED WARRANTY, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MY NOT APPLY TO YOU. HOWEVER, ANY IMPLIED WARRANTY OR MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE IS FOR A PERIOD OF 1 YEAR ON THIS WRITTEN WARRANTY. WL22-AP Quick Installation Guide v.1.1 Page 6...
