Repotec RP-PE101 Quick Manual

Quick guide for Power over Ethernet Adaptor

1. Introduction

Thank you for purchasing our Power-over-Ethernet Adapter Kit / 802.3af
Power-over-Ethernet PSE Adapter. (PSE refers to "Power Sourcing Equipment")
Before you start installing the Power-over-Ethernet Adapter Kit / 802.3af
Power-over-Ethernet PSE Adapter, verify the following parts in the package.

1.1 Package Contents

The package contains the following:
Power-over-Ethernet Adapter Kit
One unit Power-over-Ethernet Injector, and one unit of Power-over-Ethernet
Splitter
One DC Power Adapter
A Quick Installation Guide for Power-Over-Ethernet Adapter Kit
802.3af Power-over-Ethernet PSE Adapter
One unit of 802.3af Power-over-Ethernet PSE Adapter
One DC Power Adapter
A Quick Installation Guide for Power-over-Ethernet PSE Adapter
If you do not have any of the items listed above, please contact your local distributors
or authorized resellers of the manufacturer.
1.2 Getting to Know the Power-over-Ethernet Adapter Kit /
Power-over-Ethernet PSE Adapter
Power-over-Ethernet Adapter Kit
Injector
Mixes data and power into the RJ-45 connector and then transmits power and data
over the Cat5 cable.
Splitter
Splits data and power out. It can output Ethernet data and DC 5V/1.67A or 12V/1A
power. The network device can accept the power and Ethernet data from the Splitter.
802.3af Power-over-Ethernet PSE Adapter
Mixes data and power into the RJ-45 connector and then transmits power and data to
the Terminal. The module must be use a chip that is compliant 802.3af solution's
controller.
