Page 1: Operating Instruction
COLOR TFT LCD MONITOR OPERATING INSTRUCTION Solutions for: - rear vision systems - car entertainments Before operating this set, please read these instructions completely... - Page 2 TFT LCD MONITOR TFT LCD MONITOR SAFETY PRECAUTIONS : LED :480 (RGB) x 234 ( I m p r o p e r h a n d l i n g f r o m i g n o r i n g CAUTION t h e f o l l o w i n g m a y r e s u l t i n s e r i o u s :0.107mm x 0.370mm...
-
Page 3: Specifications
- DC 12-24 V power input - Provide DC 12V power to cameras - Auto brightness adjustment function(For VFLC00090 ONLY) - 2 Camera inputs, CCD1 is default. CCD2 for Reverse operation. - Auto switch from default CCD1 input toCCD2 input source to check... - Page 4 Auto Power on source: 8.Power On Speed Normal Fast 9. Auto Brightness(FOR VFLC00090 ONLY) 0 Default: all adjustment can be returned back to pre-set value. 3. You can use UP/DOWN key to adjust corresponding item shown on the screen. 4. Press “V1/V2” key to change the video source Press "MENU"...
- Page 5 TFT LCD MONITOR TFT LCD MONITOR Monitor Stand Installation Diagram Monitor Stand Installation Diagram STEP 1: Slide the A part into the slide track of B part to be complete stand. STEP 2: Slide the rear of the monitor housing into the complete stand.
- Page 6 100cm 100cm Black: Video 1 in, Audio 1 in & DC12V out DC12V 6 pin mini din lock-type (female) 6 pin mini din (Disable for VFLC00090) (VFLC00090 Fuse (250V/2.5A) (250V/2.5A) DC12V Red: Video 2 in, Audio 2 in & DC12V out...
