- Page 1 Installation and Operating Manual Domestic Hot Water Tank WWKS 300 WWKS 500 For the professionals Read carefully before installation...
-
Page 2: Table Of Contents
Table of Contents Use ......3 Safety Instructions and Explanation of Symbols ......3 Safety instructions. -
Page 3: Use
The domestic hot water tank serves for heating Any other use, or use over and above that de- and storing process water. Above all, solar sy- scribed, will be considered not in conformity with stems and supplementary heating systems, like intended purpose. -
Page 4: Explanation Of Symbols
Explanation of symbols Notes mark important information for cases in Safety Instructions which there is no danger for humans and the are marked with a warning triangle as machine. shown alongside. Safety instructions mark important information for Spanner cases in which there can be possible danger for specifi... -
Page 5: Specifi Cations
Specifi cations Legal Regulations The Device must be installed and operated according to the following norms and country specifi c directives and provisions • DIN EN 12828 • DIN 18382 • DIN 1988 • DIN EN 12975 • DIN 4708 •... -
Page 6: Technical Data
Technical Data Hot water Heating infl ow Circulation return line Heating return line Cold water / Draining Anode not insulated Thermometer Plug G1 1/2", insulation and cover Blind fl ange with EPDM dia- phragm gasket Plug 1 1/4" Solar return line G1" Solar infl... - Page 7 Tab. 1: Technical Data of the WWKS 300 Tab. 2: Technical data of thr WWKS 500 Domestic hot water tank WWKS 300 Domestic hot water tank WWKS 500 r t i l r t i l Permissible operating tempera- 95° C Permissible operating tempera- 95°...
-
Page 8: Installation
Installation Installation of the tank ensure that the underlying ground is of suffi ci- ent strength. . ► Electrical heating elements may only be in- ► The tank should be positioned min. 10 cm stalled by approved electrical technicians. away from the wall ►... -
Page 9: Maintenance
Maintenance • The cleaning of the tank and the inspection of the plant should be carried out annually. • The functional safety of the safety valve should be checked at regular intervals, with an annu- al maintenance by technical personnel being recommended. -
Page 10: Annexe
Annexe O 500 ±2 ±2 O 600 ±5 „X“ „Y“ 8° ±2 Bild 3: Dimensions of the WWKS 300 Annexe We reserve the right to make changes owing to technical improvements. - Page 11 O 597 377 ±2 390 ±2 O 700 ±5 „Y“ 7° 120 ±2 Bild 4: Dimensions of the WWKS 500 Annexe We reserve the right to make changes owing to technical improvements..
